Diameter 0.1mm Blue / red Superfine thermocouple bare wire with PFA insulation ( type KX / JX / EX )

Product Details

Place of Origin: China

Brand Name: Tankii

Certification: ISO9001

Model Number: JX / EX / KX

Payment & Shipping Terms

Minimum Order Quantity: 100 Meters

Price: Negotiation

Packaging Details: 500m/1000m per roll with plastic film wrapped and carton package. As the order quantity and customer requirement.

Payment Terms: T/T, Western Union, Paypal

Supply Ability: 1000Ton per week

Get Best Price
Contact Now
Specifications
Highlight:

high temperature thermocouple cable

,

thermocouple cable k type

Color:
Red/Black/Blue/yellow/Purple
Insulation Material:
PVC/PFA/PTFE/FB/Silicone Rubber
Conductor Type:
Solid/Stranded
Standard:
GB/IEC/ANSI/BS/DIN/JIS
Item:
Diameter 0.1mm Blue / Red Superfine Thermocouple Bare Wire With PFA Insulation ( Type KX / JX / EX )
Color:
Red/Black/Blue/yellow/Purple
Insulation Material:
PVC/PFA/PTFE/FB/Silicone Rubber
Conductor Type:
Solid/Stranded
Standard:
GB/IEC/ANSI/BS/DIN/JIS
Item:
Diameter 0.1mm Blue / Red Superfine Thermocouple Bare Wire With PFA Insulation ( Type KX / JX / EX )
Description
Diameter 0.1mm Blue / red Superfine thermocouple bare wire with PFA insulation ( type KX / JX / EX )
Diameter 0.1mm Blue / red Superfine thermocouple bare wire with PFA insulation ( type KX / JX / EX )

Quick Details

The thermocouple compensation cables can also be termed as instrumentation cables, since they are used for process temperature measurement. The construction is similar to pair instrumentation cable but the conductor material is different. Thermocouples are used in processes to sense temperature and is connected to the pyrometers for indication and control. The thermocouple and pyrometer are electrically conducted by thermocouple extension cables / thermocouple compensating cables. The conductors used for these thermocouple cables are required to have similar thermo-electric (emf) properties as that of the thermocouple used for sensing the temperature.

Our plant mainly manufacture type KX,NX,EX,JX,NC,TX,SC/RC,KCA,KCB compensating wire for thermocouple, and they are used in temperature measurement instruments and cables. Our thermocouple compensating products are all made abiding by GB/T 4990-2010 ‘Alloy wires of extension and compensating cables for thermocouples’ (Chinese National Standard), and also IEC584-3 ‘Thermocouple part 3-compensating wire’ (International standard).

The representing of the comp. wire: thermocouple code+C/X , e.g. SC, KX

1. X: Short for extension, means that the compensation wire's alloy is as the same as the the alloy of the thermocouple
2. C: Short for compensation, means that the compensation wire's alloy has similar characters with the thermocouple's alloy in a certain temperature range.

Application

1. Heating – Gas burners for ovens
2. Cooling – Freezers
3. Engine protection – Temperatures and surface temperatures
4. High temperature control – Iron casting


Detailed Description

Thermocouple Code Comp. Type Comp. Wire Name Positive Negative
Name Code Name Code
S SC copper-constantan 0.6 copper SPC constantan 0.6 SNC
R RC copper-constantan 0.6 copper RPC constantan 0.6 RNC
K KCA Iron-constantan22 Iron KPCA constantan22 KNCA
K KCB copper-constantan 40 copper KPCB constantan 40 KNCB
K KX Chromel10-NiSi3 Chromel10 KPX NiSi3 KNX
N NC Iron-constantan 18 Iron NPC constantan 18 NNC
N NX NiCr14Si-NiSi4Mg NiCr14Si NPX NiSi4Mg NNX
E EX NiCr10-Constantan45 NiCr10 EPX Constantan45 ENX
J JX Iron-constantan 45 Iron JPX constantan 45 JNX
T TX copper-constantan 45 copper TPX constantan 45 TNX

The color of Insulation and Sheath
Type Insulation Color Sheath Color
Positive Negative G H
/ S / S
SC/RC RED GREEN BLACK GRAY BLACK YELLOW
KCA RED BLUE BLACK GRAY BLACK YELLOW
KCB RED BLUE BLACK GRAY BLACK YELLOW
KX RED BLACK BLACK GRAY BLACK YELLOW
NC RED GRAY BLACK GRAY BLACK YELLOW
NX RED GRAY BLACK GRAY BLACK YELLOW
EX RED BROWN BLACK GRAY BLACK YELLOW
JX RED PURPLE BLACK GRAY BLACK YELLOW
TX RED WHITE BLACK GRAY BLACK YELLOW
Note: G--For general use H--For heat resistant use S--Precision class Normal class has no sign












































Packaging & Delivery

 Packaging Details  Roll with plastic film wrapped and carton package
 Delivery Detail  Shipped in 7 days after payment





Application:
Diameter 0.1mm Blue / red Superfine thermocouple bare wire with PFA insulation ( type KX / JX /  EX ) 0
