High temperature resistance enameled Ni80Cr20 Wire

Name: High temperature resistance enameled Ni80Cr20 Wire
Brand: Shanghai Tankii Alloy Material Co.,Ltd
SKU: Enameled wire
Price: 31.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: Tankii

Certification: ISO9001 Rohs

Model Number: Enameled wire

Payment & Shipping Terms

Minimum Order Quantity: 5KG

Price: negotiable

Packaging Details: Carton box

Delivery Time: 15-25days

Payment Terms: L/C, T/T, Western Union

Supply Ability: 100tons per year

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                              High temperature resistance enamelled wire, Ni80Cr20 enamelled wire, Enamelled wire with high heat resistance


Model NO.:	Ni80Cr20	Color:	Green, Red, Yellow, Blue...
Resistivity:	1.09	Elongation:	Min 20%
Insulation:	Polyester, Polyurethane, Polyimide..	Specification:	Required
Production Capacity:	3000 Tons/Year	Class:	130,155,180,200, 220，240℃
Tensile Strength:	750	Transport Package:	Wooden Case
Trademark:	TANKII	HS Code:	7226920000

Model NO.:	Ni80Cr20
Color:	Green, Red, Yellow, Blue...
Resistivity:	1.09
Elongation:	Min 20%
Insulation:	Polyester, Polyurethane, Polyimide..
Specification:	Required
Production Capacity:	3000 Tons/Year
Class:	130,155,180,200, 220，240℃
Tensile Strength:	750
Transport Package:	Wooden Case
Trademark:	TANKII
HS Code:	7226920000

Description

High temperature resistance enameled Ni80Cr20 Wire

Product Description

These enameled resistance wires have been broadly used for standard resistors, automobile
parts, winding resistors, etc. using the insulation processing best suited for these applications, taking full advantage of the distinctive features of enamel coating.

Furthermore, we will carry out enamel coating insulation of precious metal wire such as silver and platinum wire upon order. Please make use of this production-on-order.

Type Of Nichrome Wire

NiCr80/20,NiCr70/30,NiCr60/15,NiCr90/10,NiCr35/20,NiCr30/20

Type of Insulation

Insulation-enamelled Name	Thermal LevelºC (working time 2000h)	Code Name	GB Code	ANSI. TYPE
Polyurethane enamelled wire	130	UEW	QA	MW75C
Polyester enamelled wire	155	PEW	QZ	MW5C
Polyester-imide enamelled wire	180	EIW	QZY	MW30C
Polyester-imide and polyamide-imide double coated enameled wire	200	EIWH (DFWF)	QZY/XY	MW35C
Polyamide-imide enamelled wire	220	AIW	QXY	MW81C

High temperature resistance enameled Ni80Cr20 Wire 0
