Product Details
Place of Origin: CHINA
Brand Name: TANKII
Certification: ISO9001
Model Number: Nickel 200/Nickel Alloy 200/N6
Payment & Shipping Terms
Minimum Order Quantity: 10kg
Price: USD28-30/kg
Packaging Details: usually packed on the spool, film cover on the wire, all the spool putted in the carton, then put the carton on the wooden pallet or in the wooden case
Delivery Time: 7-10 Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 200ton/Year
Material: |
Pure Nickel |
Shape: |
Round Wire |
Color: |
Bright |
Temper: |
Soft |
Package: |
Packed On The Spool |
Application: |
Fuse In The Lighting |
Density: |
8.9 |
Melting Point: |
1453 |
Boiling Point: |
2732 |
Material: |
Pure Nickel |
Shape: |
Round Wire |
Color: |
Bright |
Temper: |
Soft |
Package: |
Packed On The Spool |
Application: |
Fuse In The Lighting |
Density: |
8.9 |
Melting Point: |
1453 |
Boiling Point: |
2732 |
Pure nickel Wire with Different Color for Insulation Coating Enameled Wire
Product Description
These enameled resistance wires have been broadly used for standard resistors, automobile parts, winding resistors, etc. using the insulation processing best suited for these applications, taking full advantage of the distinctive features of enamel coating.
Furthermore, we will carry out enamel coating insulation of precious metal wire such as silver and platinum wire upon order. Please make use of this production-on-order.
Tpye of Insulation:
1) Polyester resistance wire , class 130
2) Modified polyester resistance wire , class 155
3) Polyesterimide resistance wire , class 180
4) Polyester (imide) coated with polyamide-imide resistance wire , class 200
5) Polyimide resistance wire , class 220
Color of enameled insulation:
Red,Green,Yellow,Black,Blue,Nature etc. |
Type of insulation
Insulation-enamelled Name | Thermal LevelºC (working time 2000h) |
Code Name | ANSI. TYPE | |
Polyurethane enamelled wire | 130 | UEW | MW75C | |
Polyester enamelled wire | 155 | PEW | MW5C | |
Polyester-imide enamelled wire | 180 | EIW | MW30C | |
Polyester-imide and polyamide-imide double coated enameled wire | 200 | EIWH (DFWF) |
MW35C | |
Polyamide-imide enamelled wire | 220 | AIW | MW81C |
Style of supply
Alloys Name | Type | Dimension | ||
Enameled-W | Wire | D=0.018mm~1.2mm | ||
Enameled-R | Ribbon | W=0.4~24 | T=0.01~0.2mm |
Dimension of insulation
D mm |
Min thickness of insulation | Max OD of Enameled | ||
I | II | I | II | |
0.02 | 0.005 | 0.009 | 0.09 | 0.036 |
0.022 | 0.005 | 0.019 | 0.032 | 0.038 |
0.025 | 0.006 | 0.010 | 0.036 | 0.042 |
0.028 | 0.006 | 0.010 | 0.039 | 0.045 |
0.030 | 0.006 | 0.011 | 0.042 | 0.048 |
0.032 | 0.006 | 0.011 | 0.044 | 0.050 |
0.036 | 0.007 | 0.012 | 0.049 | 0.055 |
0.040 | 0.007 | 0.012 | 0.053 | 0.060 |
0.045 | 0.008 | 0.013 | 0.059 | 0.066 |
0.050 | 0.008 | 0.014 | 0.064 | 0.072 |
0.056 | 0.009 | 0.015 | 0.071 | 0.079 |
0.060 | 0.009 | 0.016 | 0.076 | 0.084 |
0.063 | 0.009 | 0.016 | 0.080 | 0.088 |
0.071 | 0.010 | 0.017 | 0.089 | 0.097 |
0.080 | 0.011 | 0.018 | 0.099 | 0.108 |
0.090 | 0.012 | 0.019 | 0.111 | 0.120 |
0.100 | 0.012 | 0.021 | 0.122 | 0.132 |
0.112 | 0.012 | 0.021 | 0.135 | 0.146 |
0.125 | 0.014 | 0.023 | 0.150 | 0.161 |
0.140 | 0.015 | 0.024 | 0.166 | 0.179 |
0.150 | 0.016 | 0.025 | 0.177 | 0.191 |
0.160 | 0.017 | 0.028 | 0.188 | 0.202 |
0.180 | 0.018 | 0.028 | 0.210 | 0.225 |
0.200 | 0.019 | 0.030 | 0.231 | 0.248 |
0.224 | 0.021 | 0.032 | 0.258 | 0.275 |
0.250 | 0.022 | 0.034 | 0.285 | 0.304 |
0.280 | 0.024 | 0.036 | 0.318 | 0.338 |
0.300 | 0.025 | 0.037 | 0.339 | 0.360 |
0.315 | 0.026 | 0.038 | 0.356 | 0.376 |
0.355 | 0.027 | 0.041 | 0.398 | 0.420 |
0.400 | 0.028 | 0.043 | 0.445 | 0.468 |
0.450 | 0.030 | 0.048 | 0.498 | 0.524 |
0.500 | 0.031 | 0.049 | 0.551 | 0.578 |
0.560 | 0.034 | 0.052 | 0.615 | 0.643 |
0.600 | 0.035 | 0.054 | 0.657 | 0.686 |
0.630 | 0.038 | 0.056 | 0.689 | 0.718 |
0.710 | 0.038 | 0.059 | 0.773 | 0.805 |
0.00 | 0.041 | 0.062 | 0.869 | 0.902 |
0.900 | 0.043 | 0.066 | 0.973 | 1.010 |
1.000 | 0.048 | 0.070 | 1.079 | 1.117 |
1.120 | 0.049 | 0.074 | 1.205 | 1.247 |
1.250 | 0.053 | 0.080 | 1.343 | 1.387 |
1.400 | 0.058 | 0.085 | 1.499 | 1.548 |
1.500 | 0.059 | 0.090 | 1.605 | 1.654 |
