High Quality 0.1~3.0mm Thickness C33000 C35300 C35600 Corrosion Resistant Brass copper Plate

Product Details

Place of Origin: Shanghai, China

Brand Name: TANKII

Model Number: C35300

Payment & Shipping Terms

Minimum Order Quantity: 1000 KG

Price: negotiable

Packaging Details: Wooned Case

Delivery Time: 7-20 days

Payment Terms: L/C, T/T, Western Union

Supply Ability: 500 Tons per month

Get Best Price
Contact Now
Specifications
Highlight:

3.0mm Brass copper Plate

,

C35300 Brass copper Plate

,

Corrosion Resistant Brass copper Plate

Model NO.:
C35300
Standard:
ASTM,DIN,En,GB,JIS
Transport Package:
Wooden Case
Trademark:
TANKII
HS Code:
740921000
Origin:
China
Production Capacity:
500tons/Month
Model NO.:
C35300
Standard:
ASTM,DIN,En,GB,JIS
Transport Package:
Wooden Case
Trademark:
TANKII
HS Code:
740921000
Origin:
China
Production Capacity:
500tons/Month
Description
High Quality 0.1~3.0mm Thickness C33000 C35300 C35600 Corrosion Resistant Brass copper Plate









C35300

CHEMICAL COMPOSITION

  Cu% Pb% Fe% Zn%
Nominal Composition       Rem
Min 60.0 1.5
Max 63.0 2.5 0.15



PHYSICAL PROPERTIES

Density g/cm3 8.47
Conductivity at 20°C IACS% 26
Elastic Modulus GPa 103.4
Poisson's ratio 0.37
Thermal expansion coefficient 10-6/ K 11.3



Based on the information provided, it seems you are inquiring about the C35300 strip material. C35300 is a type of brass alloy that is widely used in various industries due to its desirable properties.

Some key characteristics of C35300 brass strip include:

  1. Composition: C35300 is a leaded brass alloy, containing approximately 65% copper, 3% lead, and the remainder primarily zinc.

  2. Mechanical Properties: C35300 has good tensile strength, hardness, and machinability. It is relatively easy to form and fabricate into various components.

  3. Applications: C35300 brass strip is commonly used for items such as hardware fittings, automotive parts, electrical connectors, and other applications where a combination of strength, corrosion resistance, and ease of machining is required.

  4. Availability: C35300 brass strip is commercially available in a range of thicknesses, widths, and tempers to suit different manufacturing and application needs.

If you have any specific questions about the properties, availability, or applications of C35300 brass strip, please feel free to ask, and I'll be happy to provide more detailed information.



MECHANICAL PROPERTIES

State Diameter Yield strength Tensile strength Elongation Hardness
    Mpa MPa % HV
O 10-40 - ≥280 20
1/4H 10-40 - ≥345 ≥10
1/2H 10-40 - ≥380 10



FABRICATION PROPERTIES

Technique suitability
Soldering Excellent
Brazing Good
Oxyacetylene Welding Not Recommended
Gas Shielded Arc Welding Not Recommended
Coated Metal Arc Welding Not Recommended
Spot Weld Not Recommended
Seam Weld Not Recommended
Butt Weld Fair
Capacity for Being Cold Worked Fair
Capacity for Being Hot Formed Poor
Machinability Rating 90

Alloy

System

designation



UNS



EN



JIS

GB

(China)

Cu TK11000 C11000 Cu-ETP C1100 T2





CuCr/Zr

TK15100 C15100 CuZr0.1 C1510 TZr0.1
  TK18160 C18160 CuCr0.5Zr
  TK18150 C18150 CuCr1Zr TCr1-0.15
CuCrSiTi TK18070 C18070 CuCrSiTi



TCr0.3-0.2-

0.05

CuNiSnCrTi TK18090
CuNiP TK19000 C19000 CuNi1P
CuTi TK19920 C19920



CuFe

TK19210 C19210 CuFe0.1P C1921 TFe0.1
  TK19400 C19400 CuFe2P C1940 TFe2.5









CuNiSi

TK19005 C19005
  TK19010 C19010 CuNiSi
  TK70260 C70260 CuNi2Si C7026 BSi2-0.45
  TK70250 C70250 CuNi3SiMg C7025 BSi3.2-0.7
  TK70250HS C70250 CuNi4SiMg C7025
CuNiCoSi TK70318 C70318 CuNi3CoSi

Special

Brass

TK42300 C42300 CuZn10Sn1NiSi
  TK42500 C42500 CuSn3Zn9 HSn88-2





CuSn /

Bronze



TK14415 C14415 CuSn0.15 TSn0.12
  TK51000 C51000 CuSn5 C5102 QSn5-0.2
  TK51100* C51100 CuSn4 C5111 QSn4-0.3
  TK51900* C51900 CuSn6 C5191 QSn6-0.2
  TK52100* C52100 CuSn8 C5210 QSn8-0.3

 High Quality 0.1~3.0mm Thickness  C33000 C35300 C35600 Corrosion Resistant Brass copper Plate 0
