Product Details
Place of Origin: China
Brand Name: TANKII
Certification: ISO,ROHS
Model Number: C35300
Payment & Shipping Terms
Minimum Order Quantity: 1000 KG
Price: -
Packaging Details: Wooned Case
Delivery Time: 7-12 days,
Payment Terms: L/C, T/T, Western Union
Supply Ability: 600,000kg/Month
Standard: |
GB |
Material: |
Copper Lead Zinc Alloy |
Density: |
8.47 G/cm3 |
Surface: |
Bright |
Thickness: |
0.1-20mm |
Width: |
1200mm |
Standard: |
GB |
Material: |
Copper Lead Zinc Alloy |
Density: |
8.47 G/cm3 |
Surface: |
Bright |
Thickness: |
0.1-20mm |
Width: |
1200mm |
CHEMICAL COMPOSITION
| Cu% | Pb% | Fe% | Zn% | |
| Nominal Composition | Rem | |||
| Min | 60.0 | 1.5 | ||
| Max | 63.0 | 2.5 | 0.15 |
PHYSICAL PROPERTIES
| Density g/cm3 | 8.47 |
| Conductivity at 20°C IACS% | 26 |
| Elastic Modulus GPa | 103.4 |
| Poisson's ratio | 0.37 |
| Thermal expansion coefficient 10-6/ K | 11.3 |
MECHANICAL PROPERTIES
| State | Diameter | Yield strength | Tensile strength | Elongation | Hardness |
| Mpa | MPa | % | HV | ||
| O | 10-40 | - | ≥280 | ≥20 | |
| 1/4H | 10-40 | - | ≥345 | ≥10 | |
| 1/2H | 10-40 | - | ≥380 | ≥10 |
FABRICATION PROPERTIES
| Technique | suitability |
| Soldering | Excellent |
| Brazing | Good |
| Oxyacetylene Welding | Not Recommended |
| Gas Shielded Arc Welding | Not Recommended |
| Coated Metal Arc Welding | Not Recommended |
| Spot Weld | Not Recommended |
| Seam Weld | Not Recommended |
| Butt Weld | Fair |
| Capacity for Being Cold Worked | Fair |
| Capacity for Being Hot Formed | Poor |
| Machinability Rating | 90 |
|
Alloy System |
designation |
UNS |
EN |
JIS |
GB (China) |
| Cu | TK11000 | C11000 | Cu-ETP | C1100 | T2 |
|
CuCr/Zr |
TK15100 | C15100 | CuZr0.1 | C1510 | TZr0.1 |
| TK18160 | C18160 | CuCr0.5Zr | — | ||
| TK18150 | C18150 | CuCr1Zr | — | TCr1-0.15 | |
| CuCrSiTi | TK18070 | C18070 | CuCrSiTi |
— |
TCr0.3-0.2- 0.05 |
| CuNiSnCrTi | TK18090 | — | — | — | |
| CuNiP | TK19000 | C19000 | CuNi1P | — | |
| CuTi | TK19920 | C19920 | — | — | — |
|
CuFe |
TK19210 | C19210 | CuFe0.1P | C1921 | TFe0.1 |
| TK19400 | C19400 | CuFe2P | C1940 | TFe2.5 | |
|
CuNiSi |
TK19005 | C19005 | — | — | — |
| TK19010 | C19010 | CuNiSi | — | — | |
| TK70260 | C70260 | CuNi2Si | C7026 | BSi2-0.45 | |
| TK70250 | C70250 | CuNi3SiMg | C7025 | BSi3.2-0.7 | |
| TK70250HS | C70250 | CuNi4SiMg | C7025 | — | |
| CuNiCoSi | TK70318 | C70318 | CuNi3CoSi | — | — |
|
Special Brass |
TK42300 | C42300 | CuZn10Sn1NiSi | — | — |
| TK42500 | C42500 | CuSn3Zn9 | — | HSn88-2 | |
|
CuSn / Bronze
|
TK14415 | C14415 | CuSn0.15 | — | TSn0.12 |
| TK51000 | C51000 | CuSn5 | C5102 | QSn5-0.2 | |
| TK51100* | C51100 | CuSn4 | C5111 | QSn4-0.3 | |
| TK51900* | C51900 | CuSn6 | C5191 | QSn6-0.2 | |
| TK52100* | C52100 | CuSn8 | C5210 | QSn8-0.3 |
