Manganin alloy resistance heating wire 6J11 for measuring apparatus
Manganin alloy resistance heating wire 6J11 for measuring apparatus
Manganin alloy resistance heating wire 6J11 for measuring apparatus
Manganin alloy resistance heating wire 6J11 for measuring apparatus

Manganin alloy resistance heating wire 6J11 for measuring apparatus

Product Details

Place of Origin: China

Brand Name: Tankii

Model Number: 6j11

Payment & Shipping Terms

Minimum Order Quantity: 20kg

Price: USD+30USD/KG

Packaging Details: Cardboard box

Delivery Time: 10days

Payment Terms: T/T

Supply Ability: 10TON/MONTH

Get Best Price
Contact Now

Specifications

Description
Specifications
Highlight:

Manganin alloy resistance heating wire

Description
Manganin alloy resistance heating wire 6J11 for measuring apparatus

Basic Info.

Model NO.
6J11
PCD
120mm
ET
0
Hole
0
State
soft ,hard
surface
bright
standard
GB/ASTM
sample
Free
Size
0.01-10mm
Transport Package
in Roll/Coil/Spool
Specification
0.01-10mm
Trademark
TANKII
Origin
Shanghai, China
HS Code
7409400000
Production Capacity
2000ton/Year

Product Description

Manganin alloy resistance heating wire 6J11 for measuring apparatus

Chemical Content, %
Ni Mn Fe Si Cu Other RoHS Directive
CD Pb Hg Cr
- 10.5-12.5 - - Bal - ND ND ND ND

Mechanical Properties
Max Continuous Service Temp 0-45ºC
Resisivity at 20ºC 0.49±0.03ohm mm2/m
Density 8.G/cm3
Temp Coefficient of Resistance at 20 ºC -80~+80α×10-6/ºC
Melting Point 1450ºC
Tensile Strength(Hard) 635 MPa(min)
Tensile Strength,N/mm2 Annealed,Soft 340~535
Elongation 15%(min)
EMF vs Cu, μV/ºC (0~100ºC) 2
Micrographic Structure Austenite
Magnetic Property Non
Micrographic Structure Ferrite
Magnetic Property Magnetic
Manganin alloy resistance heating wire 6J11 for measuring apparatus 0
Manganin alloy resistance heating wire 6J11 for measuring apparatus 1
Manganin alloy resistance heating wire 6J11 for measuring apparatus 2
Manganin alloy resistance heating wire 6J11 for measuring apparatus 3
Manganin alloy resistance heating wire 6J11 for measuring apparatus 4
