Flexible Copper PVC Insulated Wire Type K 24AWG 26AWG ANSI Standard
Flexible Copper PVC Insulated Wire Type K 24AWG 26AWG ANSI Standard
Flexible Copper PVC Insulated Wire Type K 24AWG 26AWG ANSI Standard
Flexible Copper PVC Insulated Wire Type K 24AWG 26AWG ANSI Standard
Flexible Copper PVC Insulated Wire Type K 24AWG 26AWG ANSI Standard

Flexible Copper PVC Insulated Wire Type K 24AWG 26AWG ANSI Standard

Product Details

Place of Origin: China

Brand Name: Tankii

Certification: ISO 9001

Model Number: Thermocouple cable

Payment & Shipping Terms

Minimum Order Quantity: 200 m

Price: Negotiation

Packaging Details: 5000m/spool,2000m/spool ，customzied

Delivery Time: 5-30days

Payment Terms: T/T, Western Union

Supply Ability: 200000m/month

Get Best Price
Contact Now

Specifications

Description
Specifications
Highlight:

high temperature thermocouple cable

,

type k thermocouple wire

,

thermocouple cable k type

Package:
Boxes
Standard:
ANSI
Type:
K
Insulation:
PTFE/PVC/FIBERGLASS
Certification:
ISO 9001
COLOR:
YELLOW AND RED
Size:
24AWG,26AWG
Package:
Boxes
Standard:
ANSI
Type:
K
Insulation:
PTFE/PVC/FIBERGLASS
Certification:
ISO 9001
COLOR:
YELLOW AND RED
Size:
24AWG,26AWG
Description
Flexible Copper PVC Insulated Wire Type K 24AWG 26AWG ANSI Standard

24AWG 26AWG Flexible copper PVC insulated wires and cables red and white





Characteristics:

  • Feature:

(1)High temperature resistance , insulation

(2)Fire retardant, corrosion resistance, aging resistance

(3)High temperature resistance

(4)High strength, high modulus

(5)Anti-static, smooth appearance

  • Application:

1.Wiring of electrical household appliance

2.Lamps

3.Electrical equipment and high temperature environment ,etc.




Grade: Extension Grade or Thermocuple Grade
temperature range, deg. c -50... +400
type of coductor: K, J, T, E, N, S, R, KX, JX, TX, EX, NX, SX, RX
number of conductors: 1,2,3,4,6
Conductor type Strand or Solid
section area of each core, mm2 (Conductor Size AWG) 20, 24, 30, 32,36,40
material of insulation: fiberglass, PTFE, PTFE, PVC, silicone, kapton, etc
material of jacket: fiberglass, PTFE, PTFE, PVC, silicone, kapton, etc
shielding material: SSB mean Stainless Steel Braid (CUB mean Tinned Copper Braid)
color: ANSI, IEC, etc
quantity and lenght of coil, m(ft) 10*100m, 5*200m, 2*500m, 1*1000m, 3*1000ft, 1*2000ft,




Flexible Copper PVC Insulated Wire Type K 24AWG 26AWG ANSI Standard 0Flexible Copper PVC Insulated Wire Type K 24AWG 26AWG ANSI Standard 1Flexible Copper PVC Insulated Wire Type K 24AWG 26AWG ANSI Standard 2



Tags:

thermocouple cable k type,

type k thermocouple wire,

high temperature thermocouple cable
