Product Details
Place of Origin: China mainland
Brand Name: Tankii
Certification: ISO9001
Model Number: K type thermocouple cable
Payment & Shipping Terms
Minimum Order Quantity: 200 Meters
Price: Negotiation
Packaging Details: 500m/1000m per roll with plastic film wrapped and carton package. As the order quantity and customer requirement.
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 1000Ton per year
Color: |
Green -white- Green |
Insulation Material: |
PTFE |
Conductor Type: |
Solid |
Standard: |
ANSI, IEC |
Leading Time: |
5~7 Days |
Type: |
K Type Thermocouple Cable |
Shipping: |
By DHL/FedEx/TNT/UPS |
Item: |
Multi-wire 7/0.2mm K Type Extension Thermocouple Cable With PTFE Insulation Green Color |
Color: |
Green -white- Green |
Insulation Material: |
PTFE |
Conductor Type: |
Solid |
Standard: |
ANSI, IEC |
Leading Time: |
5~7 Days |
Type: |
K Type Thermocouple Cable |
Shipping: |
By DHL/FedEx/TNT/UPS |
Item: |
Multi-wire 7/0.2mm K Type Extension Thermocouple Cable With PTFE Insulation Green Color |
Name:Thermocouple wire
Model: KX Type
Size: 0.5mm
Rated Temperature:400℃
Structure
Conductor: Positive Ni-Cr, Negative Ni-Si
Insulation: Fiberglass with silicone resin coating
Color: Positive yellow , Negative red
Jacket: Fiberglass with silicone resin coating
Color: yellow
| Thermocouple Code | Comp. Type | Comp. Wire Name | Positive | Negative | ||
| Name | Code | Name | Code | |||
| S | SC | copper-constantan 0.6 | copper | SPC | constantan 0.6 | SNC |
| R | RC | copper-constantan 0.6 | copper | RPC | constantan 0.6 | RNC |
| K | KCA | Iron-constantan22 | Iron | KPCA | constantan22 | KNCA |
| K | KCB | copper-constantan 40 | copper | KPCB | constantan 40 | KNCB |
| K | KX | Chromel10-NiSi3 | Chromel10 | KPX | NiSi3 | KNX |
| N | NC | Iron-constantan 18 | Iron | NPC | constantan 18 | NNC |
| N | NX | NiCr14Si-NiSi4Mg | NiCr14Si | NPX | NiSi4Mg | NNX |
| E | EX | NiCr10-Constantan45 | NiCr10 | EPX | Constantan45 | ENX |
| J | JX | Iron-constantan 45 | Iron | JPX | constantan 45 | JNX |
| T | TX | copper-constantan 45 | copper | TPX | constantan 45 | TNX |
| The color of Insulation and Sheath | ||||||
| Type | Insulation Color | Sheath Color | ||||
| Positive | Negative | G | H | |||
| / | S | / | S | |||
| SC/RC | RED | GREEN | BLACK | GRAY | BLACK | YELLOW |
| KCA | RED | BLUE | BLACK | GRAY | BLACK | YELLOW |
| KCB | RED | BLUE | BLACK | GRAY | BLACK | YELLOW |
| KX | RED | BLACK | BLACK | GRAY | BLACK | YELLOW |
| NC | RED | GRAY | BLACK | GRAY | BLACK | YELLOW |
| NX | RED | GRAY | BLACK | GRAY | BLACK | YELLOW |
| EX | RED | BROWN | BLACK | GRAY | BLACK | YELLOW |
| JX | RED | PURPLE | BLACK | GRAY | BLACK | YELLOW |
| TX | RED | WHITE | BLACK | GRAY | BLACK | YELLOW |
| Note: G--For general use H--For heat resistant use S--Precision class Normal class has no sign | ||||||
| Packaging Details | Roll with plastic film wrapped and carton package |
|---|---|
| Delivery Detail | Shipped in 7 days after payment |
