Constantan Round Parallel Enamelled Wire Insulated Type For Cable Wire

Constantan Round Parallel Enamelled Wire Insulated Type For Cable Wire
Constantan Round Parallel Enamelled Wire Insulated Type For Cable Wire Constantan Round Parallel Enamelled Wire Insulated Type For Cable Wire Constantan Round Parallel Enamelled Wire Insulated Type For Cable Wire Constantan Round Parallel Enamelled Wire Insulated Type For Cable Wire

Large Image :  Constantan Round Parallel Enamelled Wire Insulated Type For Cable Wire

Product Details:
Place of Origin: Shanghai, China
Brand Name: TANKII
Certification: ISO9001:2008
Model Number: CuNi44
Payment & Shipping Terms:
Minimum Order Quantity: 10 kg
Price: To negotiate
Packaging Details: Spool, coil, carton, plywood case with plastic film according to client's requirements
Delivery Time: 7-12 days
Payment Terms: L/C, T/T, Western Union, Pyapal
Supply Ability: 30+TON+MONTH

Constantan Round Parallel Enamelled Wire Insulated Type For Cable Wire

Description
Port: Shanghai, China Usage: Electrical Industry Like Handset, Acostics
Conductor: CuNi Wire Type: Insulated
Standard: GB/JIS/DIN/ASTM Insulation Material: Enamelled
High Light:

enameled wire

,

enamel magnet wire

3 4 5 6 Parallel Enamelled Constantan Round Wire Used for Cable Wire





Constantan cables, with moderate resistance, low thermal coefficient and a flat resistance / tempuratura, have a wider range than the "manganins". It also shows a better resistance to corrosion than the last one. The use tends to be limited to the AC circuit.
Constantan cables is also the negative element of the model J thermocouple with the positovo, iron, model J is used in heating treatment applications. In addition, it is the negative element of the thermocouple T with the positive copper of OFHC, model T is used in the cryogenic temperature.



Type Of Bare Alloy Wire

The alloy we can do enamelled are Copper-nickel alloy wire,Constantan wire,Manganin wire. Kama Wire,NiCr Alloy wire,FeCrAl Alloy wire etc alloy wire

Size:

Round wire:0.018mm~2.5mm

Color of enamel insulation:Red,Green,Yellow,Black,Blue,Nature etc.

Ribbon Size:0.01mm*0.2mm~1.2mm*5mm

Moq:5kg each size





Product Description

These enameled resistance wires have been broadly used for standard resistors, automobile
parts, winding resistors, etc. using the insulation processing best suited for these applications, taking full advantage of the distinctive features of enamel coating.

Furthermore, we will carry out enamel coating insulation of precious metal wire such as silver and platinum wire upon order. Please make use of this production-on-order.





Type of Insulation

Insulation-enamelled Name

Thermal Level℃

(working time 2000h)

Code Name GB Code ANSI. TYPE
Polyurethane enamelled wire 130 UEW QA MW75C
Polyester enamelled wire 155 PEW QZ MW5C
Polyester-imide enamelled wire 180 EIW QZY MW30C
Polyester-imide and polyamide-imide double coated enameled wire 200

EIWH

(DFWF)

QZY/XY MW35C
Polyamide-imide enamelled wire 220 AIW QXY

MW81C





Constantan Round Parallel Enamelled Wire Insulated Type For Cable Wire 0Constantan Round Parallel Enamelled Wire Insulated Type For Cable Wire 1
