Black And Red Color Sc Thermocouple Compensation Cable With PTFE Insulation And Jacket

Black And Red Color Sc Thermocouple Compensation Cable With PTFE Insulation And Jacket
Black And Red Color Sc Thermocouple Compensation Cable With PTFE Insulation And Jacket Black And Red Color Sc Thermocouple Compensation Cable With PTFE Insulation And Jacket Black And Red Color Sc Thermocouple Compensation Cable With PTFE Insulation And Jacket Black And Red Color Sc Thermocouple Compensation Cable With PTFE Insulation And Jacket Black And Red Color Sc Thermocouple Compensation Cable With PTFE Insulation And Jacket

Large Image :  Black And Red Color Sc Thermocouple Compensation Cable With PTFE Insulation And Jacket

Product Details:
Place of Origin: China mainland
Brand Name: Tankii
Certification: ISO9001
Model Number: KX/KC
Payment & Shipping Terms:
Minimum Order Quantity: 200 Meters
Price: Negotiation
Packaging Details: 500m/1000m per roll with plastic film wrapped and carton package. As the order quantity and customer requirement.
Payment Terms: T/T, Western Union, Paypal
Supply Ability: 1000Ton per week

Black And Red Color Sc Thermocouple Compensation Cable With PTFE Insulation And Jacket

Description
Color: Red And Black Insulation Material: PTFE/fep/ Ptfe
Conductor Type: Solid Standard: ANSI
Leading Time: 5~7 Days Type: SC Type Compensation Wire
High Light:

type k thermocouple wire

,

thermocouple cable k type

Black And Red Color Sc Thermocouple Compensation Cable With PTFE Insulation And Jacket

Description:
1. insulator Material Silicone, fiberglass, PTFE, PFA, FEP, PTFE, PVC, Quartz Fiber, Kapton
2.Sheath Material Silicone, fiberglass, PTFE, PFA, FEP, PTFE, PVC,Quartz Fiber, Kapton
3.Conductor material positive: Chromel, negative: Alumel
4.Color code ANSI, IEC, DIN, JIS, BS etc
5.Size: 0000 AWG-46 AWG or customized
6.MOQ: 100m



Detailed Description

Thermocouple Code Comp. Type Comp. Wire Name Positive Negative
Name Code Name Code
S SC copper-constantan 0.6 copper SPC constantan 0.6 SNC
R RC copper-constantan 0.6 copper RPC constantan 0.6 RNC
K KCA Iron-constantan22 Iron KPCA constantan22 KNCA
K KCB copper-constantan 40 copper KPCB constantan 40 KNCB
K KX Chromel10-NiSi3 Chromel10 KPX NiSi3 KNX
N NC Iron-constantan 18 Iron NPC constantan 18 NNC
N NX NiCr14Si-NiSi4Mg NiCr14Si NPX NiSi4Mg NNX
E EX NiCr10-Constantan45 NiCr10 EPX Constantan45 ENX
J JX Iron-constantan 45 Iron JPX constantan 45 JNX
T TX copper-constantan 45 copper TPX constantan 45 TNX

The color of Insulation and Sheath
Type Insulation Color Sheath Color
Positive Negative G H
/ S / S
SC/RC RED GREEN BLACK GRAY BLACK YELLOW
KCA RED BLUE BLACK GRAY BLACK YELLOW
KCB RED BLUE BLACK GRAY BLACK YELLOW
KX RED BLACK BLACK GRAY BLACK YELLOW
NC RED GRAY BLACK GRAY BLACK YELLOW
NX RED GRAY BLACK GRAY BLACK YELLOW
EX RED BROWN BLACK GRAY BLACK YELLOW
JX RED PURPLE BLACK GRAY BLACK YELLOW
TX RED WHITE BLACK GRAY BLACK YELLOW
Note: G--For general use H--For heat resistant use S--Precision class Normal class has no sign








































Packaging & Delivery

Packaging Details Roll with plastic film wrapped and carton package
Delivery Detail Shipped in 7 days after payment





Application:
Black And Red Color Sc Thermocouple Compensation Cable With PTFE Insulation And Jacket 0

FAQ:

1. Payment ways?
T/T, PAYPAL, WESTUNION.

2. When will you arrange the production?
In 12 hours since we get your payment.

3. Product certifications?
MTC , ISO9001, ROHS , SGS as customers' request

4. What kind of informations shall I give you regarding the shipping?
Company name, Recipients, Correct Address, telephone, zip code.

5. What is your warranty ?
For most of our products, the warranty will be 12 months.

6. When will I get a solution for defective products?
Within 48 hours (on working days )

7. What is your shipping way?
DHL, FEDEX, UPS, TNT, EMS, CHINA POST AIR, SEA FREIGHT and AIR FREIGHT!

8. What is your shipping time?
For General Orders, the shipping time will be 5 workdays.

About us

Shanghai Tankii Alloy Material Co., Ltd. specialized in production of thermocouple wire, thermocouple cable, thermocouple connector, and other thermocouple products.

Based on the principle of “first quality, sincere service”, our managing ideology is pursuing technology innovation and creating the top brand in the alloy field. We persist in Quality - the foundation of the survival. It is our forever ideology to serve you with full heart and soul. We committed to provide customers all over the world with high-quality, competitive products and perfect service.

Our products, such us nichrome wire, nichrome strip, fecral wire, fecral strip, thermocouple wire, nickel wire, nickel strip have been exported to Europe, USA, India, Southest Asia, South America,etc.
We are willing to establish strong and long-time partnership with our customers

Your inquiry is a gift for us, your reply is a trust to us, your trust will bring us to provide you the best services in the business. Welcome to call me or email to me for more info on t type thermocouple extension wire.
