IEC Class One 14AWG High Temperature Type K Thermocouple Wire Chromel Alumel Bare Wire

Product Details

Place of Origin: China

Brand Name: Tankii

Certification: ISO9001

Model Number: K

Payment & Shipping Terms

Minimum Order Quantity: 5~10kg as per diameter

Price: USD26~60/kg

Packaging Details: ON spool and carton package. As the order quantity and customer requirement.

Delivery Time: 5-7 days

Payment Terms: T/T, Paypal, Western Union, MoneyGram,

Supply Ability: 2000 Ton per year

Get Best Price
Contact Now
Specifications
Highlight:

IEC class one Thermocouple Bare Wire

,

chromel alumel Thermocouple Bare Wire

,

14AWG Thermocouple Bare Wire

Item:
IEC Class One 14AWG High Temperature Type K Thermocouple Wire Chromel Alumel Bare Wire
Material:
Chromel Alumel
Surface:
Bright Or Oxidized
Diameter:
0.05mm-12mm Available
Grade:
I/II
MOQ:
5~10kg As Per Diameter
Item:
IEC Class One 14AWG High Temperature Type K Thermocouple Wire Chromel Alumel Bare Wire
Material:
Chromel Alumel
Surface:
Bright Or Oxidized
Diameter:
0.05mm-12mm Available
Grade:
I/II
MOQ:
5~10kg As Per Diameter
Description
IEC Class One 14AWG High Temperature Type K Thermocouple Wire Chromel Alumel Bare Wire
IEC class one 14AWG high temperature type K Thermocouple Wire chromel alumel bare wire

Available thermocouple types in Tankii Group: K, J, E, T, N, S, R, B
Solid wire range: 0.05~12mm
Twist wire is also available based on your request.


Quick Details

Type K thermocouple is one of the most popular types of thermocouple.
K thermocouple consists of a positive Nickel/Chromium alloy leg and a negative Nickel/Aluminium leg.
K thermocouple can be used across a wide temperature range (from -200°C to 1250°C), making it suitable for many applications in a variety of industries.
K thermocouple is a much more affordable option than the Platinum based Type R and Type S thermocouples which can be used at higher temperatures.

K type thermocouple wire is commonly used for temperature measurement in high-temperature environments, such as furnace temperature, heat treatment, and melting processes.

What's difference between K type and N type thermocouple wire ?

K type and N type thermocouple wires are two different types of thermocouple wires used for temperature measurement.

The main difference between them is the materials used to make the wires and their temperature ranges.



K type thermocouple wire is made of chromel (90% nickel and 10% chromium) and alumel (95% nickel, 2% manganese, 2% aluminum, and 1% silicon) alloys. It has a temperature range of -200°C to 1350°C and is commonly used in industrial applications.

N type thermocouple wire is made of nicrosil (84% nickel, 14.2% chromium, and 1.4% silicon) and nisil (95% nickel and 5% silicon) alloys.

It has a temperature range of -270°C to 1300°C and is commonly used in aerospace and nuclear applications.

In summary, K type thermocouple wire is used for industrial temperature measurement, while N type thermocouple wire is used for high-precision temperature measurement in extreme environments.


Application of thermocouple wire:

1. Industrial Process Optimization
2. HVAC Systems Management (Heating, Ventilation, and Air Conditioning (HVAC))
3. Precision in Food Processing
4. Medical Equipment and Devices
5. Automotive Performance Optimization
6. Aerospace Exploration and Innovation
7. Power Generation and Distribution
8. Laboratory Research and Development
9. Energy Management and Conservation
10. Safety and Security Enhancement:

Thermocouple Types and Temperature Range

Type
Standard Operating temperature range (°C) Tolerance(°C)
Long term Short term Grade Temperature range Tolerance
Type K GB/T2614 K 1200 1300 I -40~1100 ±1.5°C/±0.4%t
II -40~1300 ±2.5°C/±0.75%t
Type N GB/T17615 N 1200 1300 I -40~1100 ±1.5°C/±0.4%t
II -40~1300 ±2.5°C/±0.75%t
Type E GB/T4993 E 750 900 I -40~800 ±1.5°C/±0.4%t
II -40~900 ±2.5°C/±0.75%t
Type J GB/T4994 J 600 750 I 0~750 ±1.5°C/±0.4%t
II ±2.5°C/±0.75%t
Type T GB/T2903 T 300 350 I -40~350 ±0.5°C/±0.4%t
II ±1°C/±0.75%t
III -200~40 ±1°C/±1.5%t



The Delivery and Packing:

1. Packaging Details: 500m/1000m per roll with plastic film wrapped and carton package.

2. Delivery Detail: 7 days, as the order quantity.

More pictures of thermocouple wire:
IEC Class One 14AWG High Temperature Type K Thermocouple Wire Chromel Alumel  Bare Wire 0
IEC Class One 14AWG High Temperature Type K Thermocouple Wire Chromel Alumel  Bare Wire 1
IEC Class One 14AWG High Temperature Type K Thermocouple Wire Chromel Alumel  Bare Wire 2
Application for thermocouple sensor:
IEC Class One 14AWG High Temperature Type K Thermocouple Wire Chromel Alumel  Bare Wire 3


Application for extension cable:
IEC Class One 14AWG High Temperature Type K Thermocouple Wire Chromel Alumel  Bare Wire 4

With Insulation
IEC Class One 14AWG High Temperature Type K Thermocouple Wire Chromel Alumel  Bare Wire 5
