Thermocouple Alloys Type J White 0.2mm Thermocouple Wire for Thermocouple Extension Alloy Wires

Platinum-rhodium thermocouple wire
Non-insulated fine diameter, single wire and pair wire, ultra-high temperature resistant
Types S, R and B
R-type and S-type temperature range 1398 ~ 1482°C (2550 ~ 2700°F)
Type B is suitable for continuous use at temperatures up to 1704°C (3100°F)
To effectively prevent oxidation and corrosion at high temperatures, DLX offers high-quality uninsulated thermometer wires that can be applied to 3 types of "precious metal" thermocouples:
Type S: Platinum (-) and Platinum 10% Rhodium (+)
Type R: Platinum (-) and Platinum 13% Rhodium (+)
Type B: Platinum 6% Rhodium (-) and Platinum 30% Rhodium (+)
Types R and S are recommended for continuous use in oxidizing or inert atmospheres at temperatures up to 1398°C (2550°F), or short-term exposure to high temperatures up to 1482°C (2700°F). Type B is suitable for continuous use in oxidizing or inert atmospheres up to 1704°C (3100°F). When working close to the maximum temperature, it is recommended to use a larger wire diameter.
All 3 types of thermocouples can be used in a vacuum environment for short periods of time. Type B provides the best stability when applied in a vacuum environment. All 3 models are not suitable for use in reducing gases or environments containing metallic or non-metallic vapors unless a non-metallic protective sleeve is used. Never insert thermocouples directly into metal protective sleeves.
Wire diameters range from 0.025 to 0.812 mm (0.001 to 0.032"). If desired, thermocouple wires can be supplied in pairs that meet or exceed standard error limits. Special error limit wires are available on request and must be paired order.

The allowable grade and Tolerance are obtained at 0℃
