Ni76Cr2Cu5 E11a Soft Magnetic Wires 0.01mm Heat Treatment

Ni76Cr2Cu5 E11a Soft Magnetic Wires 0.01mm Heat Treatment
Ni76Cr2Cu5 E11a Soft Magnetic Wires 0.01mm Heat Treatment Ni76Cr2Cu5 E11a Soft Magnetic Wires 0.01mm Heat Treatment Ni76Cr2Cu5 E11a Soft Magnetic Wires 0.01mm Heat Treatment

Large Image :  Ni76Cr2Cu5 E11a Soft Magnetic Wires 0.01mm Heat Treatment

Product Details:
Place of Origin: Shanghai, China
Brand Name: TANKII
Certification: ISO9001 SGS
Model Number: Ni76Cr2Cu5
Payment & Shipping Terms:
Minimum Order Quantity: 100 KG
Price: negotiable
Packaging Details: Spool + Carton + Wooned Case
Delivery Time: 7-20 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100 Tons per month

Ni76Cr2Cu5 E11a Soft Magnetic Wires 0.01mm Heat Treatment

Description
Material: Ni76Cr2Cu5 Diameter: 0.02-5.00mm
Density: 8.60 G/cm3 Resisivity: 0.55
Curie Point: 400 C Shape: Wire, Rod, Strip
HS Code: 75052200 Elongation: 2%-40%
High Light:

E11a Soft Magnetic Wires

,

Ni76Cr2Cu5 Soft Magnetic Wires

,

Soft Magnetic Wires 0.01mm

Permalloy 1j76 Ni76Cr2Cu5 E11a High Permeability Soft Magnetic Alloy Wire



1J76 (Soft magnetic alloy)

1J76 is a nickel-iron magnetic alloy, with about 80% nickel and 20% iron content. Invented in 1914 by physicist Gustav Elmen at Bell Telephone Laboratories,

it is notable for its very high magnetic permeability, which makes it useful as a magnetic core material in electrical and electronic equipment, and also in magnetic shielding to block magnetic fields. Commercial permalloy alloys typically have relative permeability of around 100,000, compared to several thousand for ordinary steel.

In addition to high permeability, its other magnetic properties are low coercivity, near zero magnetostriction, and significant anisotropic magnetoresistance. The low magnetostriction is critical for industrial applications, allowing it to be used in thin films where variable stresses would otherwise cause a ruinously large variation in magnetic properties.

Permalloy's electrical resistivity can vary as much as 5% depending on the strength and the direction of an applied magnetic field. Permalloys typically have the face centered cubic crystal structure with a lattice constant of approximately 0.355 nm in the vicinity of a nickel concentration of 80%.



A disadvantage of permalloy is that it is not very ductile or workable, so applications requiring elaborate shapes, such as magnetic shields, are made of other high permeability alloys such as mu metal. Permalloy is used in transformer laminations and magnetic recording heads.


1J76 widely used in radio-electronic industry, precision instruments, remote control and automatic control system.

Normal composition%

Ni 75~76.5 Fe Bal. Mn 0.3~0.6 Si 0.15~0.3
Mo - Cu 4.8~5.2 Cr 1.8~2.2
C ≤0.03 P ≤0.02 S ≤0.02


Typical Mechanical properties

Yield strength Tensile Strength Elongation
Mpa Mpa %
980 1030 3~50


Typical Physical properties

Density (g/cm3) 8.6
Electrical resistivity at 20ºC(Om*mm2/m) 0.55
Coefficient of linear expansion(20ºC~200ºC)X10-6/ºC 10.3~11.5
Saturation magnetostriction coefficient λθ/ 10-6 2.4
Curie point Tc/ ºC 400

The magnetic properties of alloys with high permeability in weak fields
1J76 Initial permeability Maximum permeability Coercivity Saturation magnetic induction intensity
Сold-rolled strip/ sheet.
Thickness, mm
μ0.08/ (mH/m) μm/ (mH/m) Hc/ (A/m) BS/ T
0.01 mm 17.5 87.5 5.6









0.75
0.1~0.19 mm 25.0 162.5 2.4
0.2~0.34 mm 28.0 225.0 1.6
0.35~1.0 mm 30.0 250.0 1.6
1.1~2.5 mm 27.5 225.0 1.6
2.6~3.0 mm 26.3 187.5 2.0
cold drawn wire
0.1 mm 6.3 50 6.4
Bar
8-100 mm 25 100 3.2
Mode of heat treatment 1J76
Annealing media Vacuum with a residual pressure not higher than 0.1Pa, hydrogen with a dew point of not higher than minus 40 ºC.
The heating temperature and rate 1100~1150ºC
Holding time 3~6
Cooling rate With 100 ~ 200 ºC/ h cooled to 600 ºC, rapidly cooled to 300ºC


Style of supply

Alloys Name Type Dimension
1J76 Wire D= 0.1~8mm
1J76 Strip W= 8~390mm T= 0.3mm
1J76 Foil W= 10~100mm T= 0.01~0.1
1J76 Bar Dia= 8~100mm L= 50~1000
