Titanium Alloy Strip TC2 Gr9 Ti-3Al-2.5V for Aerospace Hydraulic

Name: Titanium Alloy Strip TC2 Gr9 Ti-3Al-2.5V for Aerospace Hydraulic
Brand: Shanghai Tankii Alloy Material Co.,Ltd
SKU: Gr.9 / TC2 (Ti-3Al-2.5V)
Price: 40 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: TANKIN

Certification: ISO9001

Model Number: Gr.9 / TC2 (Ti-3Al-2.5V)

Payment & Shipping Terms

Minimum Order Quantity: 50kg

Price: 40 usd

Packaging Details: Cardboard packaging+wooden box

Delivery Time: 10-30days

Payment Terms: T/T

Supply Ability: 5000kg/month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:

Grade:	Gr.9 / TC2 (Ti-3Al-2.5V)	Thickness:	0.05 – 6 Mm
Width:	5 – 1200 Mm (customized)	Standard:	ASTM B265
Mechanical:	Rm ≥ 620 MPa, A ≥ 15%	Application:	Aerospace Hydraulic Tube, Bicycle, Sports

Grade:	Gr.9 / TC2 (Ti-3Al-2.5V)
Thickness:	0.05 – 6 Mm
Width:	5 – 1200 Mm (customized)
Standard:	ASTM B265
Mechanical:	Rm ≥ 620 MPa, A ≥ 15%
Application:	Aerospace Hydraulic Tube, Bicycle, Sports

Description

Titanium Alloy Strip TC2 Gr9 Ti-3Al-2.5V for Aerospace Hydraulic

Ti-3Al-2.5V (TC2, Gr9) Titanium Alloy Strip

Ti-3Al-2.5V, also known as "half 6-4", offers strength close to Ti-6Al-4V with significantly better cold formability and weldability, making it the standard for aerospace hydraulic tubing and high-performance consumer products.

Specifications:

Gr.7 / TA9; Pd 0.12-0.25%; ASTM B265; Rm ≥ 345 MPa; thickness 0.05-30 mm; width 5-1250 mm.

Advantages:

Gr.9 / TC2; Al 2.5-3.5%, V 2.0-3.0%; ASTM B265; Rm ≥ 620 MPa, elongation ≥ 15%; thickness 0.05-6 mm; width 5-600 mm.

Chemical Composition Reference (wt%, Maximum Value)

ASTM Grade	GB Grade	JIS Grade	N max	C max	H max	Fe max	O max	Alloying Elements	Others
Gr.1	TA1	Class 1	0.03	0.08	0.015	0.20	0.18		Balance Ti
Gr.2	TA2	Class 2	0.03	0.08	0.015	0.30	0.25		Balance Ti
Gr.3	TA3	Class 3	0.05	0.08	0.015	0.30	0.35		Balance Ti
Gr.4	TA4	Class 4	0.05	0.08	0.015	0.50	0.40		Balance Ti
Gr.5	TC4	Class 60	0.05	0.08	0.015	0.40	0.20	Al:5.5-6.75, V:3.5-4.5	Balance Ti
Gr.7	TA9	Class 12	0.03	0.08	0.015	0.30	0.25	Pd:0.12-0.25	Balance Ti
Gr.9	TC2	Class 61	0.03	0.08	0.015	0.25	0.15	Al:2.5-3.5, V:2.0-3.0	Balance Ti
Gr.11	TA9-1	Class 11	0.03	0.08	0.015	0.20	0.18	Pd:0.12-0.25	Balance Ti
Gr.23	TC4 ELI	Class 60E	0.03	0.08	0.0125	0.25	0.13	Al:5.5-6.5, V:3.5-4.5	Balance Ti

Mechanical Properties Reference (Room-temperature ≥ Value; High-temperature data for reference)

Grade	Rm Tensile Strength(MPa)	Rp0.2 Yield Strength(MPa)	Elongation A(%)	Reduction of Area Z(%)	Test Temp(ºC)	HighTemp Rm(MPa)	StressRupture Strength(MPa)
TA1	240	140	24	30	-	-	-
TA2	400	275	20	30	-	-	-
TA3	500	380	18	30	-	-	-
TA5	685	585	15	40	-	-	-
TA6	685	585	10	27	350	420	390
TA7	785	680	10	25	350	490	440
TC1	585	460	15	30	350	345	325
TC2	685	560	12	30	350	420	390
TC4	895	825	10	25	400	620	570
TC6	980	840	10	25	400	735	665
TC9	1060	910	9	25	500	785	590
TC10	1030	900	12	25	400	835	785
TC11	1030	900	10	30	500	685	588

Note: All chemical and mechanical data are standard reference values. Actual performance depends on thickness, temper and production batch.

Core Advantages

High strength with excellent cold formability; good fatigue life; light and corrosion resistant.

Application

Aerospace hydraulic tubing, bicycle and motorcycle frames, sports equipment, springs.
