Titanium Alloy Sheet Plate TC4 ELI Gr23 for Medical Implant ASTM F136

Name: Titanium Alloy Sheet Plate TC4 ELI Gr23 for Medical Implant ASTM F136
Brand: Shanghai Tankii Alloy Material Co.,Ltd
SKU: Gr.23 / TC4 ELI (Ti-6Al-4V ELI)
Price: 60 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: TANKIN

Certification: ISO9001

Model Number: Gr.23 / TC4 ELI (Ti-6Al-4V ELI)

Payment & Shipping Terms

Minimum Order Quantity: 10kg

Price: 60 usd

Packaging Details: Cardboard packaging+wooden box

Delivery Time: 10-30days

Payment Terms: T/T

Supply Ability: 5000kg/month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:

Grade:	Gr.23 / TC4 ELI (Ti-6Al-4V ELI)	Thickness:	0.05 – 60 Mm
Width:	5 – 1200 Mm (customized)	Standard:	ASTM F136 / ASTM B265
Mechanical:	Rm ≥ 828 MPa, Low Interstitials, Good Impact Toughness	Application:	Bone Plate, Screw, Medical Implant, Surgical Instrument

Grade:	Gr.23 / TC4 ELI (Ti-6Al-4V ELI)
Thickness:	0.05 – 60 Mm
Width:	5 – 1200 Mm (customized)
Standard:	ASTM F136 / ASTM B265
Mechanical:	Rm ≥ 828 MPa, Low Interstitials, Good Impact Toughness
Application:	Bone Plate, Screw, Medical Implant, Surgical Instrument

Description

Titanium Alloy Sheet Plate TC4 ELI Gr23 for Medical Implant ASTM F136

TC4 ELI (Gr23) Titanium Alloy for Medical Implants

TC4 ELI (Extra Low Interstitial) is the implant-grade version of Ti-6Al-4V, with tight control of oxygen, nitrogen and iron to improve fracture toughness and ductility. It is the standard material for orthopedic implants, supplied to ASTM F136.

Specifications: Gr.23; ASTM F136 / B265; Rm ≥ 828 MPa; low interstitial content; thickness 0.05-60 mm; width 5-1200 mm.

Chemical Composition Reference (wt%, Maximum Value)

ASTM Grade	GB Grade	JIS Grade	N max	C max	H max	Fe max	O max	Alloying Elements	Others
Gr.1	TA1	Class 1	0.03	0.08	0.015	0.20	0.18		Balance Ti
Gr.2	TA2	Class 2	0.03	0.08	0.015	0.30	0.25		Balance Ti
Gr.3	TA3	Class 3	0.05	0.08	0.015	0.30	0.35		Balance Ti
Gr.4	TA4	Class 4	0.05	0.08	0.015	0.50	0.40		Balance Ti
Gr.5	TC4	Class 60	0.05	0.08	0.015	0.40	0.20	Al:5.5-6.75, V:3.5-4.5	Balance Ti
Gr.7	TA9	Class 12	0.03	0.08	0.015	0.30	0.25	Pd:0.12-0.25	Balance Ti
Gr.9	TC2	Class 61	0.03	0.08	0.015	0.25	0.15	Al:2.5-3.5, V:2.0-3.0	Balance Ti
Gr.11	TA9-1	Class 11	0.03	0.08	0.015	0.20	0.18	Pd:0.12-0.25	Balance Ti
Gr.23	TC4 ELI	Class 60E	0.03	0.08	0.0125	0.25	0.13	Al:5.5-6.5, V:3.5-4.5	Balance Ti

Mechanical Properties Reference (Room-temperature ≥ Value; High-temperature data for reference)

Grade	Rm Tensile Strength(MPa)	Rp0.2 Yield Strength(MPa)	Elongation A(%)	Reduction of Area Z(%)	Test Temp(ºC)	HighTemp Rm(MPa)	StressRupture Strength(MPa)
TA1	240	140	24	30	-	-	-
TA2	400	275	20	30	-	-	-
TA3	500	380	18	30	-	-	-
TA5	685	585	15	40	-	-	-
TA6	685	585	10	27	350	420	390
TA7	785	680	10	25	350	490	440
TC1	585	460	15	30	350	345	325
TC2	685	560	12	30	350	420	390
TC4	895	825	10	25	400	620	570
TC6	980	840	10	25	400	735	665
TC9	1060	910	9	25	500	785	590
TC10	1030	900	12	25	400	835	785
TC11	1030	900	10	30	500	685	588

Note: All chemical and mechanical data are standard reference values. Actual performance depends on thickness, temper and production batch.

Core Advantages

Excellent corrosion resistance against seawater, chloride and most acidic media
Low density with high specific strength, lightweight structural material
Good ductility for ultra-thin rolling, precision slitting and deep drawing
Vacuum-packed to avoid surface oxidation during delivery
Multiple grades for medical, chemical, aerospace and new-energy scenarios

Application

Chemical anti-corrosion liners, plate heat exchangers, medical accessories, aerospace thermal shielding, laboratory corrosion-resistant samples, electronic precision components.
