Fecral Alloy 0cr21al6nb 0cr27al7mo2 0cr25al5 Furnace Electric Heating Element

Name: Fecral Alloy 0cr21al6nb 0cr27al7mo2 0cr25al5 Furnace Electric Heating Element
Brand: Shanghai Tankii Alloy Material Co.,Ltd
SKU: 0cr21al6nb
Price: 111.80 USD
Availability: InStock

Product Details

Place of Origin: CHINA

Brand Name: TANKII

Certification: ISO9001

Model Number: 0cr21al6nb

Payment & Shipping Terms

Minimum Order Quantity: 20kg

Price: negotiation

Packaging Details: spool+plastic bag+carton+pallet for resistance wires

Payment Terms: L/C, T/T, Western Union

Supply Ability: 20, 000kg/month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                            0cr27al7mo2 Electric Heating Element, 0cr21al6nb Electric Heating Element, 0cr25al5 Electric Heating Element


Color:	Sliver Or Polish	Conductor Material:	Fecral
Surface:	Bright And Oxidation	Feature::	High Nickel, High Resistance
Certificate::	ISO 9001 RoHS SGS	Type:	FeCrAl Rod
Feature:	High Nickel,high Resistance

Color:	Sliver Or Polish
Conductor Material:	Fecral
Surface:	Bright And Oxidation
Feature::	High Nickel, High Resistance
Certificate::	ISO 9001 RoHS SGS
Type:	FeCrAl Rod
Feature:	High Nickel,high Resistance

Description

Fecral Alloy 0cr21al6nb 0cr27al7mo2 0cr25al5 Furnace Electric Heating Element

Cheap Price Fecral Alloy 0cr21al6nb 0cr27al7mo2 0cr25al5 Furnace Electric Heating Element

Model NO.

0cr21al6nb

Material

Fe-Cr-Al Wire

Form

Heating Wire

Shape

Wire/Rod

Density

7.1 g/cm3

Thermal Conductivity

46.1 Kj/M.H

Resistivity

1.45+/-5% Ohm/M

Melting Point

1500c

Surface

Bright, Acid White, Oxidation

Hardness

200-260hv

Elongation

Min12

Working Tem

1250c

Transport Package

Carton or Wooden Box

Specification

0.025-10mm

Trademark

TANKII

Origin

China

HS Code

7223000000

Production Capacity

500tons/Month

Packaging & Delivery

Package Size

12.00cm * 12.00cm * 12.00cm

Package Gross Weight

1.000kg

FeCrAl alloy has the characteristic of high resistivity,low temperature resistance coefficient,high operating temperature,goodanti-oxidation and anti-corrosion under high temperature.

It is widely used in industrial furnace, household appliances, industry furnace, metallurgy, machinery, aircraft, automotive,
and other industries producing heating elements and resistance elements.

Alloy Nomenclature Performance		1Cr13AL4	0Cr25Al5	0Cr21AL6	0Cr23Al5	0Cr21Al4	0Cr21Al6Nb	0Cr27Al7Mo2
	Cr	12.0-15.0	23.0-26.0	19.0-22.0	20.5-23.5	18.0-21.0	21.0-23.0	26.5-27.8
	Al	4.0-6.0	4.5-6.5	5.0-7.0	4.2-5.3	3.0-4.2	5.0-7.0	6.0-7.0
Main Chemical composition	Re	opportune	opportune	opportune	opportune	opportune	opportune	opportune
	Fe	Rest	Rest	Rest	Rest	Rest	Rest	Rest
							Nb0.5	Mo1.8-2.2
Max. continuous service temp. of element(ºC)		950	1250	1250	1250	1100	1350	1400
Resistivity at 20ºC(μΩ/m)		1.25	1.42	1.42	1.35	1.23	1.45	1.53
Density(g/cm3)		7.4	7.1	7.16	7.25	7.35	7.1	7.1
Thermal conductivity(KJ/m.h.ºC)		52.7	46.1	63.2	60.2	46.9	46.1	--
Coefficient of lines expansion(α*10-6/ºC)		15.4	16	14.7	15	13.5	16	16
Melting point approx.( ºC)		1450	1500	1500	1500	1500	1510	1520
Tensile strength(N/mm2)		580-680	630-780	630-780	630-780	600-700	650-800	680-830
Elongation at rupture(%)		>16	>12	>12	>12	>12	>12	>10
Variation of area(%)		65-75	60-75	65-75	65-75	65-75	65-75	65-75
Repeat Bending frequency(F/R)		>5	>5	>5	>5	>5	>5	>5
Hardness(H.B.)		200-260	200-260	200-260	200-260	200-260	200-260	200-260
continuous service time(Hours/ ºC)		--	≥80/1300	≥80/1300	≥80/1300	≥80/1250	≥50/1350	≥50/1350
Micrographic structure		Ferrite	Ferrite	Ferrite	Ferrite	Ferrite	Ferrite	Ferrite
Magnetic properties		Magnetic	Magnetic	Magnetic	Magnetic	Magnetic	Magnetic	Magnetic

Fecral Alloy 0cr21al6nb 0cr27al7mo2 0cr25al5 Furnace Electric Heating Element 0

Fecral Alloy 0cr21al6nb 0cr27al7mo2 0cr25al5 Furnace Electric Heating Element 1

Fecral Alloy 0cr21al6nb 0cr27al7mo2 0cr25al5 Furnace Electric Heating Element 2
