Ni200 18650 Pure Nickel Strip Corrosion Resistant High Thermal Conductivity Electric Resistance Wire

Name: Ni200 18650 Pure Nickel Strip Corrosion Resistant High Thermal Conductivity Electric Resistance Wire
Brand: Shanghai Tankii Alloy Material Co.,Ltd
SKU: Nickel 200
Price: 29.00 USD
Availability: InStock

Product Details

Place of Origin: CHINA

Brand Name: TANKII

Certification: ISO9001

Model Number: Nickel 200

Payment & Shipping Terms

Minimum Order Quantity: 10kg

Price: USD28-30/kg

Packaging Details: usually packed on the spool, film cover on the wire, all the spool putted in the carton, then put the carton on the wooden pallet or in the wooden case

Delivery Time: 7-10 Days

Payment Terms: L/C, T/T, Western Union

Supply Ability: 200ton/Year

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                  Ni200 18650 nickel strip, pure nickel 200 battery strip, electric resistance nickel wire


Material:	Pure Nickel	Shape:	Round Wire
Color:	Bright	Temper:	Soft
Package:	Packed On The Spool	Application:	Fuse In The Lighting
Density:	8.9	Melting Point:	1453
Boiling Point:	2732

Material:	Pure Nickel
Shape:	Round Wire
Color:	Bright
Temper:	Soft
Package:	Packed On The Spool
Application:	Fuse In The Lighting
Density:	8.9
Melting Point:	1453
Boiling Point:	2732

Description

Ni200 18650 Pure Nickel Strip Corrosion Resistant High Thermal Conductivity Electric Resistance Wire

Ni200 18650 Nickel Strip Pure Nickel 200 Strip 99.96

General Description
Commercially wrought Nickel 200 ( UNS N02200) , a grade of pure nickel contains 99.2% nickel, has excellent mechanical properties, magnetic properties, high thermal, electrical conductivity and excellent resistance to many corrosive environment. Nickel 200 is useful in any environment below 600ºF(315ºC). It has highly resistance to neutral and alkaline salt solutions. Nickel 200 also has low corrosion rates in neutral and distilled water.
The applications of pure nickel includes food processing equipment, magnetostrictive devices and rechargeable batteries, computers, cellular Phone, power tools, camcorders and so on.
Chemical Composition

Alloy	Ni%	Mn%	Fe%	Si%	Cu%	C%	S%
Nickel 200	Min 99.2	Max 0.35	Max 0.4	Max 0.35	Max 0.25	Max 0.15	Max 0.01

Physical Data

Density	8.89g/cm3
Specific Heat	0.109(456 J/kg.ºC)
Electrical Resistivity	0.096×10-6ohm.m
Melting Point	1435-1446ºC
Thermal Conductivity	70.2 W/m-K
Mean Coeff Thermal Expansion	13.3×10-6m/m.ºC

Typical Mechanical Properties

Mechanical Properties	Nickel 200
Tensile Strength	462 Mpa
Yield Strength	148 Mpa
Elongation	47%

Our Production Standard

	Bar	Forging	Pipe	Sheet/Strip	Wire
ASTM	ASTM B160	ASTM B564	ASTM B161/B163/B725/B751	AMS B162	ASTM B166

Specification of Cold-drawing Strip Type

Thickness(mm)	Tolerance(mm)	Width(mm)	Tolerance(mm)
0.05-0.10	±0.010	5.00-10.0	±0.2
>0.10-0.20	±0.015	>10.0-20.0	±0.2
>0.20-0.50	±0.020	>20.0-30.0	±0.2
>0.50-1.00	±0.030	>30.0-50.0	±0.3
>1.00-1.80	±0.040	>50.0-90.0	±0.3
>1.80-2.50	±0.050	>90.0-120.0	±0.5
>2.50-3.50	±0.060	>120.0-250.0	±0.6

Do you need a different steel quality or dimension? Please write to us. Our sales team makes an offer from stock program or delivery program :)

Length tolerance +/-2mm

Description:

Production time - 5-7 weeks.
Preparation for shipment - 2-3 working days.
Look at the FAQ please.

radio and electrical engineering (electrical and electronic components);
Vehicle construction;
medical technology;
Domestic appliances;
Food industry (handling of cooling brine, fatty acids and fruit juices).

Wire made of nickel is characterized by the following properties:

high electrical and thermal conductivity;
good temperature resistance (up to 300 °C);
high ductility;
excellent resistance to alkaline and corrosive media;
good mechanical properties (easily polished, welded and forged);

excellent acid resistance.
