Nichrome Wire Resistance Wire NiCr90/10 NiCr80/20 NiCr70/30 NiCr6015 Electric Resistance Wire For PTC Heater

Name: Nichrome Wire Resistance Wire NiCr90/10 NiCr80/20 NiCr70/30 NiCr6015 Electric Resistance Wire For PTC Heater
Brand: Shanghai Tankii Alloy Material Co.,Ltd
SKU: NiCr 60/15
Price: 22.00 USD
Availability: InStock

Product Details

Place of Origin: Shanghai

Brand Name: Tankii

Certification: DIN, ASTM, JIS

Model Number: NiCr 60/15

Payment & Shipping Terms

Minimum Order Quantity: 20kg

Price: 15-30$

Packaging Details: spool ,coil, or as clients' requirement

Delivery Time: 25days

Payment Terms: L/C, D/A, D/P, T/T, Western Union

Supply Ability: 1000T/month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                    NiCr70/30 Electric Resistance Wire, NiCr80/20 Electric Resistance Wire, NiCr90/10 Electric Resistance Wire


Application:	Heating	Conductor Material:	Copper
Type:	Low Voltage	Insulation Material:	Pvc
Jacket:	Rubber	Color:	As Required
Insulation:	Silicone Rubber	Rated Voltage:	300/500v
Conductor Type:	Solid	Standard:	IEC

Application:	Heating
Conductor Material:	Copper
Type:	Low Voltage
Insulation Material:	Pvc
Jacket:	Rubber
Color:	As Required
Insulation:	Silicone Rubber
Rated Voltage:	300/500v
Conductor Type:	Solid
Standard:	IEC

Description

Nichrome Wire Resistance Wire NiCr90/10 NiCr80/20 NiCr70/30 NiCr6015 Electric Resistance Wire For PTC Heater

Nichrome Wire Resistance Wire NiCr90/10 NiCr80/20 NiCr70/30 NiCr6015 Electric Resistance Wire For PTC Heater

Detailed Description:
Ni60Cr15 is a nickel-chromium alloy (NiCr alloy) characterized by high resistivity, good oxidation resistance ,good form stability and good ductility and excellent weldability. It is suitable for use at temperatures up to 1150°C.

Typical applications for Ni60Cr15 are used in metal sheathed tubular elements,for example,hot plates,
grills,toaster ovens and storage heaters.The alloys is also used for suspended coils in air heaters in clothes dryers,fan heaters,hand dryers etc.

Normal composition%

C	P	S	Mn	Si	Cr	Ni	Al	Fe	Other
Max
0.08	0.02	0.015	0.60	0.75~1.60	15.0~18.0	55.0~61.0	Max 0.50	Bal.	-

Typical Mechanical properties(1.0mm)

Yield strength	Tensile Strength	Elongation
Mpa	Mpa	%
370	730	35

Typical Physical properties

Density (g/cm3)	8.2
Electrical resistivity at 20ºC(mm2/m)	1.12
Conductivity coefficient at 20ºC (WmK)	13

Coefficient of thermal expansion
Temperature	Coefficient of Thermal Expansion x10-6/ºC
20 ºC- 1000ºC	17

Specific heat capacity
Temperature	20ºC
J/gK	0.46

Melting point (ºC)	1390
Max continuous operating temperature in air (ºC)	1150
Magnetic properties	non-magnetic

Temperature Factors Of Electrical Resistivity

20ºC	100ºC	200ºC	300ºC	400ºC	500ºC	600ºC
1	1.011	1.024	1.038	1.052	1.064	1.069
700ºC	800ºC	900ºC	1000ºC	1100ºC	1200ºC	1300ºC
1.073	1.078	1.088	1.095	1.109	-	-

Chemical Composition and Properites:

Properties/Grade		NiCr 80/20	NiCr 70/30	NiCr 60/15	NiCr 35/20	NiCr 30/20
Main Chemical Composition(%)	Ni	Bal.	Bal.	55.0-61.0	34.0-37.0	30.0-34.0
	Cr	20.0-23.0	28.0-31.0	15.0-18.0	18.0-21.0	18.0-21.0
	Fe	≤ 1.0	≤ 1.0	Bal.	Bal.	Bal.
Max Working Temperature(ºC)		1200	1250	1150	1100	1100
Resistivity at 20ºC (μ Ω · m)		1.09	1.18	1.12	1.04	1.04
Density(g/cm3)		8.4	8.1	8.2	7.9	7.9
Thermal Conductivity (KJ/m· h· ºC)		60.3	45.2	45.2	43.8	43.8
Coefficient of Thermal Expansion(α * 10-6/ºC)		18	17	17	19	19
Melting Point(ºC)		1400	1380	1390	1390	1390
Elongation(%)		> 20	> 20	> 20	> 20	> 20
Micrographic Structure		austenite	austenite	austenite	austenite	austenite
Magnetic Property		nonmagnetic	nonmagnetic	nonmagnetic	nonmagnetic	nonmagnetic

Nichrome Wire Resistance Wire NiCr90/10 NiCr80/20 NiCr70/30 NiCr6015 Electric Resistance Wire For PTC Heater 0
