Product Details:
|
| State: | Bright Annealed | Type: | Bare |
|---|---|---|---|
| Application: | Heating | Conductor Type: | Solid |
| Conductor Material: | Copper | Insulation Material: | None |
| High Light: | Bright Annealed Manganese Copper Strip,Separator Manganese Copper Strip,Electrical Bare Copper Strip 6J12 |
||
|
6J8 |
6J12 |
6J13 |
3. Size dimension range:
|
Wire |
0.018-10mm |
|
Ribbons |
0.05*0.2-2.0*6.0mm |
|
Strip |
0.05*5.0-5.0*250mm |
4. Chemical Composition:
|
Name Code |
Main Composition (%) |
Cu |
Mn |
Ni |
|
Manganin |
6J13 |
Bal |
11-13 |
2-5 |
5. Physical Properties:
|
Name Code |
Density (g/mm2) |
Max. Working Temp.(º C ) |
|
Manganin 6J13 |
8.4 |
10-80 |
6. Mechanical Properties:
|
|
Code |
Resistivity (μ Ω. M) |
Temp. Coff. of Resistance |
Thermal EMF vs.Copper |
Elongation (%) |
Tensile Strength(Mpa) |
Melting point (°c) |
|
Manganin |
6J13 |
0.44 ±0.04 |
20 |
≤2 |
≥15 |
490--539 |
960 |
| Type | Electrical resistivity (20degreeΩ mm²/m) |
temperature coefficient of resistance (10^6/degree) |
Dens ity g/mm² |
Max. temperature (°c) |
Melting point (°c) |
| CuNi1 | 0.03 | <1000 | 8.9 | / | 1085 |
| CuNi2 | 0.05 | <1200 | 8.9 | 200 |
1090 |
| CuNi6 | 0.10 | <600 | 8.9 | 220 | 1095 |
| CuNi8 | 0.12 | <570 | 8.9 | 250 | 1097 |
| CuNi10 | 0.15 | <500 | 8.9 | 250 | 1100 |
| CuNi14 | 0.20 | <380 | 8.9 | 300 | 1115 |
| CuNi19 | 0.25 | <250 | 8.9 | 300 | 1135 |
| CuNi23 | 0.30 | <160 | 8.9 | 300 | 1150 |
| CuNi30 | 0.35 | <100 | 8.9 | 350 | 1170 |
| CuNi34 | 0.40 | -0 | 8.9 | 350 | 1180 |
| CuNi40 | 0.48 | ±40 | 8.9 | 400 | 1280 |
| CuNi44 | 0.49 | <-6 | 8.9 | 400 | 1280 |
Application of Manganin
OTHER Chemical Composition And Main Properties Of Matrial
1. What's the minimum quantity customer can order?
If we have your size in stock, we can provide any quantity you want.
If we do not have, for spool wire, we can produce 1 spool, about 2-3kg. For coil wire, 25kg.
2. How can you pay for small sample amount?
We have Western union account, wire transfer for sample amount also ok.
3. Customer do not have express account. How will us arrange the delivery for sample order?
Just need to provide your address information, we will check the express cost, you can arrange the express cost together with sample value.
4. What's our payment terms?
We can accept LC T/T payment terms, it also depending on delivery and total amount. Let's talk more in details after getting your detailed requirements.
5. Do you provide free samples?
If you want several meters and we have stock of your size, we can provide, customer need to bear the International express cost.
