IEC584 Standard Thermocouple Bare Wire 19 Strands 0.16mm NX Extension Wire

IEC584 Standard Thermocouple Bare Wire 19 Strands 0.16mm NX Extension Wire
IEC584 Standard Thermocouple Bare Wire 19 Strands 0.16mm NX Extension Wire
IEC584 Standard Thermocouple Bare Wire 19 Strands 0.16mm NX Extension Wire IEC584 Standard Thermocouple Bare Wire 19 Strands 0.16mm NX Extension Wire IEC584 Standard Thermocouple Bare Wire 19 Strands 0.16mm NX Extension Wire IEC584 Standard Thermocouple Bare Wire 19 Strands 0.16mm NX Extension Wire IEC584 Standard Thermocouple Bare Wire 19 Strands 0.16mm NX Extension Wire

Large Image :  IEC584 Standard Thermocouple Bare Wire 19 Strands 0.16mm NX Extension Wire

Product Details:
Place of Origin: China Mainland
Brand Name: Tankii
Certification: ISO9001
Model Number: NX
Payment & Shipping Terms:
Minimum Order Quantity: one spool or 17kg
Price: USD35/kg
Packaging Details: Standard exoprt package in carton box or wooden box
Delivery Time: Within 3 days after getting the payment
Payment Terms: T/T, Paypal, Western Union, MoneyGram,
Supply Ability: 1000Ton per year

IEC584 Standard Thermocouple Bare Wire 19 Strands 0.16mm NX Extension Wire

Description
Item: IEC584-3 Stranded Thermocouple Wire 19* 0.16mm Type NX Thermocouple WireIEC584 Standard Thermocouple Wire 19 Strands 0.16mm NX Extension Wire Diameter: 19* 0.16mm
MOQ: One Spool About 17kg Material: NiCrSi-NiSiMg
Surface: Bright Insulation: Bare
Wire Class: IEC 584-3 Leading Time: 1 Day
Highlight:

IEC584 Extension Thermocouple Bare Wire

,

Thermocouple Wire 19 Strands

,

Bright Thermocouple Extension Wire



IEC584 Standard Thermocouple Wire 19 Strands 0.16mm NX Extension Wire



Tankii Advantages:

Cheapest price for inventory, with IEC standard error limits, no need to worry about the quality.



Tankii stock size: N type extension grade thermocouple wire, stranded 19*0.16mm, IEC584-3



Thermocouple Grade Wire or Extension Grade Wire?

Thermocouple Wire (cable) is available in two grades; Thermocouple Grade wire & Extension Grade wire.

Typically, thermocouple grade is used to make the actual thermocouple sensor or sensing point (junction) itself , whereas thermocouple extension wire (cable) is used to connect thermocouple sensors to associated instrumentation systems, usually via an industrial terminal enclosure or thermocouple connector.

Type N thermocouple grade wire has greater emf stability and corrosion resistance than Type K, however the combination develops a lower emf output and cannot, therefore, be directly substituted.



The Type N thermocouple is composed of a nickel-14% chromium-1 1/2% silicon (+) wire versus a nickel 4 1/2% silicon-1/10% magnesium (-) wire. It was developed to be used under the same conditions as a Type K. Type N should be used in oxidizing or inert atmospheres with a service temperature range between -200°C and 1260°C (-330°F to 2300°F). The addition of silicon and chromium makes this type of thermocouple more resistant to Green-Rot and less drifting when compared to a Type K. The negative element, or NN, of a Type N thermocouple can be described by any of the following names: Nisil, nickel-silicon. The positive element, or NP, of a Type N thermocouple can be described by any of the following names: Nicrosil, nickel-chromium-silicon.





Type N Thermocouple (Nicrosil / Nisil): The Type N shares the same accuracy and temperature limits as the Type K. The type N is slightly more expensive. The type N has better repeatability between 572F to 932F (300C to 500C) compared to the type K.



Type N Temperature Range:

  • Maximum continuous operating temperature: up to 2,300F (1,260C)
  • Short term use: 2,336F (1,280C)
  • Thermocouple grade wire, -454 to 2300F (-270 to 1,260C)
  • Extension wire, 32 to 392F (0 to 200C)

Type N Accuracy (whichever is greater):
  • Standard: +/- 2.2C or +/- .75%
  • Special Limits of Error: +/- 1.1C or 0.4%

Consideration for bare wire type E thermocouple applications:

  • The type N holds up better to oxidation at high temperatures when compared to the type K.

Characteristics:

The thermocouple wires have excellent performance and are extensively used in the temperature measurement and control in different fields,

such as metallurgy, chemical industry, petroleum industry, machinery-electric industry, energy industry, agriculture and military industry.

Our products conform to the standards of IEC584 -1and IEC-2.



IEC584 Standard Thermocouple Wire 19 Strands 0.16mm NX Extension Wire




Thermocouple strips, thermocouple connectors are available.

Application Range of thermocouple wire:
1. Aerospace and Composites
2. Aluminum industry
3. Food and Pharmaceutical
4. Forgings
5. Glass, Ceramics, Clay Tiles, Bricks
6. Heat Treating
7. Petroleum, Downhole Oil & Gas
8. Sensor Manufacturing
9. Steel industry
10. Utilities Power Generation



IEC584 Standard Thermocouple Wire 19 Strands 0.16mm NX Extension Wire




N Type Thermocouple Stranded Wire's 19/0.16mm 200 ℃ and 350℃​ in Stock 66kg
Type Tensile Strength Elongation EMF
      (vs Platinum)(mV)
  N/mm² % 100℃ 200℃ 400℃
NNX 625 25 0.969 1.951 /
NPX 692 26.7 1.800 3.968 /
NN 710 27 0.987 1.989 4.066
NP 615 30 1.789 3.947 8.894

IEC584 Standard Thermocouple Bare Wire 19 Strands 0.16mm NX Extension Wire 0

Application:N type thermocouple

IEC584 Standard Thermocouple Bare Wire 19 Strands 0.16mm NX Extension Wire 1



Used for N  type extension cable:

IEC584 Standard Thermocouple Bare Wire 19 Strands 0.16mm NX Extension Wire 2



 Delivery and Packing of thermocouple wire:

1. Packaging Details : 3900~5000m per roll with plastic film wrapped and carton package.
2. Leading time : within 3 days
3. Delivery: By express / air / sea


IEC584 Standard Thermocouple Wire 19 Strands 0.16mm NX Extension Wire






Welcome to call me or email to me for more information on N type thermocouple stranded wire 19/0.16mm or solid wire 0.16mm.
