Supermalloy 1j80 Ni80Cr3Si Heating Alloy Wire Soft Magnetic Type

Supermalloy 1j80 Ni80Cr3Si Heating Alloy Wire Soft Magnetic Type
Supermalloy 1j80 Ni80Cr3Si Heating Alloy Wire Soft Magnetic Type Supermalloy 1j80 Ni80Cr3Si Heating Alloy Wire Soft Magnetic Type Supermalloy 1j80 Ni80Cr3Si Heating Alloy Wire Soft Magnetic Type Supermalloy 1j80 Ni80Cr3Si Heating Alloy Wire Soft Magnetic Type

Large Image :  Supermalloy 1j80 Ni80Cr3Si Heating Alloy Wire Soft Magnetic Type

Product Details:
Place of Origin: Shanghai, China
Brand Name: TANKII
Certification: ISO9001 SGS
Model Number: Ni80Cr3Si
Payment & Shipping Terms:
Minimum Order Quantity: 100 KG
Price: negotiable
Packaging Details: Spool + Carton + Wooned Case
Delivery Time: 7-20 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100 Tons per month

Supermalloy 1j80 Ni80Cr3Si Heating Alloy Wire Soft Magnetic Type

Description
Material: Ni80Cr3Si Diameter: 0.02 Mm Min.
Density: 8.50 G/cm3 Resisivity: 0.62
Curie Point: 330 C Shape: Wire, Rod
HS Code: 7505 2200 Elongation: 2-40%
High Light:

Ni80Cr3Si Heating Alloy Wire

,

Supermalloy Heating Alloy Wire

,

Soft Magnetic Heating Alloy Wire

Mainly used in two areas for energy conversion and information processing

In the power industry, mainly in the high magnetic field has a high magnetic induction and low core loss of the alloy. In the electronics industry, mainly at low or medium alloy having a high magnetic permeability and low coercive force. At high frequencies shall be made on a thin strip or alloy higher resistivity. Usually with sheet or strip.

Soft magnetic materials in exchange for use, due to the alternating magnetic eddy currents are induced inside the material, resulting in the loss, the smaller the resistance of the alloy, the greater the thickness, the higher the frequency of the alternating magnetic field, eddy current losses greater, magnetic reduce more. For this, the material must be made thinner sheet (tape), and the surface coated with an insulating layer, or the use of certain methods to the surface to form an oxide insulating layer, such alloys commonly used magnesium oxide electrophoresis coating.

Iron-nickel alloy mostly in the alternating magnetic field use, mainly for yoke iron, relay, Small Power Transformers and Magnetically shielded.

The following are details of our products 1J80:


Chemical composition

composition C P S Mn Si
Content(%) 0.03 0.020 0.020 0.60~1.10 1.10~1.50
composition Ni Cr Mo Cu Fe
Content(%) 79.0~81.5 2.60~3.00 - 0.2 Bal

Heat treatment system

shop sign Annealing medium heating temperature Keep the temperature time/h Cooling rate

1j80
Dry hydrogen or vacuum, pressure is not greater than 0.1 Pa Along with the furnace heating up 1100~1150ºC
3~6
In 100 ~ 200 ºC / h speed cooling to 400~500 ºC, fast to 200 ºC draw a charge

Supermalloy 1j80 Ni80Cr3Si Heating Alloy Wire Soft Magnetic Type 0

Supermalloy 1j80 Ni80Cr3Si Heating Alloy Wire Soft Magnetic Type 1
