Product Details
Place of Origin: Shanghai
Brand Name: Tankii
Certification: DIN, ASTM, JIS
Model Number: N40
Payment & Shipping Terms
Minimum Order Quantity: 20kg
Packaging Details: spool ,coil, or as clients' requirement
Delivery Time: 25days
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 1000T/month
Type: |
K |
Condition: |
New |
Weight: |
Based |
Power Source: |
Electric |
After-sales Service Provided: |
No Overseas Service Provided |
Voltage: |
220v |
Warranty: |
1 Year |
Power(w): |
Adjustable |
Material: |
Sic |
MOQ: |
20kg |
Type: |
K |
Condition: |
New |
Weight: |
Based |
Power Source: |
Electric |
After-sales Service Provided: |
No Overseas Service Provided |
Voltage: |
220v |
Warranty: |
1 Year |
Power(w): |
Adjustable |
Material: |
Sic |
MOQ: |
20kg |
Heating Element Wire (N40) for Resistor
Product: Heating Element Wire/Nichrome Wire/NiCrFe Alloy Wire
Grade: N40(35-20 Ni-Cr), Ni35Cr20Fe
Chemical Composition: Nickel 35%, Chrome 20%, Fe Bal.
Resistivity: 1.04 ohm mm2/m
Condition: Bright, Annealed, Soft
Diameter: 0.018~30mm
Producer: Shanghai Tankii Alloy Material Co., Ltd.
The nichrome wire is usually used in tube heater, hair dryer, electric iron, soldering iron, rice cooker, oven, furnace, heating element, resistance element, etc.
If you have any requirement, pls be free to tell us.
MOST PROFESSIONAL ALLOY PRODUCER IN CHINA
| Chemical Composition and Main Properties of Nichrome | ||||||
| Properties Grade | NiCr 80/20 | NiCr 70/30 | NiCr 60/15 | NiCr 35/20 | NiCr 30/20 | |
| Main Chemical Composition | Ni | Balance | Balance | 55.0-61.0 | 34.0-37.0 | 30.0-34.0 |
| Cr | 20.0-23.0 | 28.0-31.0 | 15.0-18.0 | 18.0-21.0 | 18.0-21.0 | |
| Fe | ≤1.0 | ≤1.0 | Balance | Balance | Balance | |
| Max Continuous Service Temperature(oC) | 1200 | 1250 | 1150 | 1100 | 1100 | |
| Resisivity 20oC (Ωmm2/m) | 1.09 | 1.18 | 1.12 | 1.04 | 1.04 | |
| Density (g/cm3) | 8.4 | 8.1 | 8.2 | 7.9 | 7.9 | |
| Thermal Conductivity(KJ/m@h@oC) | 60.3 | 45.2 | 45.2 | 43.8 | 43.8 | |
| Coefficient of Thermal Expansion(α*10-6/oC) | 18 | 17 | 17 | 19 | 19 | |
| Melting Point( oC) | 1400 | 1380 | 1390 | 1390 | 1390 | |
| Elongation(%) | >20 | >20 | >20 | >20 | >20 | |
| Micrographic Structure | austenite | austenite | austenite | austenite | austenite | |
| Magnetic Property | nonmagnetic | nonmagnetic | nonmagnetic | Weak magnetic | Weak magnetic | |
Shanghai Tankii Alloy Material Co., Ltd. Focus on the production of resistance alloy(nichrome Alloy, FeCrAl Alloy, copper nickel alloy, thermocouple wire, precision alloy and thermal spray alloy in the form of wire, sheet, tape, strip, rod and plate. We've already got ISO9001 quality system certificate and approval of ISO14001 environmental protection system. We own a complete set of advanced production flow of refining, cold reduction, drawing and heat treating etc. We also proudly have independent R&D capacity.
Shanghai Tankii Alloy Material Co., Ltd has accumulated lots of experiences over 35 years in this field. During these years, more than 60 management elites and high science and technology talents were employed. They participated in every walk of the company life, which make our company keep blooming and invincible in the competitive market. Based on the principle of "first quality, sincere service", our managing ideology is pursuing technology innovation and creating the top brand in the alloy field. We persist in Quality - the foundation of the survival. It is our forever ideology to serve you with full heart and soul. We committed to provide customers all over the world with high-quality, competitive products and perfect service.
Our products, such us nichrome alloy, precision alloy, thermocouple wire, fecral alloy, copper nickel alloy, thermal spray alloy have been exported to over 60 countries in the world. We are willing to establish strong and long-time partnership with our customers. Most complete range of products dedicated to Resistance, Thermocouple and Furnace manufacturers Quality with end to end production control Technical support and Customer Service.
