1400W Injection Molding Heating Element 300MM Length

Product Details

Place of Origin: Shanghai,China

Brand Name: TANKII

Certification: JIS,GB,DIN,BS,ASTM,AISI,CTI

Model Number: bayonent heating elements

Payment & Shipping Terms

Minimum Order Quantity: 100pcs

Price: $10~$25/KG

Packaging Details: on spool,paper box,wooden case/pallet,in coil vaccum packaging export carton

Delivery Time: 30days

Payment Terms: L/C, D/P, T/T, Western Union, MoneyGram

Supply Ability: 600pcs per moth

Get Best Price
Contact Now
Specifications
Highlight:

1400W Injection Molding Heating Element

,

300MM Furnace Heating Element

,

Bayonet Injection Molding Heating Element

Port:
Shanghai,China
Brand:
Tankii
Local Service Location:
None
Condition:
New
Power Source:
Electric
Weight:
Final Dimension
Cetification:
JIS,GB,DIN,BS,ASTM,AISI,CTI
After -sales Service:
Online Support
Key Selling Point:
Fast Heater
Warranty:
1year
Power:
200~1400W
After Warranty Service:
Online Support
Type:
Air Heater
Dimension(L*W*H):
Customization
Voltage:
220V, 220/230V
Working Temperature:
200 - 700 ℃
Marketing Type:
New Product
Core Components:
Resistance Wire
Length:
30~300MM
MOQ:
100PCS
Port:
Shanghai,China
Brand:
Tankii
Local Service Location:
None
Condition:
New
Power Source:
Electric
Weight:
Final Dimension
Cetification:
JIS,GB,DIN,BS,ASTM,AISI,CTI
After -sales Service:
Online Support
Key Selling Point:
Fast Heater
Warranty:
1year
Power:
200~1400W
After Warranty Service:
Online Support
Type:
Air Heater
Dimension(L*W*H):
Customization
Voltage:
220V, 220/230V
Working Temperature:
200 - 700 ℃
Marketing Type:
New Product
Core Components:
Resistance Wire
Length:
30~300MM
MOQ:
100PCS
Description
1400W Injection Molding Heating Element 300MM Length


Bayonet heating elements are a reliable and efficient solution for electric heating applications.


These elements are custom designed for the voltage and input (KW) required to satisfy the application. There are a wide variety of configurations available in either large or small profiles. Mounting can be vertical or horizontal, with heat distribution selectively located according to the required process. Bayonet elements are designed with ribbon alloy and watt densities for furnace temperatures up to 1800°F (980°C).
Advantages

· Element replacement is fast and easy. Element changes can be made while the furnace is hot, following all plant safety procedures. All electrical and replacement connections can be made outside the furnace. No field welds are necessary; simple nut and bolt connections allow for quick replacements. In some cases, replacement can be completed in as little as 30 minutes depending on the size of the element complexity and accessibility.

· Each element is custom designed for peak energy efficiency. Furnace temperature, voltage, desired wattage and material selection are all used in the design process.

· Inspection of the elements can be performed outside the furnace.

· When necessary, as with a reducing atmosphere, bayonets can be operated in sealed alloy tubes.

· Repairing a SECO/WARWICK bayonet element may be an economical alternative. Consult us for current pricing and repair options.
Bayonet heating element uses range from heat treat furnaces and die casting machines to molten salt baths and incinerators. They are also useful in converting gas-fired furnaces to electric heating.

  • Broad power and temperature range
  • Far higher power output than conventional heating element
  • Excellent high temperature performance
  • Long service life at all temperatures

1400W Injection Molding Heating Element 300MM Length 0

Bayonet Heating Elements

ELEMENT
O.D. (in.)
(NiCr ALLOY)
Max Kilowatts/Linear FootELEMENT
O.D. (in.)
(FeCrAl ALLOY)
UP TO 1000°F1000°F To 1350°F1350°F To 1700°F1700°F TO 2050°F2050°F TO 2250°F
2 3/42.382.201.881.56
   2.282.101.872 5/8
3 3/83.803.472.962.44
   3.833.483.123 1/8
3 3/44.574.143.482.94
   3.833.483.124 5/16
4 3/46.465.834.994.14
   3.835.404.904 7/8
5 3/47.266.595.684.68
   6.435.845.286
6 1/88.127.366.325.27
   7.286.606.006 3/4
7 3/49.768.867.626.36




Company Profile

Shanghai Tankii Alloy Material Co., Ltd. Focus on the production of resistance alloy(nichrome Alloy, FeCrAl Alloy, copper nickel alloy, thermocouple wire, precision alloy and thermal spray alloy in the form of wire, sheet, tape, strip, rod and plate. We've already got ISO9001 quality system certificate and approval of ISO14001 environmental protection system. We own a complete set of advanced production flow of refining, cold reduction, drawing and heat treating etc. We also proudly have independent R&D capacity.
Shanghai Tankii Alloy Material Co., Ltd has accumulated lots of experiences over 35 years in this field. During these years, more than 60 management elites and high science and technology talents were employed. They participated in every walk of the company life, which make our company keep blooming and invincible in the competitive market. Based on the principle of "first quality, sincere service", our managing ideology is pursuing technology innovation and creating the top brand in the alloy field. We persist in Quality - the foundation of the survival. It is our forever ideology to serve you with full heart and soul. We committed to provide customers all over the world with high-quality, competitive products and perfect service.
Our products, such us nichrome alloy, precision alloy, thermocouple wire, fecral alloy, copper nickel alloy, thermal spray alloy have been exported to over 60 countries in the world. We are willing to establish strong and long-time partnership with our customers. Most complete range of products dedicated to Resistance, Thermocouple and Furnace manufacturers Quality with end to end production control Technical support and Customer Service.
