Product Details
Place of Origin: Shanghai
Brand Name: Tankii
Certification: DIN, ASTM, JIS
Model Number: 4J29
Payment & Shipping Terms
Minimum Order Quantity: 20kg
Packaging Details: spool ,coil, or as clients' requirement
Delivery Time: 25days
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 1000T/month
Material: |
Precision Alloy |
Shape: |
Wire |
Application: |
Industry |
Dimensions: |
Customized |
Standard: |
GB |
Color: |
Nature |
Size: |
Clients Requirement |
Process: |
Cnc Machinng |
Condition: |
Soft And Hardc |
Surface: |
Bright |
MOQ: |
20kgs |
Product Name: |
Kovar Expansion Precision Alloy Ni29Co18 Uns K94610 (4J29) |
Material: |
Precision Alloy |
Shape: |
Wire |
Application: |
Industry |
Dimensions: |
Customized |
Standard: |
GB |
Color: |
Nature |
Size: |
Clients Requirement |
Process: |
Cnc Machinng |
Condition: |
Soft And Hardc |
Surface: |
Bright |
MOQ: |
20kgs |
Product Name: |
Kovar Expansion Precision Alloy Ni29Co18 Uns K94610 (4J29) |
Product Description
OhmAlloy-4J29 (Expansion alloy)
4J29(China); 29H, 29H-B, Techallony(Russia); Kovar, Rodar, Glasseal 29-17(United States); Nilo K, Telcaseal(Great Britain); KV-1, KV-2, KV-3(Japan); Dilver P0, Dilver P1(France); Vacon 12, Silvar 48(Germany).
4J29 expansion alloy, also known as Kovar alloy, is a Nickel Iron alloy with 29% Nickel, 17% Cobalt and the remaining balance is Iron. The expansion characteristics of Kovar match both borosilicate (or Pyrex) glasses and alumina ceramics, making it one of the most popular controlled expansion alloys for hermetic sealing applications. Kovar is produced to ensure good properties for machining and deep drawing, and is a porosity free product. You'll find Kovar in applications such as power tubes, microwave tubes, transistors, diodes, hybrid packages, and other kinds of scientific instruments.
Application:
The alloy is widely used as glass sealing for electronic vacuum devices, such as launching tube, oscillating tube, ignitron, magnetron, transistor, sealing plug, relay, leading wire of integrated circuit, chassis, shell, scaffold and so on.
Physical Constants:
Density:8.17g/cm³
Specific gravity (g/cm3): 8.36
Melting point(ºC): 1450
Melting heat(calorie/g): 64
Vapour pressure (μ M): 1× 10-6 (1000ºC)
Specific heat(calorie/g/ºC): 0.105 (0ºC)
0.155 (430ºC)
Heat conductivity(calorie/cm· Sec. · ºC): 0.0395 (30ºC)
0.0485(300ºC)
Curie temperature (ºC): 435
γ α Phase-transition temperature(ºC): Below -80
Electrical performance:
Resistivity (μ Ω -mm): 49 (25ºC)
Shanghai Tankii Alloy Material Co., Ltd. Focus on the production of resistance alloy(nichrome Alloy, FeCrAl Alloy, copper nickel alloy, thermocouple wire, precision alloy and thermal spray alloy in the form of wire, sheet, tape, strip, rod and plate. We've already got ISO9001 quality system certificate and approval of ISO14001 environmental protection system. We own a complete set of advanced production flow of refining, cold reduction, drawing and heat treating etc. We also proudly have independent R&D capacity.
Shanghai Tankii Alloy Material Co., Ltd has accumulated lots of experiences over 35 years in this field. During these years, more than 60 management elites and high science and technology talents were employed. They participated in every walk of the company life, which make our company keep blooming and invincible in the competitive market. Based on the principle of "first quality, sincere service", our managing ideology is pursuing technology innovation and creating the top brand in the alloy field. We persist in Quality - the foundation of the survival. It is our forever ideology to serve you with full heart and soul. We committed to provide customers all over the world with high-quality, competitive products and perfect service.
Our products, such us nichrome alloy, precision alloy, thermocouple wire, fecral alloy, copper nickel alloy, thermal spray alloy have been exported to over 60 countries in the world. We are willing to establish strong and long-time partnership with our customers. Most complete range of products dedicated to Resistance, Thermocouple and Furnace manufacturers Quality with end to end production control Technical support and Customer Service.
