Product Details
Place of Origin: Shanghai,China
Brand Name: TANKII
Certification: BS,ASTM,AISI,CTI
Model Number: TK1
Payment & Shipping Terms
Minimum Order Quantity: 100KG
Packaging Details: on spool,paper box,wooden case/pallet,in coil
Delivery Time: 30days
Payment Terms: L/C, D/P, T/T, Western Union
Supply Ability: 600T per moth
Port: |
Shangahi,China |
Brand: |
Tankii |
Cr: |
22.0-26.0 |
Al: |
5.0-7.0 |
Re: |
0.04-1.0 |
Fe: |
Bal |
Max Continuous Operating Temperature(℃): |
1400 |
Resisitivity20℃(Ωmm2/m): |
1.48 |
Density(g/cm³): |
7.1 |
Thermal Conductivity At 20℃,w/(m·k): |
0.49 |
Linear Expansion Coefficient(x10﹣6/℃)20﹣1000℃: |
16 |
Approximate Melting Point(℃): |
1520 |
Tensile Strength(N/m㎡): |
680-830 |
Elongation%: |
>10 |
Section Variation Shrink Rate(%): |
65-75 |
Repeatedly Bend Frequency(F/R): |
>5 |
Hardness: |
200-260 |
Micrographic Structure: |
Ferrite |
Magnetic Property: |
Magnetic |
Fast Life(h/℃): |
≧81/1350 |
MOQ: |
100KG |
Port: |
Shangahi,China |
Brand: |
Tankii |
Cr: |
22.0-26.0 |
Al: |
5.0-7.0 |
Re: |
0.04-1.0 |
Fe: |
Bal |
Max Continuous Operating Temperature(℃): |
1400 |
Resisitivity20℃(Ωmm2/m): |
1.48 |
Density(g/cm³): |
7.1 |
Thermal Conductivity At 20℃,w/(m·k): |
0.49 |
Linear Expansion Coefficient(x10﹣6/℃)20﹣1000℃: |
16 |
Approximate Melting Point(℃): |
1520 |
Tensile Strength(N/m㎡): |
680-830 |
Elongation%: |
>10 |
Section Variation Shrink Rate(%): |
65-75 |
Repeatedly Bend Frequency(F/R): |
>5 |
Hardness: |
200-260 |
Micrographic Structure: |
Ferrite |
Magnetic Property: |
Magnetic |
Fast Life(h/℃): |
≧81/1350 |
MOQ: |
100KG |
FeCrAl Alloy is high resistance and electrical heating alloy.FeCrAl alloy can reach process temperatures of 2192 to 2282℉,corresponding to a resistance temperature of 2372℉.
In order to improve anti-oxidation ability and increase working life,we usually put addition of rare earths in the alloy,such as La+Ce,Yttrium,Hafnium,Zirconium,etc.
It is normally used in electrial furnace,glass top hobs,quartz tube heaters,resistors,catalytic converter,heating elements and etc.
TK1 large-sized cold-drawn wire products can be used for high-temperature resistance furnace. Practice has proved that: The product process is stable, integrated performance is good. Has good high temperature oxidation resistance and longer service life; Excellent winding properties at room temperature processing, ease of processing molding; Little rebound resilience and so on. Processing performance is better than 0Cr27Al7Mo2, high temperature performance is better than 0Cr21Al6Nb; Operating temperature can reach 1425 ºC.
Model No. | TK1 |
transport package | waterproof film,weave bag,pallet |
rated voltage | 220v/380 |
Hardness | 200-260 |
approximate melting point(℃) | 1520 |
Micrographic structure | ferrite |
tensile strength(N/m㎡) | 680-830 |
MOQ | 100KG |
