Product Details
Place of Origin: Shanghai,China
Brand Name: TANKII
Certification: BS,ASTM,AISI,CTI
Model Number: 1Cr13Al4
Payment & Shipping Terms
Minimum Order Quantity: 100KG
Packaging Details: on spool,paper box,wooden case/pallet,in coil
Delivery Time: 30days
Payment Terms: L/C, D/P, T/T, Western Union
Supply Ability: 600T per moth
Port: |
Shangahi,China |
Brand: |
Tankii |
Cr: |
12.0-15.0 |
Al: |
4.0-6.0 |
Re: |
Opportune |
Fe: |
Bal |
Maxcontinuous Operating Temperature(℃): |
650 |
Resisitivity20℃(Ωmm2/m): |
1.25 |
Density(g/cm³): |
7.4 |
Thermal Conductivity At 20℃,w/(m·k): |
0.49 |
Linear Expansion Coefficient(x10﹣6/℃)20﹣1000℃: |
15.4 |
Approximate Melting Point(℃): |
1450 |
Tensile Strength(N/m㎡): |
580-680 |
Elongation%: |
>16 |
Section Variation Shrink Rate(%): |
65-75 |
Repeatedly Bend Frequency(F/R): |
>5 |
Hardness: |
(H.B) |
Micrographic Structure: |
Ferrite |
Magnetic Property: |
Magnetic |
Fast Life(h/℃): |
No |
MOQ: |
100kg |
Port: |
Shangahi,China |
Brand: |
Tankii |
Cr: |
12.0-15.0 |
Al: |
4.0-6.0 |
Re: |
Opportune |
Fe: |
Bal |
Maxcontinuous Operating Temperature(℃): |
650 |
Resisitivity20℃(Ωmm2/m): |
1.25 |
Density(g/cm³): |
7.4 |
Thermal Conductivity At 20℃,w/(m·k): |
0.49 |
Linear Expansion Coefficient(x10﹣6/℃)20﹣1000℃: |
15.4 |
Approximate Melting Point(℃): |
1450 |
Tensile Strength(N/m㎡): |
580-680 |
Elongation%: |
>16 |
Section Variation Shrink Rate(%): |
65-75 |
Repeatedly Bend Frequency(F/R): |
>5 |
Hardness: |
(H.B) |
Micrographic Structure: |
Ferrite |
Magnetic Property: |
Magnetic |
Fast Life(h/℃): |
No |
MOQ: |
100kg |
FeCrAl Alloy is high resistance and electrical heating alloy.FeCrAl alloy can reach process temperatures of 2192 to 2282℉,corresponding to a resistance temperature of 2372℉.
In order to improve anti-oxidation ability and increase working life,we usually put addition of rare earths in the alloy,such as La+Ce,Yttrium,Hafnium,Zirconium,etc.
It is normally used in electrial furnace,glass top hobs,quartz tube heaters,resistors,catalytic converter,heating elements and etc.
1Cr13Al4 is a iron-chromium-aluminium alloy (FeCrAl alloy) characterized by Stable performance,
Anti-oxidation,Corrosion resistance,High temperature stability,Excellent coil-forming ability,Uniform and beautiful surface condition without spots.It is suitable for use at temperatures up to 1450°C.
|
Model NO.
|
1Cr13Al4 |
| Cetificate | BS,ASTM,AISI,CTI |
| working temperature | 1450 |
| surface treatment | Bright |
| specification | heating system |
| trademark | tankii |
| application | heating system |
| transport package | spool/coil+wooden case |
| specification | 0.02-10mm |
| MOQ | 100KG |
