Constantan T Type Enamelled Thermocouple Bare Wire For Medical Measurement

Constantan T Type Enamelled Thermocouple Bare Wire For Medical Measurement
Constantan T Type Enamelled Thermocouple Bare Wire For Medical Measurement Constantan T Type Enamelled Thermocouple Bare Wire For Medical Measurement Constantan T Type Enamelled Thermocouple Bare Wire For Medical Measurement Constantan T Type Enamelled Thermocouple Bare Wire For Medical Measurement

Large Image :  Constantan T Type Enamelled Thermocouple Bare Wire For Medical Measurement

Product Details:
Place of Origin: China Mainland
Brand Name: Tankii
Certification: ISO9001
Model Number: TN -constantan
Payment & Shipping Terms:
Minimum Order Quantity: 10kg
Price: Negotiation
Packaging Details: Standard exoprt package in carton box or wooden box
Delivery Time: 5-7 days after getting the payment
Payment Terms: T/T, Paypal, Western Union, MoneyGram,
Supply Ability: 1000Ton per year

Constantan T Type Enamelled Thermocouple Bare Wire For Medical Measurement

Description
Material: Constantan Surface: Enamelled By Polyester
Diameter: ≥ 0.1mm Wire Type: Solid Wire
Wire Class: I , II, Leading Time: 5~20 Days After Getting The Payment
Item: T Type Enamelled Thermocouple Wire 0.1mm Copper And Constantan Wire Used In Medical Measurement
High Light:

thermocouple lead wire

,

high temperature thermocouple wire



T Type Enamelled Thermocouple Wire 0.1mm Copper And Constantan Wire Used In Medical Measurement



Quick Description

A typical thermocouple construction consists of a pair of dissimilar metals that are electrically joined together at the sensing point and connected to a voltage measuring instrument at the other end. When one junction is hotter than the other, a thermal “electromotive” force (in millivolts) is produced that is roughly proportional to the difference in temperature between the hot and cold junctions.



The thermocouple wires have excellent performance and are extensively used in the temperature measurement and control in different fields, such as metallurgy, chemical industry, petroleum industry, machinery-electric industry, energy industry, agriculture and military industry.



Our products conform to the standards of IEC584 -1and IEC-2.

Thermocouple strips, thermocouple connectors and cables are available if you need.

T Type Enamelled Thermocouple Wire 0.1mm Copper And Constantan Wire Used In Medical Measurement

Application Range of thermocouple wire:

1. Aerospace and Composites
2. Aluminum industry
3. Food and Pharmaceutical
4. Forgings
5. Glass, Ceramics, Clay Tiles, Bricks
6. Heat Treating
7. Petroleum, Downhole Oil & Gas
8. Sensor Manufacturing
9. Steel industry
10. Utilities Power Generation

T Type Enamelled Thermocouple Wire 0.1mm Copper And Constantan Wire Used In Medical Measurement
Constantan T Type Enamelled Thermocouple Bare Wire For Medical Measurement 0



Thermocouple Type and Temperature Range

Thermocouple type and index



Measurement Range

Type



Index





PtRh30-PtRh6

B 600~1700



PtRh13-Pt

R 0~1600



PtRh10-Pt

S 0~1600



NiCr-NiSi

K -200~1300



NiCr-CuNi (constantan)

E -200~900



Fe-CuNi (constantan)

J -40~750



Cu-CuNi (constantan)

T -200~350



NiCrSi-NiSi

N -200~1300


The allowable grade and Tolerance are obtained at 0℃

Thermocouple

Type

Grade

Temperature range

Allowable Tolerance /℃
Type B 600~1700 ±0.25% t
600~800 ±4
800~1700 ±0.5%t
Type R(S) 0~1100 ±1
1100~1600 ±[1+(t-1100) ×0.3%]
0~600 ±1.5
600~1600 ±0.25% t
Type K and Type N -40~1100 ±1.5℃ or ±0.4%t
-40~1300 ±2.5℃ or ±0.75%t
-200~40 ±2.5℃ or ±1.5%t
Type E -40~1100 ±1.5℃ or ±0.4%t
-40~1300 ±2.5℃ or ±0.75%t
-200~40 ±2.5℃ or ±1.5%t
Type J -40~750 ±1.5℃ or ±0.4%t
-40~750 ±2.5℃ or ±0.75%t
Type T -40~350 ±0.5℃ or ±0.4%t
-40~350 ±1.0℃ or ±0.75%t
-200~40 ±1.0℃ or ±1.5%t





 Delivery and Packing of thermocouple wire:

1. Packaging Details : On spool, in carton or wooden case  as per the qty

2. Leading time : 5 - 20 days, as the order quantity of thermocouple wire.

3. Delivery: By express, air, sea as per thermocouple wire qty



Welcome to call me or email to me for more information on T type thermocouple wire enamelled wire.
