Product Details:
|
| Packing: | Case | Craft: | Cold Rolled |
|---|---|---|---|
| Characteristics: | High Resistivity, Good Oxidation Resistance | Sample: | Free |
| Shape: | Strip/Wire/Ribbon/Pipe/Sheet/Bar/Foil | Surface: | Bright |
| The Highest Use Temperature: | 650c | Density: | 7.4 |
| Resisivity: | 1.25 | ||
| High Light: | high resistance wire,nickel alloys |
||
1. Detailed description:
Resistance alloy cables are used for heating resistance elements. Haide electrothermal alloy produced high strength for high purity, low impurity resistivity stability, small temperature coefficient, surface body in good condition, and the highest intensity and high temperature and good processing performance can weld steels of the nature of the varieties of the complete specifications. Widely used in metallurgy, industrial kitchens, household appliances, machinery and electronic manufacturing industries to make heating resistance materials.
1. FeCrAl alloys of electric heating resistance with high electrical resistivity, small coefficient of resistance temperature, high operational temperature, good resistance to corrosion under high temperature and especially suitable for use in the atmosphere with sulfur and sulfur, more price Low, it is normally used in electric industrial furnaces, household appliances, remote infrared device ideal heating material.
FeCrAl type: 1Cr13AI4, 0Cr21AI4, 0Cr21AI6, 0Cr25AI5, 0Cr21AI6 Nb, 0Cr27AI7Mo2, etc. Serious electric flat belt, electric flat wire
2. Nickel-chromium alloy with electrothermal iron resistance and high resistivity, good body sexual surface. At high temperature and high intensity, and good performance and processing can weld nature widely used in matellurgy, electrical, mechanical components and electrical manufacturing industries to make heating resistance materials. Ni-Cr type: Cr20Ni80, Cr15Ni60, Cr20Ni35, Cr20Ni30 , Cr25Ni20, etc. Serious electric flat belt, flat electric wires.
The size of the product:
The diameter of cable .0.05-12mm, Thickness of flat band 0.03-5mm, width of flat tape 0.2-500mm.
2. Characteristics and properties:
1) The highest working temperature up to 1250 degrees.
2) Longer working life, and better technical properties
3) Top surface of the load.
4) Greater resistivity.
5) Lower density.
6) free of scrap rust
SHANGHAI TANKII ALLOY MATERIAL CO.,LTD IS THE BEST PRODUCER IN THE WORLD.
| Chemical Composition and Main Property of Fe-Cr-Al Resistance Alloy | ||||||||
| Properties Grade | 1Cr13Al4 | 0Cr25Al5 | 0Cr21Al6 | 0Cr23Al5 | 0Cr21Al4 | 0Cr21Al6Nb | 0Cr27Al7Mo2 | |
| Main Chemical Composition (%) |
Cr | 12.0-15.0 | 23.0-26.0 | 19.0-22.0 | 22.5-24.5 | 18.0-21.0 | 21.0-23.0 | 26.5-27.8 |
| Al | 4.0-6.0 | 4.5-6.5 | 5.0-7.0 | 4.2-5.0 | 3.0-4.2 | 5.0-7.0 | 6.0-7.0 | |
| Re | opportune | opportune | opportune | opportune | opportune | opportune | opportune | |
| Fe | Bal. | Bal. | Bal. | Bal. | Bal. | Bal. | Bal. | |
| Nb0.5 | Mo1.8-2.2 | |||||||
| Max Continuous Service Temperature(oC) | 950 | 1250 | 1250 | 1250 | 1100 | 1350 | 1400 | |
| Resisivity 20oC (Ωmm2/m) | 1.25 ±0.08 |
1.42 ±0.06 |
1.42 ±0.07 |
1.35 ±0.07 |
1.23 ±0.07 |
1.45 ±0.07 |
1.53 ±0.07 |
|
| Density(g/cm3) | 7.4 | 7.1 | 7.16 | 7.25 | 7.35 | 7.1 | 7.1 | |
| Thermal Conductivity | 52.7 | 46.1 | 63.2 | 60.2 | 46.9 | 46.1 | 45.2 | |
| (KJ/m@h@oC) | ||||||||
| Coefficient of Thermal Expansion(α×10-6/oC) | 15.4 | 16 | 14.7 | 15 | 13.5 | 16 | 16 | |
| Approximate Melting Point( oC) | 1450 | 1500 | 1500 | 1500 | 1500 | 1510 | 1520 | |
| Tensile Strength(N/mm2) | 580-680 | 630-780 | 630-780 | 630-780 | 600-700 | 650-800 | 680-830 | |
| Elongation(%) | >16 | >12 | >12 | >12 | >12 | >12 | >10 | |
| Section Variation | 65-75 | 60-75 | 65-75 | 65-75 | 65-75 | 65-75 | 65-75 | |
| Shrink Rate (%) | ||||||||
| Repeatedly Bend Frequency(F/R) | >5 | >5 | >5 | >5 | >5 | >5 | >5 | |
| Hardness (H.B.) | 200-260 | 200-260 | 200-260 | 200-260 | 200-260 | 200-260 | 200-260 | |
| Continuous Service Time | no | ≥80/1300 | ≥80/1300 | ≥80/1300 | ≥80/1250 | ≥50/1350 | ≥50/1350 | |
| Micrographic Structure | Ferrite | Ferrite | Ferrite | Ferrite | Ferrite | Ferrite | Ferrite | |
| Magnetic Property | Magnetic | Magnetic | Magnetic | Magnetic | Magnetic | Magnetic | Magnetic | |
