Fchw-1 Fchw-2 Fecral Alloy Heating Element Wire With Personalized Packing

Certification
China Shanghai Tankii Alloy Material Co.,Ltd certification
China Shanghai Tankii Alloy Material Co.,Ltd certification
Customer Reviews
Perfect cables and bare wires. During the COVID-19 period, you sent us masks as gift, again, thanks a lot for your friendship during these difficult times!

—— Lorenzo Crisetig

Good supplier of Thermocouple wire, short leadting time and fast shipment. It's worth cooperating with Tankii alloy.

—— Vand***

Qualified products. We may place more orders to TANKII

—— Edward***

I bought thermocouple wire from Selina, she is a very responsible lady,Tankii's products quality is pretty good.

—— Jain**

Quick response with professional service on alloy wires. I trust tankii alloy.

—— Crist***

I'm Online Chat Now

Fchw-1 Fchw-2 Fecral Alloy Heating Element Wire With Personalized Packing

Fchw-1 Fchw-2 Fecral Alloy Heating Element Wire With Personalized Packing
Fchw-1 Fchw-2 Fecral Alloy Heating Element Wire With Personalized Packing Fchw-1 Fchw-2 Fecral Alloy Heating Element Wire With Personalized Packing Fchw-1 Fchw-2 Fecral Alloy Heating Element Wire With Personalized Packing Fchw-1 Fchw-2 Fecral Alloy Heating Element Wire With Personalized Packing

Large Image :  Fchw-1 Fchw-2 Fecral Alloy Heating Element Wire With Personalized Packing

Product Details:
Place of Origin: Shanghai, China
Brand Name: TANKII
Certification: ISO9001:2008
Model Number: 0Cr25Al5
Payment & Shipping Terms:
Minimum Order Quantity: 20kg
Price: To negotiate
Packaging Details: Spool, Coil, Carton, Wooden case with plastic film according to per client's requirements
Delivery Time: 7-15 DAYS
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 1000+TON+YEAR

Fchw-1 Fchw-2 Fecral Alloy Heating Element Wire With Personalized Packing

Description
Chemical Composition: Ferro Bal. Chrome 20 Aluminum 6 Type: Round Wire/ Ribbon/ Strip/ Foil
Conductor Type: Solid Surface: Smooth, Bright, Annealed
Material: FeCrAl Shipment: Air, Sea, Express
High Light:

nichrome resistance wire

,

nickel alloys

Fchw-1 Fchw-2 Fecral Alloy Heating Element Wire With Personalized Packing


General Description

FeCrAl Electrictrical Resistance Heating alloys with high electrical resistivity, temperature coefficient of resistance is small, high operating temperature. good corrosion resistance under high temperature, and particularly suitable for use in a gas containing sulfur and sulfides, low price, it is widely used in industrial electric furnace, household appliances, far infrared device ideal heating material.
FeCrAl type:1Cr13AI4, 0Cr21AI4, 0Cr21AI6, 0Cr25AI5, 0Cr21AI6 Nb, 0Cr27AI7Mo2 etc.Series electric flat belt, electric fire wire
.



FCHW-1 and FCHW-2 large-sized cold-drawn wire products can be used for high-temperature resistance furnace. Practice has
proved that: the product process is stable, integrated performance is good. Has good high temperature oxidation
resistance and longer service life; excellent winding properties at room temperature processing, ease of
processing molding; little rebound resilience and so on. Processing performance is very good; operating
temperature can reach 1400 .
Main specifications and uses:
Conventional Product specifications: 0.5 ~ 10 mm
Uses: mainly used in powder metallurgy furnace, diffusion furnace, radiant tube heater and all kinds of high-temperature furnace heating body.



Product forms and size range
Round wire
0.010-12 mm (0.00039-0.472 inch) other sizes are available on request.

Ribbon (flat wire)
Thickness: 0.023-0.8 mm (0.0009-0.031 inch)
Width: 0.038-4 mm (0.0015-0.157 inch)
Width/thickness ratio max 60, depending on alloy and tolerance
Other sizes are available on request.

Resistance electric heating wire has strong antioxidant properties, but a variety of gases in furnaces such as air, carbon, sulfur, hydrogen and nitrogen atmosphere, still have a certain impact on it.

Although these heating wires all have had antioxidant treatment, the transportation, winding, installation and other process will cause damage to a certain extent and reduce its service life.

In order to extend the service life, customers need to do pre oxidation treatment before using. The method is to heat alloy elements which have installed completely in the dry air to the temperature (lower 100-200C than its maximum using temperature), heat preservation for 5 to 10 hours, then cooling slowly with furnace.






Properties Grade


Alchrome 875
Cr Al Re Fe
25.0 6.0 Suitable Balance
Max Continuous ServiceTemperature(ºC)

Diameter 1.0-3.0 Diameter large than 3.0,
1225-1350ºC 1400ºC
Resisivity 20ºC (Omm2/m) 1.45
Density(g/cm 3 ) 7.1
Approximate Melting Point( ºC) 1500
Elongation (%) 16-33
Repeatedly Bend Frequency(F/R)20ºC 7-12
Continuous Service Time under 1350ºC More than 60 hours
Micrographic Structure Ferrite

The relationship between the maximum operating temperature and the furnace atmosphere





Furnace atmosphere Dry Air Humid Air hydrogen-argon gas Argon Decomposition ammonia gas
Temp( ºC) 1400 1200 1400 950 1200




Fchw-1 Fchw-2 Fecral Alloy Heating Element Wire With Personalized Packing 0Fchw-1 Fchw-2 Fecral Alloy Heating Element Wire With Personalized Packing 1
