H41XT Elastic alloy strip Elinvar strip Ni42CrTi Used for elastic sensitive elements

H41XT Elastic alloy strip Elinvar strip Ni42CrTi Used for elastic sensitive elements
H41XT Elastic alloy strip Elinvar strip Ni42CrTi Used for elastic sensitive elements H41XT Elastic alloy strip Elinvar strip Ni42CrTi Used for elastic sensitive elements H41XT Elastic alloy strip Elinvar strip Ni42CrTi Used for elastic sensitive elements

Large Image :  H41XT Elastic alloy strip Elinvar strip Ni42CrTi Used for elastic sensitive elements

Product Details:
Place of Origin: SHANGHAI
Brand Name: TANKII
Certification: ISO9001
Model Number: H41XT
Payment & Shipping Terms:
Minimum Order Quantity: 50kg
Price: usd + 26~27 + kg
Packaging Details: Wooden cases or cartons
Delivery Time: 10~15day
Payment Terms: L/C, T/T, D/A
Supply Ability: 20 + Ton + month

H41XT Elastic alloy strip Elinvar strip Ni42CrTi Used for elastic sensitive elements

Description
Chemical Composition: Ni42CrTi Density: 8.1g/cm3
Melting Point: 1460 C Thermal Conductivity: 12.98 W/(m.C)
Use: Elastic Sensitive Elements Packaging: Wooden Cases Or Cartons
High Light:

nickel alloys

,

nichrome resistance wire





H41XT Elastic alloy strip Elinvar strip Ni42CrTi Used for elastic sensitive elements



Ni42CrTi belongs to Fe - Ni - Cr - Ti is ferromagnetic precipitation strengthening constant elastic alloy.
After solid solution treatment, plasticity is good, hardness is low, easy to processing molding.
Solid solution or after the cold strain aging treatment, reinforcement and good constant elastic properties.

Ni42CrTi alloy with small temperature coefficient, high mechanical quality factor, good wave velocity uniformity, high strength and modulus of elasticity and smaller elastic aftereffect and lag, low linear expansion coefficient, good processing properties and good corrosion resistance and other excellent properties.



Chemical composition

composition % Fe Ni Cr Ti Al C Mn Si p S
content min Bal 41.5 5.2 2.0 0.5
max 43.5 5.8 2.7 0.8 0.05 0.8 0.8 0.02 0.02





Typical Physical properties

Density (g/cm3) 8.1
Electrical resistivity at 20ºC(OMmm2/m) 1.0
Melting point ºC 1480
Thermal conductivity, λ/ W/(m*ºC) 12.98
Elastic Modulus, E/ Gpa 176~206


Application overview

and special requirements





Ni42CrTi alloy obtained widely used in aviation.
Is mainly used for tension, pressure, bending stress of elastic sensitive element and longitudinal moment or bending vibration mode of the frequency components, for example, require constant elastic modulus (or frequency) of all kinds of sensor, pressure sensor, signal torque and around sexual curtilage screw around the top;
Can also be used to produce the film box, diaphragm, shock tube, corrugated tube, precision springs, pieces of silk, super mechanical filter, etc





H41XT Elastic alloy strip Elinvar strip Ni42CrTi Used for elastic sensitive elements 0

FAQ

1. What's the minimum quantity customer can order?
If we have your size in stock, we can provide any quantity you want.
If we do not have, for spool wire, we can produce 1 spool, about 2-3kg. For coil wire, 25kg.
2. How can you pay for small sample amount?
We have Western union account, wire transfer for sample amount also ok.

3. Customer do not have express account. How will us arrange the delivery for sample order?
Just need to provide your address information, we will check the express cost, you can arrange the express cost together with sample value.

4. What's our payment terms?
We can accept LC T/T payment terms, it also depending on delivery and total amount. Let's talk more in details after getting your detailed requirements.

5. Do you provide free samples?
If you want several meters and we have stock of your size, we can provide, customer need to bear the International express cost.

6. What's our working time?
We will give you reply through email/phone Online contact tool within 24 hours. No matter working day or holidays.
