Precision Resistor Nicr Alloy 6J22 Karma Wire Anti Oxidation

Product Details

Place of Origin: Shanghai

Brand Name: Tankii

Certification: DIN, ASTM, JIS

Model Number: karma

Payment & Shipping Terms

Minimum Order Quantity: 20kg

Packaging Details: spool ,coil, or as clients' requirement

Delivery Time: 25days

Payment Terms: L/C, D/A, D/P, T/T, Western Union

Supply Ability: 1000T/month

Get Best Price
Contact Now
Specifications
Highlight:

Precision Resistor Nicr Alloy

,

Anti Oxidation Karma Wire

,

6J22 Nicr Alloy

Product Name:
Nicr20alsi Wire/Karma /6J22Wire For Resistor
Max Working Temperature:
300
Resistivity:
1.33
Density:
8.1
Thermal Conductivity:
46
Melting Point:
1400
Hardness:
180
Tensile Strength:
780
MOQ:
20kg
Product Name:
Nicr20alsi Wire/Karma /6J22Wire For Resistor
Max Working Temperature:
300
Resistivity:
1.33
Density:
8.1
Thermal Conductivity:
46
Melting Point:
1400
Hardness:
180
Tensile Strength:
780
MOQ:
20kg
Description
Precision Resistor Nicr Alloy 6J22 Karma Wire Anti Oxidation

NiCr20AlSi wire/Karma wire for Resistors

Karma alloy is made up of copper, nickel, Aluminum and Iron as the main components. The resistivity is 2~3 times higher than Manganin. It has lower temperature coefficient of resistance(TCR), lower thermal EMF versus copper, good permanence of resistance for a long period of time and strong anti-oxidation. Its working temperature range is wider than Manganin (-60~300ºC). It is suitable for making fine precision resistance elements and strain foil.

Chemical Content(%)

Grade C Si Mn P S Ni Al Fe Cr
Karma ≤0.04 ≤0.20 0.5~1.05 ≤0.010 ≤0.010 Bal. 2.7~3.2 2.0~3.0 19.0~21.5


Physical Properties

Grade Density(g/cm3) EMF vs
Pt(0-100ºC)μv/ºC
Max using
Temp (ºC)
Volume
resistivity(μΩ.m)
PPM value
(×10-6/ºC)
Karma 8.1 ≤2.5 ≤300 1.33±8%(20ºC) ≤±30(20ºC)
