Ni95Al5 Alloy Thermal Spray Wire 1.6mm 2.0mm 2.2mm Ni Al Spray High Heat Wire

Name: Ni95Al5 Alloy Thermal Spray Wire 1.6mm 2.0mm 2.2mm Ni Al Spray High Heat Wire
Brand: TANKII
SKU: NiAl95/5
Rating: 4.9 (130 reviews)

Product Details

Place of Origin: CHINA

Brand Name: TANKII

Certification: ISO9001

Model Number: NiAl95/5

Payment & Shipping Terms

Minimum Order Quantity: 15KG

Price: Negotiation

Packaging Details: On Spool

Delivery Time: 5-10 days

Payment Terms: L/C, T/T, Western Union

Supply Ability: 20, 000kg/month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                            high heat wire, low voltage heating wire


Size:	1.6mm,1.8mm,2.0mm,2.2mm	Chemical Composition:	Ni95Al5
Density:	8.2g/cm3

Size:	1.6mm,1.8mm,2.0mm,2.2mm
Chemical Composition:	Ni95Al5
Density:	8.2g/cm3

Description

Ni95Al5 Alloy Thermal Spray Wire 1.6mm 2.0mm 2.2mm Ni Al Spray High Heat Wire

NiAl95/5

NiAl 95/5 Aolly 1.6mm 2.0mm 2.2mm Thermal Spray Wire Ni Al Spray Wire

High quality thermal spray wire Ni95Al5

(Common name:NiAl 95-5, Nickel Aluminum 95/5,N9,Ni95Al5,95/5 Nickel Aluminum,F-80NA Nickel Aluminium 95/5)

This alloy is a nickel aluminium alloy characterized by dense coating,high temperature oxidation resistance, heat shock resistance and scratch resistance.This wire has stable chemical composition, low oxgen and high bonding strength.

Typical applications for NiAl 95/5 are widely used in arc and flange flame spray systems, Coatings to resist heat and prevent scaling of conventional low alloy steels,Bond coats for improving the adhesion of top coatings,Coatings on moulds in the glass industry.

Normal composition%

Al	Mn	Fe	Ni	Si	Cu	C	Ti
4.5-5.5	Max 0.3	Max 0.3	Bal.	Max 0.5	Max 0.08	Max 0.005	Max 0.3

Typical Physical properties

Density (g/cm3)	8.2
Electrical resistivity at 20ºC(mm2/m)	0.42

Typical Deposit Characteristics

Coating Harness	Coating Strength	Deposit Rate	Deposit Efficiency	Machilityineab
23-25 HRC	65-68Mpa	10 lbs /hr/100A	60-70%	Good

Specific heat capacity

Melting point (ºC)	1010
Max continuous operating temperature in air (ºC)	800
Magnetic properties	non-magnetic

Style of supply
Wire:the common sizes are 1.6mm and 2.0mm,the spool size is DIN 300,and the weight per spool is about 10-15kgs.The other sizes are on the request of our customers.

Our Services

1) We can provide a free sample for testing.
2) Customized lable, packing, OEM service
3) Mill test certificate will be provided after production, If it is necessary.
4) Good packing methods to keep goods no damage during delivery
5) We are cooperation with many famous forwarder, will try our best to choose the safety, convenience, quick, and cheap mode of transportation for our customers.
