Product Details
Place of Origin: CHINA
Brand Name: TANKII
Certification: ISO9001
Model Number: Kovar/4J29 Strip
Payment & Shipping Terms
Minimum Order Quantity: 50kg
Price: usd28/kg
Packaging Details: plastic film, wooden case
Delivery Time: 7-15 works day
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 2000ton/year
Shape: |
Strip |
Condition: |
Soft |
Surface: |
Bright |
Product Name: |
4J29 |
Shape: |
Strip |
Condition: |
Soft |
Surface: |
Bright |
Product Name: |
4J29 |
Classification : the alloy of expansion characteristics
Application: Kovar (trademark of CRS Holdings, inc., Delaware[1]) is a nickel-cobalt ferrous alloy compositionally identical to Fernico 1, designed to be compatible with the thermal expansion characteristics of borosilicate glass (~5 × 10?6 /K between 30 and 200 °C, to ~10 × 10?6 /K at 800 °C) in order to allow direct mechanical connections over a range of temperatures. It finds application in electroplated conductors entering glass envelopes of electronic parts such as vacuum tubes (valves), X-ray and microwave tubes and some lightbulbs.
Chemical Composition in % Kovar
Ni 28,5-29,5% |
Fe 51,14-54,5% |
C 0.03% |
Si 0.3% |
Mn 0,4 % |
S o 0.015% |
P 0.015% |
o 17-18% |
Ti 0.1% |
Al 0.2% |
Cu 0.2% |
Cr 0,1 % |
The thermal properties of alloy
| Temperature coefficient of linear expansion αsr ? 10-6 K-1 in the temperature range, ° C | inflection point temperature, ° C No less |
Heat treatment regime blanks and samples | ||||||||||
| 20-80 | 20-100 | 20-300 | 20-400 | 20-450 | 20-500 | 20-800 | ||||||
| - | - | 4,6-5,6 | 4,6-5,2 | - | 5,9-6,4 | - | 420 | samples and blanks annealing in hydrogen, a vacuum or protective atmosphere at a temperature (960 ± 20) ° C, holding 1 hr., cooling with the furnace or container to 200 ° C at a rate not exceeding 10 ° C / min | ||||
| Property | sintered | HIPed | ||||||||||
| Density / g cm3 | 8.0 | 8.35 | ||||||||||
| Hardness / HV1 | 160 | 150 | ||||||||||
| Youngs Modulus / GPa | 138 | 138 | ||||||||||
| reduction of area at fracture / % | 30 | 30 | ||||||||||
| yield strength / MPa | 270 | 270 | ||||||||||
| thermal conductivity / W/Km | 17 | |||||||||||
| Curie Temperature / °C | 435 | |||||||||||
| electrical resistivity Ω mm2 / m | 0.49 | |||||||||||
| specific heat J/gK | 0.46 | |||||||||||
| thermal expansion coefficient/10?6 K?1 (25 - 200 °C) | 5.5 | |||||||||||
| (25-300 °C) | 5.1 | |||||||||||
| (25-400 °C) | 4.9 | |||||||||||
| (25-450 °C) | 5.3 | |||||||||||
| (25-500 °C) | 6.2 | |||||||||||
The name Kovar is often used as a general term for Fe-Ni alloys with these particular thermal expansion properties. Note the related particular Fe-Ni alloy Invar which exhibits minimum thermal expansion.
TANKII, referring to the presence of high-power production, offers customers buy alloy Kovar in the required quantities and ensures minimum time shipments of rolled metal products, made on the basis of Kovar.
Our service:
1) We can provide a free sample for testing but the freight at yours.
2) Mill test certificate will be provided after production, If it is necessary.
3) Good packing methods to keep goods no damage during delivery
4) We cooperate with many famous forwarder, will try our best to choose the safty, convenience, quick, and cheap mode of transportation for our customers.
(1) What is your min order?
For the Thermal spray wire, Our min order is 15kg .
(2) What is the wire weight of each spool?
The wire weight of each spool is around 15kg, also can be produce according to customers' requirement.
(3)Whether can you provide a Mill Test Certification?
We can provide a Test certification after production.
(4)How can I contact with your company?
Our sales team is ready to serve you via Email, Telephone , Fax or Skype.
Tel:+86-21-56110178
Fax:+86-21-56116916
(5)Do you provide free samples?
Yes, we can provide a free sample for testing, The quantity based on the material type.The freight is at customer's sides.
(6)What is your payment terms?
We accept 100% TT ( Telegraphic Transfer) in advance for small orders( value under USD 2000).
For some big orders, we can accept 30% deposit, 70% balance before shipment. For very small orders , we can accept paypal & Western union payment.
More detail information, please feel free contact us!
