Product Details:
|
| Color: | Sliver Or Polish | Conductor Material: | Ni-Cr |
|---|---|---|---|
| Thickness: | : 0.02----4.0mm | Condition: | Bright Annealed |
| Feature:: | High Nickel, High Resistance | Certificate:: | ISO 9001 RoHS SGS |
| Width: | 2.5----250mm | Type: | Nickel Strip |
| High Light: | nickel alloys,nichrome resistance wire |
||
Resistors or Heating Element Nicr Alloy Resistance Wire Cr15Ni60 Cr20Ni40 Cr20Ni35 Cr20Ni80
NiCr60/15
Specifications
1.Pass: ISO9001 certification
2.fine after-sale services
3.small order accepted
4.samples available
5.short delivery time
1. Introduction to products
Nickel-chromium, nickel-chromium alloy with high and stable resistance, corrosion resistance, surface oxidation resistance is good, a better under high temperature and seismic strength, good ductility, good workability and weldability.
2. Products and services
1.Pass: ISO9001 certification;
2.fine after-sale services;
3.small order accepted;
4.samples available;
3.Application
Our Products widely apply to chemical industry, metallurgy mechanism, glass industry, ceramic industry, home appliance area and so on.
4.size
wires:0.018-10mm Ribbons:0.05*0.2-2.0*6.0mm
Strips:0.5*5.0-5.0*250mm Bars:D10-100mm
Chemical Content, %
|
C |
P |
S |
Mn |
Si |
Cr |
Ni |
Al |
Fe |
Other |
|
Max |
|||||||||
|
0.08 |
0.02 |
0.015 |
0.60 |
0.75~1.60 |
15.0-18.0 |
55-61 |
Max 0.50 |
Bal |
- |
Mechanical Properties
|
Max Continuous Service Temperature: Resisivity ( 20℃)/Ω·m::
Density: Thermal Conductivity: Coefficient of Thermal Expansion: Melting Point: Elongation: Micrographic Structure: Magnetic Property: |
1150℃ 1.12 +/-0.05 (Dia: <0.5mm) 1.15+/-0.05 (Dia: ≥0.50 mm) 8.2 g/cm3 45.2 KJ/m·h·℃ 17×10-6/℃ (20℃~1000℃) 1390℃ Min 20% Austenite nonmagnetic |
Temperature Factor of Electrical Resistivity
|
20℃ |
100℃ |
200℃ |
300℃ |
400℃ |
500℃ |
600℃ |
|
1 |
1.011 |
1.024 |
1.038 |
1.052 |
1.064 |
1.069 |
|
|
||||||
|
700℃ |
800℃ |
900℃ |
1000℃ |
1100℃ |
1200℃ |
1300℃ |
|
1.073 |
1.0278 |
1.088 |
1.095 |
1.109 |
- |
- |
Our Nichrome alloy are in the form of wire, ribbon, strip, coil.
Delivery conditions are:
Our major product line:
l Electric resistance alloy materials in wire, strip, tube, and bar form.
l Furnace products and heating systems:
