Babbitt Metal Heating Resistance Wire For Arc And Flame Spray Systems

Product Details

Place of Origin: CHINA

Brand Name: TANKII

Certification: ISO9001

Model Number: NiAl95/5

Payment & Shipping Terms

Minimum Order Quantity: 15KG

Price: Negotiation

Packaging Details: On Spool

Delivery Time: 5-10 days

Payment Terms: L/C, T/T, Western Union

Supply Ability: 20, 000kg/month

Get Best Price
Contact Now
Specifications
Highlight:

high heat wire

,

low voltage heating wire

Description
Babbitt Metal Heating Resistance Wire For Arc And Flame Spray Systems

                        Babbitt Metal Thermal Spray Wire Used for Arc and Flame Spray Systems



NiAl 95/5: Thermal Spray Wire (Sp 95/5, SD 95/5, Ni95Al5)



NiAl 95/5 is an austenitic nickel-aluminium alloy (NiAl alloy) for use in arc and flame spray systems. The alloy produces dense, well bonding coatings.


Typical applications for NiAl95/5 are bond coats, as protective coatings against high-temperature oxidation, protective coatings against scaling of conventional iron base alloys and as build-up coatings for dimensional restoration.



Chemical Composition: Ni ~ 95, Al ~ 5

Application or Properties: Spray wire with excellent bonding strength. Sprayed layers of this material are-resistant to variation in high temperatures and are used as a buffer layer for all other spraying alloys. Hardness, coating macro: Approximately HRc 22. Maximum working temperature: Approximately 800° C. Layer thickness: Approximately 0.1-0.15 mm.







Technical Index



1 Coating Hardness: 23~25 HRC



2 Bond Strength: 60Mpa above



3 Working Temperature: 1250 °C below



Typical Deposit Characteristics:


Typical Hardness

Bond Strength

Deposit Rate

Deposit Efficiency

Machilityineab

HRB 75

9500 psi

10 lbs /hr/100A

60-70%

Good


Standard Sizes & Packing:


Diameter

Packing

Wire Weight

1.6mm (1/16in)

D 300 Spool

15kg(33 lb)/spool





Packaging & Shipping



Packaging: Products are generally supplied in standard cardboard boxes, pallets, wooden boxes. Special

packaging requirements can also be accommodated. (also depend on the customers' requirements)
For the Thermal spray wires, we pack the wires on spools. Then put spools into cartons, Then put the cartons onto pallet.



Shipping: We cooperation with many logistics company, We can provide express, sea transportation, air transportation, and rail way transportation based on customers' requirement.




Babbitt Metal Thermal Spray Wire Used for Arc and Flame Spray SystemsBabbitt Metal Thermal Spray Wire Used for Arc and Flame Spray Systems



Our Services

1) We can provide a free sample for testing.
2) Customized lable, packing, OEM service
3) Mill test certificate will be provided after production, If it is necessary.
4) Good packing methods to keep goods no damage during delivery
5) We are cooperation with many famous forwarder, will try our best to choose the safety, convenience, quick, and cheap mode of transportation for our customers.
