APM Powder Metallurgy FeCrAl Round Bar for High Temperature Furnaces up to 1400°C with Excellent Oxidation Resistance

Product Details

Place of Origin: China

Brand Name: TANKII

Certification: ISO9001

Model Number: APM

Payment & Shipping Terms

Minimum Order Quantity: 50KG

Price: negotiation

Packaging Details: Cardboard packaging+wooden box

Delivery Time: 7-20days

Payment Terms: T/T

Supply Ability: 500tons/month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                          FeCrAl alloy round bar, high temperature furnace FeCrAl bar, APM powder metallurgy FeCrAl


Features:	Excellent Oxidation Resistance, High Creep Strength, Long Service Life, Superior High Temperature Stability	Material:	FeCrAl Alloy
Manufacturing Process:	Powder Metallurgy	Shape:	Round Bar
Diameter:	Customized	Length:	Customized
Surface:	Bright / Pickled	Resistivity:	1.53 Ω·mm²/m
Max Continuous Operating Temperature:	1400°C	Applications:	Industrial Furnaces, Heat Treatment Furnaces, Steel Industry, Glass Industry, Furnace Support Components
MOQ:	Negotiable

Features:	Excellent Oxidation Resistance, High Creep Strength, Long Service Life, Superior High Temperature Stability
Material:	FeCrAl Alloy
Manufacturing Process:	Powder Metallurgy
Shape:	Round Bar
Diameter:	Customized
Length:	Customized
Surface:	Bright / Pickled
Resistivity:	1.53 Ω·mm²/m
Max Continuous Operating Temperature:	1400°C
Applications:	Industrial Furnaces, Heat Treatment Furnaces, Steel Industry, Glass Industry, Furnace Support Components
MOQ:	Negotiable

Description

APM Powder Metallurgy FeCrAl Round Bar for High Temperature Furnaces up to 1400°C with Excellent Oxidation Resistance

APM Powder Metallurgy FeCrAl Round Bar for High Temperature Furnaces up to 1400°C

This product takes refined master alloy as raw material, uses powder metallurgy technology to manufacture alloy ingots, and is manufactured by special cold and hot processing and heat treatment process. The product has the advantages of strong oxidation resistance, good corrosion resistance at high temperature, small creep of electrothermal components, long service life at high temperature and small change of resistance. It is suitable for high temperature 1400 C, high power density, corrosive atmosphere, carbon atmosphere and other working environments. It can be used in ceramic kilns, high temperature heat treatment furnaces, laboratory furnaces,
electronic industrial furnaces and diffusion furnaces.

Main composition

	C	Si	Mn	Cr	Al	Fe
Min	-	-	-	20	5.5	Bal.
Max	0.04	0.5	0.4	22	6.0	Bal.

Main mechanical properties
Tensile Strength at Room Temperature: 650-750MPa
Elongation rate: 15-25%
Hardness: HV220-260
1000ºC Tensile Strength at 1000ºC Temperature 22-27MPa
1000ºC 6MPa High Temperature Durability at 1000 Temperature and 6MPa ≥100h

Main physical properties
Density 7.1g/cm3
Resistivity 1.53×10-6 Ω.m
Resistance Temperature Coefficient(Ct)
Melting point:1500ºC
Maximum Continuous Working Temperature 1400ºC

800ºC	1000ºC	1400ºC
1.03	1.04	1.05

Average linear expansion coefficient

20-800ºC	20-1000ºC	20-1400ºC
14	15	16

Fast life

	1400ºC	1370ºC
Average Fast Life (Hours)	178	>500
Sagging rate after rupture	8	11

APM FeCrAl Alloy Bar for High Temperature Furnace Support Components
