NiChrome N8 Foil Super Thin 0.005mm Used For Resistance Strain Gauge / Sensing Element

Name: NiChrome N8 Foil Super Thin 0.005mm Used For Resistance Strain Gauge / Sensing Element
Brand: Shanghai Tankii Alloy Material Co.,Ltd
SKU: nichrome
Price: 300.00 USD
Availability: InStock

Product Details

Place of Origin: China Mainland

Brand Name: Tankii

Certification: ISO9001

Model Number: nichrome

Payment & Shipping Terms

Minimum Order Quantity: Negotiable

Price: Negotiable

Packaging Details: Standard exoprt package

Delivery Time: About 20 days after getting the payment

Payment Terms: T/T, Paypal, Western Union, MoneyGram,

Supply Ability: 1000Ton per year

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:

Item:	NiChrome N8 Foil Super Thin 0.005mm	Material:	Nicr Alloy
Surface:	Bright	Thickness:	0.005mm Or More
Leading Time:	20 Days As Per The Order Qty	Application:	Strain Resistance Materials
Powder Or Not:	Not Powder	MOQ:	20kg

Item:	NiChrome N8 Foil Super Thin 0.005mm
Material:	Nicr Alloy
Surface:	Bright
Thickness:	0.005mm Or More
Leading Time:	20 Days As Per The Order Qty
Application:	Strain Resistance Materials
Powder Or Not:	Not Powder
MOQ:	20kg

Description

NiChrome N8 Foil Super Thin 0.005mm Used For Resistance Strain Gauge / Sensing Element

NiChrome N8 Foil Super Thin 0.005mm Used For Resistance Strain Gauge / Sensing Element

The main component of nichrome alloy is nickel, with a content usually exceeding 50%. In addition, it also contains elements such as iron, chromium, molybdenum, and copper. These elements are alloyed in a certain proportion to achieve the multifunctionality of the material:
Nickel: Provides a substrate to ensure basic performance of corrosion resistance and high temperature resistance.
Chromium: enhances the oxidation resistance and corrosion resistance of alloys.
Molybdenum: enhances the overall hardness and stress corrosion cracking resistance of alloys.
Copper: improves conductivity and antibacterial properties, enhances mechanical strength.

Nickel-chromium alloy with high and stable resistance, corrosion resistance, surface oxidation resistance, excellent coil- forming ability.it is an ideal material,it has good ductility,workability and weldability under high temperature and seismic strength.

Common Names :Karma, Evanohm, Ni80Cr20,Nikrothal 8,MWS-650,NiCrA,Tophet A,HAI-NiCr 80,Chromel A,Alloy A,Alloy 650,N8,Resistohm 80, Stablohm 650,Nichorme V,Nikrothal 80.

NiCr series: Karma, Evanohm, Cr20Ni80, Cr30Ni70, Cr15Ni60, Cr20Ni35, Cr20Ni30.

1. Size dimension range:
Foil: Tailor-made
Wire: 0.01-10mm
Ribbons: 0.05*0.2-2.0*6.0mm
Strip: 0.05*5.0-5.0*250mm
Bar:10-50mm

Key Features of nichrome products:

Nichrome 80 is a proven electrical resistance heating material
Produces adherent chromium oxide layer to prevent oxidation
Highly durable and corrosion resistant
Ideal for use in frequent temperature switching application

Chemical Composition and Propertes:

Propertes/Grade		Karma	NiCr 80/20	NiCr 70/30	NiCr 60/15	NiCr 35/20	NiCr 30/20
Main Chemical Composition(%)	Ni	Bal.	Bal.	Bal.	55.0-61.0	34.0-37.0	30.0-34.0
	Cr	19~21.5	20.0-23.0	28.0-31.0	15.0-18.0	18.0-21.0	18.0-21.0
	Fe	2~3	≤ 1.0	≤ 1.0	Bal.	Bal.	Bal.
	Al	2.7~3.2
	Mn	0.5~1.5
Max Working Temperature(ºC)		300	1200	1250	1150	1100	1100
Resistivity at 20ºC (μ Ω · m)		1.33	1.09	1.18	1.12	1.04	1.04
Density(g/cm3)		8.1	8.4	8.1	8.2	7.9	7.9
Thermal Conductivity (KJ/m· h· ºC)		46	60.3	45.2	45.2	43.8	43.8
Coefficient of Thermal Expansion(α × 10-6/ºC)		-	18	17	17	19	19
Melting Point(ºC)		1400	1400	1380	1390	1390	1390
Elongation(%)		10~20	> 20	> 20	> 20	> 20	> 20
Micrographic Structure		austenite	austenite	austenite	austenite	austenite	austenite
Magnetic Property		Non	nonmagnetic	nonmagnetic	nonmagnetic	nonmagnetic	nonmagnetic

2. Products and services
1> ROHS cerfication;
2.> Small orders are accepted;
3.> Factory direct sale;
4.> Timely delivery;
5> Samples are available;
3 Features
1>. Good oxidation resistance;
2> . Low embrittlement at high temperature;
3.> Good plasticity(easier to give them a shape);
4> . Nice performance and processing;
4 Applications
It is mainly used to manufacture precision resistor components for various measuring instruments and meters, such as high-precision resistors, strain gauges and micro resistor components. Due to its excellent physical properties, this material has wide applicability in the field of industrial instrument manufacturing.

NiChrome N8 Foil Super Thin 0.005mm Used For Resistance Strain Gauge / Sensing Element 0
