TK 1 Fe-Cr-Al Alloy Wire Rod For Industrial In Temperature Environments

Name: TK 1 Fe-Cr-Al Alloy Wire Rod For Industrial In Temperature Environments
Brand: Shanghai Tankii Alloy Material Co.,Ltd
SKU: TK 1
Price: 5 USD
Availability: InStock

Product Details

Place of Origin: CHINA

Brand Name: TANKII

Model Number: TK 1

Payment & Shipping Terms

Minimum Order Quantity: 10KG

Price: 5usd/kg

Packaging Details: Carton+wooden crate

Delivery Time: 10DAYS

Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability: 10TON/MONTH

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                    Fe-Cr-Al alloy wire rod, Alloy Wire Rod for Industrial


Description

TK 1 Fe-Cr-Al Alloy Wire Rod For Industrial In Temperature Environments

Basic Info.

Technique

Drawn Wire

Application

heater, resistor

Alloy or Not

Alloy

Standard

BS, JIS, GB, ASTM, DIN, AISI

Resistivity

1.45

Density(g/cm 3 )

7.1

packaging

Carton or wooden cases

Transport Package

Plastic Film, Weave Bag, Pallet

Specification

RoHS, ISO 9001

Trademark

TANKII

Origin

Tankii, China

HS Code

72230000

Production Capacity

5000 Tons/Year

Product Description

TK 1 Fe-Cr-Al alloy wire rod 0.5mmd

TK 1 (Kan A1 ) large-sized cold-drawn wire products can be used for high-temperature resistance furnace.
Practice has proved that: the product process is stable, integrated performance is good. Has good high temperature oxidation

resistance and longer service life; excellent winding properties at room temperature processing, ease of

processing molding; little rebound resilience and so on. Processing performance is very good; operating

temperature can reach 1400 deg .

Conventional Product specifications: 0.5 ~ 10 mm

Properties Grade	Kan-thal A1
	Cr	Al	Re	Fe
	20.5--23.5	5.8	Suitable	Balance
Max Continuous ServiceTemperature(ºC)	Diameter 1.0-3.0		Diameter large than 3.0,
	1225-1350ºC		1400ºC
Resisivity 20ºC (Omm2/m)	1.45
Density(g/cm 3 )	7.1
Approximate Melting Point( ºC)	1520
Elongation (%)	16-33
Repeatedly Bend Frequency(F/R)20ºC	7-12
Continuous Service Time under 1350ºC	More than 60 hours
Micrographic Structure	Ferrite

The relationship between the maximum operating temperature and the furnace atmosphere

Furnace atmosphere	Dry Air	Humid Air	hydrogen-argon gas	Argon	Decomposition ammonia gas
Temp( ºC)	1400	1200	1400	950	1200

TK 1 Fe-Cr-Al Alloy Wire Rod For Industrial In Temperature Environments 0

TK 1 Fe-Cr-Al Alloy Wire Rod For Industrial In Temperature Environments 1

TK 1 Fe-Cr-Al Alloy Wire Rod For Industrial In Temperature Environments 2
