Product Details
Place of Origin: CHINA
Brand Name: Tankii
Certification: ISO 9001
Model Number: Nickel alloy wire
Payment & Shipping Terms
Minimum Order Quantity: 15KG
Price: 25USD
Packaging Details: spool,coil
Delivery Time: 5-30 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 2000kg/month
Grade: |
NiCr Alloy |
Application: |
Heating Element And Resistor |
Condition: |
Hard / Soft |
Feature: |
High Resistance |
Material: |
Ni80%Cr20% |
Conductor Type: |
Solid |
Resisivity: |
1.09 |
Bar: |
10-50mm |
Composition: |
Nickel, Chromium |
Model No: |
NCHW-1 |
Highest Temperature: |
1200℃ |
Shipping Form: |
By Sir, Air Or By Express |
Type: |
Solid |
Micrografic Structure: |
Ferrite |
Resistivity: |
0.78+/-0.05 |
Available Forms: |
Wire, Strip, Sheet, Foil, Bar, Tube, Powder |
Usual Size: |
0.523mm X 18 & 0.574mm |
Max Working Temperature: |
1200C |
Grade: |
NiCr Alloy |
Application: |
Heating Element And Resistor |
Condition: |
Hard / Soft |
Feature: |
High Resistance |
Material: |
Ni80%Cr20% |
Conductor Type: |
Solid |
Resisivity: |
1.09 |
Bar: |
10-50mm |
Composition: |
Nickel, Chromium |
Model No: |
NCHW-1 |
Highest Temperature: |
1200℃ |
Shipping Form: |
By Sir, Air Or By Express |
Type: |
Solid |
Micrografic Structure: |
Ferrite |
Resistivity: |
0.78+/-0.05 |
Available Forms: |
Wire, Strip, Sheet, Foil, Bar, Tube, Powder |
Usual Size: |
0.523mm X 18 & 0.574mm |
Max Working Temperature: |
1200C |
Ni80, also known as Nickel 80, is a high-performance nickel-chromium alloy renowned for its exceptional properties. Composed of 80% nickel and 20% chromium, this alloy offers numerous advantages in various industrial applications.
One of the key strengths of Ni80 is its remarkable resistance to high temperatures. It can withstand elevated heat levels without experiencing significant deformation or degradation, making it ideal for applications that involve intense heat or thermal cycling.
Additionally, Ni80 exhibits excellent corrosion resistance, ensuring its durability and longevity in corrosive environments. This attribute makes it highly suitable for applications exposed to moisture, chemicals, or other corrosive agents.
Another notable advantage of Ni80 is its exceptional oxidation resistance. It forms a protective oxide layer on its surface when exposed to air or high temperatures, enabling it to resist oxidation and maintain its integrity even in challenging conditions.
Furthermore, Ni80 possesses excellent electrical conductivity, making it highly desirable for applications requiring efficient electrical current flow. It is commonly used in heating elements, electrical resistors, and other electrical components where reliable performance and conductivity are paramount.
Overall, Ni80's combination of high-temperature resistance, corrosion resistance, oxidation resistance, and electrical conductivity makes it a versatile and reliable choice for a wide range of industrial applications.
Product Features
Grade | Elongation | Density (g/cm3) | Electrical resistivity at 20℃(Ωmm2/m) | Conductivity coefficient at 20℃ (WmK) | Coefficient of Thermal Expansion x10-6/℃ | Melting point (℃) | Max continuous operating temperature in air (℃) | Magnetic properties |
(%) | ||||||||
Ni80Cr20 | 30 | 8.4 | 1.09 | 15 | 18 | 1400 | 1200 | Non-magnetic |
Ni35Cr20 | 35 | 7.9 | 1.04 | 13 | 19 | 1390 | 1100 | Non-magnetic |
Ni30Cr20 | 35 | 7.9 | 1.04 | 13 | 19 | 1390 | 1100 | Non-magnetic |
Ni60Cr15 | 35 | 8.2 | 1.12 | 13 | 17 | 1390 | 1150 | Non-magnetic |
Ni70Cr30 | 30 | 8.2 | 1.18 | 14 | 17 | 1380 | 1250 | Non-magnetic |
0Cr21Al4 | 16 | 7.35 | 1.23 | 13 | 13.5 | 1500 | 1100 | Non-magnetic |
1Cr13Al4 | 22 | 7.4 | 1.25 | 15 | 15.4 | 1450 | 950 | Non-magnetic |
0Cr23Al5 | 23 | 7.25 | 1.35 | 13 | 15 | 1500 | 1250 | Non-magnetic |
0Cr21Al6 | 20 | 7.16 | 1.42 | 13 | 14.7 | 1500 | 1250 | Non-magnetic |
0Cr25Al5 | 23 | 7.1 | 1.42 | 13 | 15 | 1500 | 1250 | Non-magnetic |
0Cr21Al6Nb | 22 | 7.1 | 1.45 | 13 | 16 | 1510 | 1350 | Non-magnetic |
0Cr27Al7Mo2 | 20 | 7.1 | 1.53 | 13 | 16 | 1520 | 1400 | Non-magnetic |
