Nickel Chrome NICR 80/20 Seamless Heating Alloy Nichrome Nch (R) W1 Micro Capillary Tube / Pipe

Name: Nickel Chrome NICR 80/20 Seamless Heating Alloy Nichrome Nch (R) W1 Micro Capillary Tube / Pipe
Brand: Shanghai Tankii Alloy Material Co.,Ltd
SKU: NI80CR20
Price: 300.00 USD
Availability: InStock

Product Details

Place of Origin: Shanghai, China

Brand Name: TANKII

Certification: ISO9001 SGS

Model Number: NI80CR20

Payment & Shipping Terms

Minimum Order Quantity: 10 KG

Price: negotiable

Packaging Details: Wooned Case

Delivery Time: 7-20 days

Payment Terms: L/C, T/T, Western Union

Supply Ability: 100 Tons per month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                            Seamless Heating Micro Capillary Tube, Nickel Chrome Micro Capillary Tube


Model NO.:	Nichrome Tube	Chemical Composition:	77% Ni
Density:	8.4 G/cm3	Out Diameter:	0.3mm Min.
Wall Thickness:	0.02mm Min.	Length:	0.3mm Min.
Origin:	Shanghai China

Model NO.:	Nichrome Tube
Chemical Composition:	77% Ni
Density:	8.4 G/cm3
Out Diameter:	0.3mm Min.
Wall Thickness:	0.02mm Min.
Length:	0.3mm Min.
Origin:	Shanghai China

Description

Nickel Chrome NICR 80/20 Seamless Heating Alloy Nichrome Nch (R) W1 Micro Capillary Tube / Pipe

Nickel Chrome NICR 80/20 Seamless Heating Alloy Nichrome Nch (R) W1 Micro Capillary Tube/Pipe

Description

Model NO.	NiCr8020	Density	8.4 g/cm3
Material Shape	Tube	Melting Point	1400 C
Range of Application	Resistor, Heater	OEM	YES
Certification	ISO9001, RoHS	Stock	Seyn
Brand	HUONA	Tensile Strength	810 MPa
Usage	Resistance materials	Electrical Resistivity	1.09
Elongation	>20%	Trademark	TANKII
Hardness	180 HV	Transport Package	Spool, Carton, Wooden Case
Max Working Temperature	1200 C	Specification	0.8mm
HS Code	7506200000	Origin	China

Chemical Composition and Propertes:
Propertes/Grade		NiCr 80/20	NiCr 70/30	NiCr 60/15	NiCr 35/20	NiCr 30/20
Main Chemical Composition(%)	Ni	Bal.	Bal.	55.0-61.0	34.0-37.0	30.0-34.0
	Cr	20.0-23.0	28.0-31.0	15.0-18.0	18.0-21.0	18.0-21.0
	Fe	≤ 1.0	≤ 1.0	Bal.	Bal.	Bal.
Max Working Temperature(ºC)		1200	1250	1150	1100	1100
Resistivity at 20ºC(μ Ω · m)		1.09	1.18	1.12	1.04	1.04
Density (g/cm3)		8.4	8.1	8.2	7.9	7.9
Thermal Conductivity (KJ/m· h· ºC)		60.3	45.2	45.2	43.8	43.8
Coefficient of Thermal Expansion(α × 10-6/ºC)		18	17	17	19	19
Melting Point(ºC)		1400	1380	1390	1390	1390
Elongation(%)		> 20	> 20	> 20	> 20	> 20
Micrographic Structure		austenite	austenite	austenite	austenite	austenite
Magnetic Property		nonmagnetic	nonmagnetic	nonmagnetic	nonmagnetic	nonmagnetic

Chemical Composition	Nickel 80%, Chrome 20%
Condition	BrightColor
Diameter	0.3mm Min.
Nichrome Strip	Width 450mm~1mm, thickness 0.001m~7mm
wall thickness	0.02 mm min.
Grade	Ni80Cr20, Ni70/30, Ni60Cr15, Ni60Cr23, Ni35Cr20Fe, Ni30Cr20 Ni80, Ni70,Ni60, Ni40,
Advantage	Nichrome's metallurgical structure confers them a very good plasticity when cold.
Characteristics	Stable performance; Anti-oxidation; Corrosion resistance; High temperature stability; Excellent coil-forming ability; Uniform and beautiful surface condition without spots.
Usage	Resistance heating elements;Material in metallurgy; Household appliances; Mechanical manufacturing and other industries.
