Cold Drawn Ni80Cr20 Tube Nichrome 8020 NICR Resistance Alloy Capillary Pipe / Super-thin Pipe OD 2 Mm

Name: Cold Drawn Ni80Cr20 Tube Nichrome 8020 NICR Resistance Alloy Capillary Pipe / Super-thin Pipe OD 2 Mm
Brand: Shanghai Tankii Alloy Material Co.,Ltd
SKU: NICR 80/20
Price: 300.00 USD
Availability: InStock

Product Details

Place of Origin: Shanghai, China

Brand Name: TANKII

Certification: ISO9001 SGS

Model Number: NICR 80/20

Payment & Shipping Terms

Minimum Order Quantity: 10 KG

Price: negotiable

Packaging Details: Wooned Case

Delivery Time: 7-20 days

Payment Terms: L/C, T/T, Western Union

Supply Ability: 100 Tons per month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                            OD 2 mm Nichrome 8020 tube, Cold Drawn Nichrome 8020 tube, NICR Resistance alloy capillary pipe


Material:	Nichrome Tube	OD:	0.3-20.0mm
W.T.:	0.02mm Min.	Surface:	Bright Surface
Density:	8.4 G/cm3	Length:	0.5mm Min.
Sample:	Accept Small Order

Material:	Nichrome Tube
OD:	0.3-20.0mm
W.T.:	0.02mm Min.
Surface:	Bright Surface
Density:	8.4 G/cm3
Length:	0.5mm Min.
Sample:	Accept Small Order

Description

Cold Drawn Ni80Cr20 Tube Nichrome 8020 NICR Resistance Alloy Capillary Pipe / Super-thin Pipe OD 2 Mm

Chemical Composition: 80% nickel, 20% chrome
Resisvity: 1.09 ohm mm2/m,
Hardness: Soft, hard or semi-hard

The resistance of the nichrome tube generates heat when an electric current passes through it.
The heat generated by the nichrome tube is proportional to the amount of electrical current flowing through it and the resistance of the tube.
The higher the electrical current and the resistance of the tube, the more heat is generated.

Characteristics: Stable performance; Anti-oxidation; Corrosion resistance; High temperature stability; Excellent coil-forming ability; Uniform and beautiful surface condition without spots.

Usage: Resistance heating elements; Material in metallurgy;
Household appliances; Mechanical manufacturing and other industries.

We professionally produce nickel-base alloy tape, include Ni80Cr20, Ni60Cr23,
Ni60Cr16, Ni35Cr20, Ni20Cr25, NiMn, Ni200, Karma, Evanohm, NCHW, etc.

Properties/Grade		Cr20Ni80	Cr30Ni70	Cr15Ni60	Cr20Ni35	Cr20Ni30
Main Chemical composition	Ni	Rest	Rest	55.0-61.0	34.0-37.0	30.0-34.0
	Cr	20.0-23.0	28.0-31.0	15.0-18.0	18.0-21.0	18.0-21.0
	Fe	≤ 1.0	≤ 1.0	Rest	Rest	Rest
Max. continuous service temp. of element		1200	1250	1150	1100	1100
Resistivity at 20oC (μ Ω · m)		1.09	1.18	1.12	1.04	1.04
Density (g/cm3)		8.40	8.10	8.20	7.90	7.90
Thermal conductivity(KJ/m· h· oC)		60.3	45.2	45.2	43.8	43.8
Coefficient of lines expansion(α × 10-6/oC)		18.0	17.0	17.0	19.0	19.0
Melting point (approx. )( oC)		1400	1380	1390	1390	1390
Elongation at rupture (%)		> 20	> 20	> 20	> 20	> 20
Micrographic structure		austenite	austenite	austenite	austenite	austenite
Magnetic properties		nonmagnetic	nonmagnetic	nonmagnetic	nonmagnetic	nonmagnetic

Cold Drawn Ni80Cr20 Tube Nichrome 8020 NICR Resistance Alloy Capillary Pipe / Super-thin Pipe OD 2 Mm 0
