1.5mm*50mm 0cr21al6nb Strip Fecralnb21/6 Strip

Name: 1.5mm*50mm 0cr21al6nb Strip Fecralnb21/6 Strip
Brand: Shanghai Tankii Alloy Material Co.,Ltd
SKU: 0Cr21Al6Nb
Price: 26.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: Tankii

Certification: ISO 9001

Model Number: 0Cr21Al6Nb

Payment & Shipping Terms

Minimum Order Quantity: Negotiation

Price: Negotatioin

Packaging Details: Spool,coil,cartoon

Delivery Time: 5-30 days

Payment Terms: T/T, Western Union

Supply Ability: 20000kg/month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                    0cr21al6nb Fecralnb21/6 Strip, 1.5mm Fecralnb21/6 Strip, 1.5mm*50mm Fecralnb21/6 Strip


Product Name:	Spark Plug Wire	Shape:	Wire
Material:	FeCrAl	Application:	Spark Plug Wire
Size:	Customer's Requirement	Type:	Bare

Product Name:	Spark Plug Wire
Shape:	Wire
Material:	FeCrAl
Application:	Spark Plug Wire
Size:	Customer's Requirement
Type:	Bare

Description

1.5mm*50mm 0cr21al6nb Strip Fecralnb21/6 Strip

1.5mm*50mm 0Cr21Al6Nb strip FeCrAlNb21/6 Strip

0Cr21Al6Nb is a iron-chromium-aluminium alloy (FeCrAl alloy) characterized by high resistance, low coefficient of electric resistance, high operating temperature, good corrosion resistance under high temperature.It is suitable for use at temperatures up to 1250°C.

Typical applications for 0Cr21Al6Nb are used in industrial electric furnace, household electrical appliance and far infrared ray device

1. Product Detail

1) Normal Composition(%)

C	P	S	Mn	Si	Cr	Ni	Al	Fe	Other
Max
0.12	0.025	0.025	0.70	Max 1.0	18.0~21.0	Max 0.60	3.0~4.2	Bal.	-

2)Typical Mechanical Properties(1.0mm)

Yield strength	Tensile Strength	Elongation
Mpa	Mpa	%
550	750	22

3)Typical Physical Properties

Density (g/cm3)	7.1
Electrical resistivity at 20ºC(Ωmm2/m)	1.45
Conductivity coefficient at 20ºC (WmK)	13

4)Coefficient of thermal expansion
Temperature	Coefficient of Thermal Expansion x10-6/ºC
20 ºC- 1000ºC	16

Grade		1Cr13Al4	TK1	0Cr25Al5	0Cr20Al6Re	0Cr23Al5	0Cr19Al3	0Cr21Al6Nb	0Cr27Al7Mo2
Nominal composition %	Cr	12.0-15.0	22.0-26.0	23.0-26.0	19.0-22.0	22.5-24.5	18.0-21.0	21.0-23.0	26.5-27.8
	Al	4.0-6.0	5.0-7.0	4.5-6.5	5.0-7.0	4.2-5.0	3.0-4.2	5.0-7.0	6.0-7.0
	Re	opportune	0.04-1.0	opportune	opportune	opportune	opportune	opportune	opportune
	Fe	Bal.		Bal.	Bal.	Bal.	Bal.	Bal.	Bal.
								Nb0.5	Mo1.8-2.2
Resistivity 20ºC		1.25	1.48	1.42	1.40	1.35	1.23	1.45	1.53
Density(g/cm³)		7.4	7.1	7.1	7.16	7.25	7.35	7.1	7.1
Max continuous operating temperature(ºC)		650	1400	1250	1250	1250	1100	1350	1400

1.5mm*50mm 0cr21al6nb Strip Fecralnb21/6 Strip 0
