Electric CrFeAl 145 Resistance Nickel Alloys High Resistivity Low Temperature

Name: Electric CrFeAl 145 Resistance Nickel Alloys High Resistivity Low Temperature
Brand: Shanghai Tankii Alloy Material Co.,Ltd
SKU: CrFeAl 145
Price: 300.00 USD
Availability: InStock

Product Details

Place of Origin: CHINA

Brand Name: TANKII

Certification: ISO9001

Model Number: CrFeAl 145

Payment & Shipping Terms

Minimum Order Quantity: 20kg

Price: negotiation

Packaging Details: spool+plastic bag+carton+pallet for resistance wires

Payment Terms: L/C, T/T, Western Union

Supply Ability: 20, 000kg/month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                    Electric CrFeAl 145 Resistance Nickel Alloys, Low Temperature Resistance Nickel Alloys, CrFeAl 145 Resistance Nickel Alloys


Color:	Sliver Or Polish	Conductor Material:	Ni-Cr
Thickness:	: 0.02----4.0mm	Condition:	Bright Annealed
Feature::	High Nickel, High Resistance	Certificate::	ISO 9001 RoHS SGS
Width:	2.5----250mm	Type:	Nickel Strip

Color:	Sliver Or Polish
Conductor Material:	Ni-Cr
Thickness:	: 0.02----4.0mm
Condition:	Bright Annealed
Feature::	High Nickel, High Resistance
Certificate::	ISO 9001 RoHS SGS
Width:	2.5----250mm
Type:	Nickel Strip

Description

Electric CrFeAl 145 Resistance Nickel Alloys High Resistivity Low Temperature

Electric CrFeAl 145 Resistance Nickel Alloys High Resistivity Low Temperature

Fe - Cr - Al alloy: 0Cr25Al5, 0Cr23Al5, 0Cr14Al4, 0Cr27Al7Mo2, 0Cr21Al6Nb, 0Cr21Al6.

Grade	0Cr25Al5
Size	10-60mm
Surface	oxidized
Resistivity	1.42±0.07μΩ.m
Highest temperature	1250ºC
Density	7.1g/cm³
Tensile strength	750N/mm²
Elongation	≥12%

Grade	Highest temperature	Resistivity	Melting point	Tensile strength	Elongation
0Cr21Al4	1100ºC	1.23±0.06μΩ.m	1500ºC	750	≥12
0Cr25Al5	1250ºC	1.42±0.07μΩ.m	1500ºC	750	≥12
0Cr21Al6NbCo	1350ºC	1.43±0.07μΩ.m	1510ºC	750	≥12
0Cr27Al7Mo2	1400ºC	1.53±0.07μΩ.m	1520ºC	750	≥10
KSC	1350ºC	1.44±0.05μΩ.m	1510ºC	750	≥16
Cr20Ni80	1200ºC	1.09±0.05μΩ.m	1400ºC	750	≥20
Cr15Ni60	1150ºC	1.12±0.05μΩ.m	1390ºC	750	≥20
Cr20Ni35	1100ºC	1.04±0.05μΩ.m	1390ºC	750	≥20
Cr20Ni30	1100ºC	1.04±0.05μΩ.m	1390ºC	750	≥20

Grade	Chemical composition%
	C	P	S	Mn	Si	Cr	Ni	Al	Fe
	≤				Si	Cr	Ni	Al	Fe
0Cr21Al4	0.12	0.025	0.025	0.7	≤1.0	17-21	≤0.6	3-4	balance
0Cr25Al5	0.06	0.025	0.02	0.5	≤0.6	23-26	≤0.6	4.5-6.5	balance
0Cr21Al6Nb	0.05	0.025	0.02	0.5	≤0.6	21-23	≤0.6	5-7	balance
0Cr27Al7Mo2	0.05	0.025	0.02	0.2	≤0.4	26.5-27.8	≤0.6	6-7	balance
Cr20Ni80	0.08	0.02	0.015	0.6	0.75-1.6	20-23	balance	<0.5	≤1.0
Cr15Ni60	0.08	0.02	0.015	0.6	0.75-1.6	15-18	55-61	<0.5	balance
Cr20Ni35	0.08	0.02	0.015	1.0	1-3	18-21	34-37	-	balance
Cr20Ni30	0.08	0.02	0.015	1.0	1-3	18-21	30-34	-	balance
