Pure Nickel Strip Purity > 99.5% for Cathode Tap / Battery Industry

Product Details

Place of Origin: China

Brand Name: TANKII

Certification: ISO,ROHS

Model Number: Pure Ni

Payment & Shipping Terms

Minimum Order Quantity: 20KG

Packaging Details: in roll, wooden case outside

Payment Terms: L/C, T/T, Western Union

Supply Ability: 10,000/Month

Get Best Price
Contact Now
Specifications
Highlight:

nickel foil

,

nickel copper alloy

Ni (Min):
: 99.6% Min
Thickness:
: 0.002 To 3.50 Mm
Width:
: Up To 1500mmwide
Powder Or Not:
: Not Powder
Standard:
: ASTM B162
Sample Free:
:Avialable
Ni (Min):
: 99.6% Min
Thickness:
: 0.002 To 3.50 Mm
Width:
: Up To 1500mmwide
Powder Or Not:
: Not Powder
Standard:
: ASTM B162
Sample Free:
:Avialable
Description
Pure Nickel Strip Purity > 99.5% for Cathode Tap / Battery Industry

Pure Nickel Strip Purity > 99.5% for Cathode Tap / Battery Industry





Product Description

     Pure Nickel Strip is primarily used for chemical treatment, preservation and production of synthetic fiber materials. The Pure Nickel strip can be operated up to 600̊F.  It has outstanding magnetic properties and thermal and electrical conductivity.



     Pure Nickel strip can be used as cathode tap, cell connector of nickel metal hydride battery, nickel cadmiumbattery and lithium battery. It is also used as the pin of PTC devices and Electric vacuum components.



Chemical Composition of Pure Nickel Strip:



Nickel

99.6%

Copper

0.25%

Iron

0.40%

Manganese

0.35%

Carbon

0.15%

Silicon

0.35%

Sulfur

0.01%



Nickel Strip Chemical requirements

Grade

Ni+Co

Cu

Si

Mn

C

Mg

S

P

Fe

N4

99.9

0.015

0.03

0.002

0.01

0.01

0.001

0.001

0.04

N6

99.6

0.10

0.10

0.05

0.10

0.10

0.005

0.002

0.10

Ni201

99.0

0.25

0.35

0.35

0.02

  /

0.01

/

0.40

Ni200

99.0

0.20

0.30

0.30

0.15

/

0.01

/

0.40







Physical properties of Pure Nickel Strip:

Density, g/cm3

8.89

Melting Range, °C

1435-1446

Specific Heat, J/kg•°C

456

Curie Temperature, °C

360







What are the characteristics of Nickel Strip?

  •  High degree of electrical conductivity
  •  Low electrical resistivity
  •  Excellent surface and slit edge conditions
  •  Enhanced solderability as a result of low surface oxides
  •  formability with deep draw characteristics with reduced die wear
  •  Resistance to grain growth

Pure Nickel Strip Purity > 99.5% for Cathode Tap / Battery Industry 0

In what applications is Nickel Strip used?

  •  Rechargeable Batteries (Nickel Metal Hydride, Lithium Ion)
  •  Material Stampings
  •  Lead Frames
  •  Gaskets and Seals
  •  Lighting Applications
  •  Superconductor Applications
  •  Weld Wire
