Product Details
Place of Origin: Shanghai,China
Brand Name: TANKII
Certification: BS,ASTM,AISI,CTI
Model Number: Nickel wire
Payment & Shipping Terms
Minimum Order Quantity: 120KG
Price: $15~$25/KG
Packaging Details: on spool,paper box,wooden case/pallet,in coil
Delivery Time: 30days
Payment Terms: L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability: 700T per moth
Port: |
ShangHai ,China |
Brand: |
Tankii |
Application: |
Industry Heating Elements |
Grade: |
Pure Nickel |
Ultimate Strenrth (≥ Mpa): |
462Mpa |
Type: |
Nickel |
Resistance(μω.m): |
Stable |
Ni( Min): |
99.9% |
Powder Or Not: |
Not Powder |
Elongation(≥ %): |
35% |
Surface: |
Bright |
Thickness: |
0.01~6mm |
Material: |
Nickel Material |
Width: |
10~1000mm |
Standard: |
ASTM |
Product Name: |
High Temperture Resistance 99.98% Pure Nickel Wire (Ni4) 0.025mm In Stock Used In Electrical Industry |
Melting Point: |
1455℃ |
Color: |
Nickel Nature |
Purity: |
More Than 99.9% |
Faeture: |
Weak Magnetic |
Density: |
8.9g/cm3 |
Port: |
ShangHai ,China |
Brand: |
Tankii |
Application: |
Industry Heating Elements |
Grade: |
Pure Nickel |
Ultimate Strenrth (≥ Mpa): |
462Mpa |
Type: |
Nickel |
Resistance(μω.m): |
Stable |
Ni( Min): |
99.9% |
Powder Or Not: |
Not Powder |
Elongation(≥ %): |
35% |
Surface: |
Bright |
Thickness: |
0.01~6mm |
Material: |
Nickel Material |
Width: |
10~1000mm |
Standard: |
ASTM |
Product Name: |
High Temperture Resistance 99.98% Pure Nickel Wire (Ni4) 0.025mm In Stock Used In Electrical Industry |
Melting Point: |
1455℃ |
Color: |
Nickel Nature |
Purity: |
More Than 99.9% |
Faeture: |
Weak Magnetic |
Density: |
8.9g/cm3 |
Product Description:
Nickel 200 is commercially pure wrought nickel. It is highly resistant to various reducing chemicals. It can also be used in oxidizing conditions that cause the formation of a passive oxide film, for instance its unexcelled resistance to caustic alkalis. Nickel 200 is limited to service at temperatures below 315℃, because at higher temperatures it suffers from graphitization which results in severely compromised properties. In that circumstance, Nickel 201 is used instead. It has a high Curietemperature and good magnetostrictive properties. Its thermal and electrical conductivities are higher than nickel alloys.
Nickel 201 is the low-carbon version of Nickel 200. Because of its low carbon content, Nickel 201 is not subject to embrittlement by intergranularly precipitated carbon or graphite when exposed to temperatures of 315 to 760℃ for prolonged time if carbonaceous materials are not in contact with it. Therefore, it is a substitute for Nickel 200 in Applications above 315℃. However it does suffer from intergranular embrittlement by sulfur compounds at temperatures above 315℃. Sodium peroxide can be used to change them to sulfates to counteract their effect.
| Alloy | Ni% | Mn% | Fe% | Si% | Cu% | C% | S% |
| Nickel 201 | Min 99 | Max 0.35 | Max 0.4 | Max 0.35 | Max 0.25 | Max 0.02 | Max 0.01 |
| Nickel 200 | Min 99.2 | Max 0.35 | Max 0.4 | Max 0.35 | Max 0.25 | Max 0.15 | Max 0.01 |
