Product Details
Place of Origin: China
Brand Name: Tankii
Certification: ISO RoHS AISI ASTM GB
Model Number: Ni-MH Batteries
Payment & Shipping Terms
Minimum Order Quantity: 1 Square Meter/Square Meters
Price: USD 35/ Square Meter
Packaging Details: Standard Export Package
Delivery Time: 5-10 days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 20 Tons/Month
Material: |
Pure Nickel |
Ppi: |
15~120 |
HS Code: |
7508909000 |
Transport Package: |
Standard Export Package |
Nominal Voltage: |
12V |
Usage: |
Car, Bus, UPS, Electric Power, Electric Bicycle, Boat |
Shape: |
Square Battery |
Color: |
Silver Gray |
Package: |
Paper Carton |
Origin: |
China |
Material: |
Pure Nickel |
Ppi: |
15~120 |
HS Code: |
7508909000 |
Transport Package: |
Standard Export Package |
Nominal Voltage: |
12V |
Usage: |
Car, Bus, UPS, Electric Power, Electric Bicycle, Boat |
Shape: |
Square Battery |
Color: |
Silver Gray |
Package: |
Paper Carton |
Origin: |
China |
Ni Foam Porous Metal Foam of Nickel Foam 80ppi 0.3*250mm
Foam Nickel is a low density permeable material that has a very high porosity with typically 75-95% of the volume consisting of void spaces. Nickel Foam has a wide variety of applications in heat exchangers, energy absorption, flow diffusion, lightweight optics and is used as a filter material for gas and liquid.
Tankii supplies high quality nickel foam for rechargeable battery applications. Our plates have proven to be excellent electrode substrates for Ni-Cd and Ni-H rechargeable batteries and hydrogen storage units.
Our Services
1. Full set of lithium battery materials, including:
LiMn2O4, LTO, LiNiMnCoO2(NMC), LiCoO2, Graphite(MCMB)and other cathode&anode battery materials; Alumimun foil, copper foils, battery separator, etc.
2. Full set of lithium battery equipments, for example:
Mixing machine --coating machine--oven--rolling machine--welding machine--slitting / cutiing machine --winding machine--sealed machine, etc.
3. Full set of lithium battery technology.
We can design the laboratory and production line, according to customer's request.
Ni Foam product is composed by pure Nickel. Product shows excellent properties of corrosion resistance and hardness. Usefulness: (Various shapes can be produced)
1. Used as the base plate of positive electrode in Ni-MH / Ni-Cd battery.
2. Filtration materials of air / oil / smoke etc.
3. Porous electrode in Galvano-Chemistry Engineering.
4. Elimination of heat.
5. Amortization materials.
6. Noise-Absorbing and Vibration-Absorbing materials.
7. Electromagnetic shielding materials.
8. Catalyst carrier.
9. Precious metal recovery.
| SPECIFICATION | ||
| ITEM | CONTINUOUS NICKEL FOAM | THICK NICKEL FOAM |
| THICKNESS | (0.3~2.5)±0.05mm | (2.6~12)±0.05mm |
| PPI | 90~120 | 20~80 |
| SURFACE DENSITY | (280~1800)±30g/M2 | (400~3000)±30g/M2 |
| TENSILE STRENGTH | (VERTICAL)≥130n/CM2 (HORIZONTAL)≥100n/CM2 | |
| ELONGATION | (VERTICAL)≥5% (HORIZONTAL)≥12% | |
| POROSITY | ≥96% | ≥96% |
| WIDTH | (50~960)±0.5mm | (50~960)±0.5mm |
| SPLICE FREQUENCY | 200m≤4 junction | largest length 1000mm |
| RATIO RESISTANCE | ≤5X10-6 | ≤5X10-6 |
| item name | nickel plate |
| Standard | ASTM B162 |
| Material | NUS N02201 (ASTM B 162) same as N4 (GB/T 2054). NUS N02200 (ASTM B 162) same as N6 (GB/T 2054). |
| type | plate sheet |
| Specification | Length 50-2000mm width 50-1200mm thickness 0.5-50mm |
| Packing | Export wooden case |
| MOQ | 10pcs |
| Lead time | Within 7~10 work days after deposit |
| Payment | T/T, Western Union,Money Gram, paypal , Trade Assurance |
| use | electric apparatus and chemical machinery Recording media, Graphic display, Glass coating, Solar Photovoltaic Application. |
| Loading port | Shanghai, qingdao, Shenzhen |
