Product Details
Place of Origin: Shanghai
Brand Name: Tankii
Certification: Rohs, SGS
Model Number: Ni80Cr20
Payment & Shipping Terms
Minimum Order Quantity: 50kg
Price: Negotiable
Packaging Details: Wooden case, pallet
Delivery Time: 7~30 working days
Payment Terms: L/C, T/T, Western Union, Paypal
Supply Ability: 3000T/Year
Features: |
High Resistivity |
Material: |
NiCr |
Package: |
Wooden Case |
Specification: |
Negotiable |
Use: |
Resistance Materials |
Resistivity At 20oC (μΩ·m): |
1.09 |
Density (g/cm3): |
8.4 |
Melting Point (approx.)(℃): |
1400 |
Thermal Conductivity(KJ/m·h·oC): |
60.3 |
Coefficient Of Lines Expansion (α×10-6/oC): |
18.0 |
Elongation At Rupture (%): |
＞20 |
Features: |
High Resistivity |
Material: |
NiCr |
Package: |
Wooden Case |
Specification: |
Negotiable |
Use: |
Resistance Materials |
Resistivity At 20oC (μΩ·m): |
1.09 |
Density (g/cm3): |
8.4 |
Melting Point (approx.)(℃): |
1400 |
Thermal Conductivity(KJ/m·h·oC): |
60.3 |
Coefficient Of Lines Expansion (α×10-6/oC): |
18.0 |
Elongation At Rupture (%): |
＞20 |
Electrical High Resistance NiCr8020/Ni80Cr20 Round Heating Wire for Elements in Water Heaters
Regular size of Nickel alloy wire :
We supply products in the shape of wire,flat wire,strip.We can also make customized material according to useris requests.
Bright and white wire--0.025mm~3mm
Pickling wire:1.8mm~10mm
Oxidized wire:0.6mm~10mm
Flat wire:thickness 0.05mm~1.0mm,width 0.5mm~5.0mm
Nickel chrome Ni80Cr20 Electrical resistivity of alloy main technical performance
| brand | Cr | Ni | Al | Fe | C | P | S | Mn | Si |
| ≤ | |||||||||
| Ni80Cr20 | 20.0~23.0 | Remain | ≤0.5 | ≤1 | 0.08 | 0.02 | 0.15 | 0.60 | 0.75~1.6 |
| brand | highest use temperature/ºC | Melting point/ºC | density (g/cm³) | resistivity/(μΩ·M) | elongation(%) | Coefficient of thermal conductivity | Linear expansion coefficient of | microstructure | magnetic |
| Ni80Cr20 | 1200 | 1400 | 8.40 | 1.09 | ≥20 | 60.3 | 18.0 | austenitic | no magnetic |
Mechanical properties
| brand | Tensile strength/Mpa |
| Ni80Cr20 | 637~786 |
Use time test
| brand | Test temperature/ºC | time/h |
| Ni80Cr20 | 1200 | 80 |
Shanghai Tankii Alloy Material Co., Ltd. specialized in production of Nichrome Alloy, Precision Alloy, Thermal bimetal strip and other alloy products.
Based on the principle of “first quality, sincere service”, our managing ideology is pursuing technology innovation and creating the top brand in the alloy field. We persist in Quality - the foundation of the survival. It is our forever ideology to serve you with full heart and soul. We committed to provide customers all over the world with high-quality, competitive products and perfect service.
Our products, such us nichrome wire, nichrome strip, fecral wire, fecral strip, thermocouple wire, nickel wire, nickel strip have been exported to Europe, USA, India, Southest Asia, South America,etc.
We are willing to establish strong and long-time partnership with our customers.
Your inquiry is a gift for us, your reply is a trust to us, your trust will bring us to provide you the best services in the business.
