Electric Arc Spray Zinc Wire 99.99% Purity for Thermal Spraying Coating

Product Details

Brand Name: TANKII

Certification: ISO9001

Payment & Shipping Terms

Minimum Order Quantity: 5kg

Price: Negotiation

Packaging Details: Products are generally supplied in standard cardboard boxes, pallets, wooden boxes. Special packaging requirements can also be accommodated. (also depend on the customers' requirements) For the Thermal spray wires , we pack the wires on spools. Then put s

Delivery Time: 7 work days

Payment Terms: T/T, Western Union, L/C

Supply Ability: 2000 tons per month

Get Best Price
Contact Now
Specifications
Highlight:

99.99% Purity Spray Zinc Wire

,

Thermal Coating Spray Zinc Wire

Place Of Origin:
China (Mainland)
Model Number:
Zn 99.99
Application:
Industry
Shape:
Round Wire
Material:
Pure Zinc
Chemical Composition:
Zinc 99.99
Certificate:
ISO9001
Standard:
GB
Place Of Origin:
China (Mainland)
Model Number:
Zn 99.99
Application:
Industry
Shape:
Round Wire
Material:
Pure Zinc
Chemical Composition:
Zinc 99.99
Certificate:
ISO9001
Standard:
GB
Description
Electric Arc Spray Zinc Wire 99.99% Purity for Thermal Spraying Coating

Electric Arc Spray Zinc Wire 99.99% Purity for Thermal Spraying Coating



Production Overview:



Electric arc spray wire / Thermal spraying with pure zinc wire was 99.99%, when the atmospheric conditions is not in serious corrosion (such as dry weather), can reduce the the purity to 99.95%.Zinc has good plasticity, can draw wire material, used for wire arc spraying and flame spraying.When in the flame spraying, purity of zinc in the process of spraying generally will not change.


Specification

Zinc wire for thermal spray
Composition : Zn 99.995%
Diameter : 0.5-4.76mm
Package : 20-50kg/bundle ; 20kg/Spool ;50-250kg/drum ; 500kgs/barrel


Applications


The thermal spraying zinc wire is used in a variety of applications, such as:

1. Galvanized steel pipe (galvanized steel square tube, galvanized round pipe, high frequency welded pipe, greenhouse pipe)
2. Wind power industry (wind turbine, wind turbine hub spray zinc, wind power flange spraying zinc, wind tower, wind turbine components, wind power bearing seat)
3.Iron spray zinc anti-corrosion
4. Ductile iron pipe / underground pipeline
5. Container industry -- refrigerated containers
6. Electric power tower (power pole)
7. Metallized film capacitor spray zinc
8. The surface of the bridge spray zinc corrosion (bridge wind braze spray zinc, steel beam sprayed zinc)
9. Traffic equipment fence spray zinc (road and bridge fence and the connection plate spray zinc, road and bridge fence spray zinc)
10. Spraying zinc on Expressway display rack
11.Water conservancy gate and facilities spraying zinc anti-corrosion (water conservancy facilities pipeline, steel gate spraying zinc, hoist)
12. Steel structure surface
13. Shaped steel parts (zinc spray for casting parts, hot spraying zinc for welded joints)
14. Electro-galvanized steel sheet
15. Car brake clamp body and bracket (automobile tubing and tubing assembly)
16.Marine / dockyard

Item
Chemical content
Zn
Cd
Pb
Fe
Cu
Balance Total
pure zinc
Nominal value
≥99.995
≤0.002
≤0.003
≤0.002
≤0.001
0.005
Diameter
Package
Zinc content
Φ1.3mm


25kg/bundle; 15-20kg/shaft; 50-200/barrel


≥99.9953
Φ1.6mm
Φ2.0mm
Φ2.3mm
Φ2.8mm
Φ3.0mm
Φ3.175mm
250kg/barrel
Φ4.0mm
200kg/barrel
Detailed Photos


99.99% pure zinc thermal spray wire chemical composition:

Chemical Composition Zn Cd Pb Fe Cu Total non-zinc
Normal Value Min99.995 Max0.002 Max0.003 Max0.002 Max0.001 0.005
Actual Value 99.9957 0.0017 0.0015 0.0008 0.0003 0.0043



99.99% pure zinc thermal spray wire Physical Properties:

Term Specification
Tensile Strength Mpa 115+/-10
Elongation % 45+/-5
Melting Point 419
Density g/cm3 7.14



Key benefits:

  1. Purity Zn > 99,995%, EN 117921 .
  2. Low Cadmium content: Cd 0,0002 - 0,0005 = only ca. 50% of the highest content allowed according to EN 117921 .
  3. Remarkable adhesiveness of zinc .
  4. Clean and smooth surface of the wire (good electric conductivity and high durability of nozzle) .



Product Images:



Electric Arc Spray Zinc Wire 99.99% Purity for Thermal Spraying Coating 0



Packaging & Shipping



Packaging:

Products are generally supplied in standard cardboard boxes, pallets, wooden boxes. Special packaging requirements can also be accommodated. (also depend on the customers' requirements)

For the Thermal spray wires , we pack the wires on spools. Then put spools into cartons, Then put the cartons onto pallet.



Shipping:

We cooperation with many logistics company,We can provide express, sea transportation, air transportation, and rail way transportation based on customers' requirement.





Our Services



1) We can provide a free sample for testing but the freight at yours.



2) Mill test certificate will be provided after production, If it is necessary.



3) Good packing methods to keep goods no damage during delivery



4) We cooperate with many famous forwarder, will try our best to choose the safty, convenience, quick, and cheap mode of transportation for our customers.



Electric Arc Spray Zinc Wire 99.99% Purity for Thermal Spraying Coating 1



How can I contact with your company?



We are always ready to serve you via Email, Telephone, Fax, Skype, Whatsapp or Mobile telephone.



Tel: +86-18017457857





Do you provide free samples?



Yes, we can provide a free sample for testing,buyer should bear all the shipping costs.



What is your payment terms?



T/T,L/C,D/A,D/P,Western Union,Paypal

We are doing the best to match your demand.



What is the lead time?



Usually sample lead time is 7 days after payment has been confirmed.

Normal order is 7-15days,it depends on customers’ quantity.

Anyway,we try to offer good-quality products as soon as possible.
