Product Details
Place of Origin: China
Brand Name: Superalloys
Certification: ISO 9001 and RoHS
Model Number: Incoloy 800H
Payment & Shipping Terms
Minimum Order Quantity: 50KG
Price: USD 35~70 / KG
Packaging Details: Wooden case or pallet
Delivery Time: 25-30 days
Payment Terms: T/T, Western Union, L/C
Supply Ability: 10000
Shape: |
Bar, Wire, Strip, Sheet, Flange |
Condition: |
Bright |
Density: |
8.0 |
Melting Point: |
1350~1400 |
Shape: |
Bar, Wire, Strip, Sheet, Flange |
Condition: |
Bright |
Density: |
8.0 |
Melting Point: |
1350~1400 |
Incoloy 800H / UNS N08810 High Temp Alloy for Nitric Condenser, High Temperature Steels
Name: Incoloy 800H / UNS N08810
Application: Ships, tanks with diesel exhaust valve mainly made of wrought Nimonic 80A. Nimonic 80A has high heat resistance, high strength at high temperatures, deformation resistance, increasing the difficulty of forging suitable for the manufacture of bolts, combustion chamber exhaust valve.
Feature:
3. Good workability
Description:
Chemical composition(%)
|
Grade |
% |
Ni |
Cr |
Fe |
C |
Mn |
Si |
Cu |
S |
Al |
Ti |
|
Incoloy 800H |
Min. |
30 |
19 |
|
0.05 |
|
|
|
|
0.15 |
0.15 |
|
Max. |
35 |
23 |
Bal. |
0.10 |
1.5 |
1 |
0.75 |
0.015 |
0.60 |
0.60 |
Physical properties
>Density (g/cm3): 8.0
>Melting point (℃): 1350~1400
Mechanical properties
|
|
Yield Strength (Mpa) |
Tensile Strength (Mpa) |
Elongation, % |
Hardness, HB |
|
Incoloy 800H |
180 |
450 |
≤35 |
|
