Hot Rolled High Temperature Electrical Wire For Heating Elements

Hot Rolled High Temperature Electrical Wire For Heating Elements
Hot Rolled High Temperature Electrical Wire For Heating Elements Hot Rolled High Temperature Electrical Wire For Heating Elements Hot Rolled High Temperature Electrical Wire For Heating Elements Hot Rolled High Temperature Electrical Wire For Heating Elements Hot Rolled High Temperature Electrical Wire For Heating Elements

Large Image :  Hot Rolled High Temperature Electrical Wire For Heating Elements

Product Details:
Place of Origin: Shanghai
Brand Name: Tankii
Certification: DIN, ASTM, JIS
Model Number: high temp alloy
Payment & Shipping Terms:
Minimum Order Quantity: 20kg
Price: 15-25$
Packaging Details: spool ,coil, or as clients' requirement
Delivery Time: 25days
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 1000T/month

Hot Rolled High Temperature Electrical Wire For Heating Elements

Description
Port: Shanghai Application: Structure
Standard: ASTM Type: Oxidation
Certification: Iso Material: Nickel Alloy
Technique: Hot Rolled Grade: NiCr Alloy
Usage: Construction Structure MOQ: 20KG
Highlight:

Oxidation High Temp Alloy Wire

,

26AWG High Temperature Electrical Wire

,

High Temperature Electrical Wire 2.0mm

1. Introduction:
Name: High Temperature Electrical Wire for Heating Elements
Size: 26AWG~4/0 AWG

1 Flexible nickel core
2 Fiberglass braid with high temperature finish
3 Mica tape
4 Fiberglass braid silicone impregnate with high temperature finish





2. Parameter:

SizeAWG ConductorStructure Insulation Thickness(mm) Braid Thickness(mm) Diameter(mm)
26 7/0.16 ≥0.64 ≥0.18 2.0±0.2
24 7/0.2 2.3±0.2
22 7/0.254 2.4±0.2
20 10/0.254 2.6±0.2
18 16/0.254 2.8±0.2
16 26/0.254 3.2±0.2
14 41/0.254 3.6±0.2
12 65/0.254 4.2±0.2
10 103/0.254 ≥0.76 ≥0.38 5.2±0.2
8 163/0.254 6.6±0.2
6 266/0.254 7.1±0.2
4 420/0.254 8.3±0.2

3.Technology:
Main technical parameters
Conductor Resistance 0.5 Ω /M/3m Min
Dielectric Strength AC1000V,Leakage Currence less than 0.25MA(3m)
Insulation Resistance DC 500V 100MΩ /3M MIN
Flex test 300G,90° degree each side,6cycles/min,morn than 3000 cycles
Adhesion Test Insulation adhesion during 1.15-2.5 LBS,Jack adhesion during 2-8LBS
Relative humidity ≤80%
Atmospheric pressure 700hPa~1060hPa


4. Advantages:
Ratings: -60°C~+450°C, 600V
Conductors: Nickel copper, Nickel
Insulation: Mica tape, fiberglass braid
Jacket: Fiberglass braid with high temperature finish
Unique insulation system offers outstanding heat-aged flexibility for longer service life.
Excellent cutting and stripping characteristics, making it ideal for high volume manufacturing and assembly.
Provides dimensional consistency and uniformity.
Suitable for applications to -60°C
Resists braid pushback.



5. Application
Used for internal wiring of

household ovens,
appliances,
lighting fixtures
and electronic equipment

as high-temperature lead wire.



Shanghai Tankii Alloy Material Co., Ltd. Focus on the production of resistance alloy(nichrome Alloy, FeCrAl Alloy, copper nickel alloy, thermocouple wire, precision alloy and thermal spray alloy in the form of wire, sheet, tape, strip, rod and plate. We've already got ISO9001 quality system certificate and approval of ISO14001 environmental protection system. We own a complete set of advanced production flow of refining, cold reduction, drawing and heat treating etc. We also proudly have independent R&D capacity.

Shanghai Tankii Alloy Material Co., Ltd has accumulated lots of experiences over 35 years in this field. During these years, more than 60 management elites and high science and technology talents were employed. They participated in every walk of the company life, which make our company keep blooming and invincible in the competitive market. Based on the principle of "first quality, sincere service", our managing ideology is pursuing technology innovation and creating the top brand in the alloy field. We persist in Quality - the foundation of the survival. It is our forever ideology to serve you with full heart and soul. We committed to provide customers all over the world with high-quality, competitive products and perfect service.

Our products, such us nichrome alloy, precision alloy, thermocouple wire, fecral alloy, copper nickel alloy, thermal spray alloy have been exported to over 60 countries in the world. We are willing to establish strong and long-time partnership with our customers. Most complete range of products dedicated to Resistance, Thermocouple and Furnace manufacturers Quality with end to end production control Technical support and Customer Service.
